FCC ID 2AIG4-MOD1
WiFi and BT Module
by DELTA Dansk Elektronik, Lys & Akustik
Grantee Code: 2AIG4 Product Code: MOD1
Latest application date: 2016-09-08
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-09-08 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-09-08 |
| 2402-2480 MHz | Change in identification of presently authorized equipment. Original FCC ID: Z64-WL18SBMOD Grant Date: 02/03/2014 | 2016-07-12 |
| 2402-2480 MHz | Change in identification of presently authorized equipment. Original FCC ID: Z64-WL18SBMOD Grant Date: 02/03/2014 | 2016-07-12 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 08_WiFi and BT Modul ExtPho | External Photos | 2016-07-12 | PDF 179.6 KB |
| 06_07_MOD1 LabeLSamp and LabelLoc | ID Label/Location Info | 2016-09-08 | PDF 101.7 KB |
| 06-07-WiFi and BT Modul LabelSmp+LabelLoc | ID Label/Location Info | 2016-07-12 | PDF 179.6 KB |
| 04_MOD1 AutLet-US | Attestation Statements | 2016-09-08 | PDF 260 KB |
| _Upload CL2PCH // G0M-1607-5732 | Attestation Statements | 2016-09-08 | PDF 260 KB |
| 04a_MOD1 AutLet original grantee-new grantee | Attestation Statements | 2016-07-12 | PDF 378.6 KB |
| 04b_MOD1 AuthLetter | Attestation Statements | 2016-07-12 | PDF 92.1 KB |
| 30_MOD1 CIIPCHLetter | Cover Letter(s) | 2016-09-08 | PDF 187.9 KB |
| 05_MOD1 ConReq | Cover Letter(s) | 2016-07-12 | PDF 135.1 KB |
| 46_MOD1 Change in ID | Cover Letter(s) | 2016-07-12 | PDF 139.2 KB |
| 18_MOD1 RFExp | RF Exposure Info | 2016-09-08 | PDF 268.6 KB |
Application Information
| Application ID | eHPQKX0eVpSSNlg3yRORIw== |
|---|---|
| Final Action Date | 2016-09-08 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0025594946 |
| Model | MOD1 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi and BT Module |
| Responsible Party | Birger Schneider, Vice President, Road Sensors & Lights, bis@delta.dk  , +45 40 55 21 00 |
| Test Firm | Jim Tsai, Sporton International Inc, jimtsai@sporton.com.tw  , 88633273456 |
| TCB Email | joergkusig@eurofins.de  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. This device has a 20 and 40 MHz bandwidth mode. Class II permissive change: The radio frequency radiation exposure evaluation is changed from mobile device (§2.1091) to a portable device (§2.1093). According to KDB 447498D01v06 clause 4.3 the radio module is compliant with the requirements for RF exposure with a minimum separation distance of 80 mm between the user and/or bystander for Head and Body configuration and 35 mm separation distance between the user and/or bystander of the device for Extremity / Limp worn configuration. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| eHPQKX0eVpSSNlg3yRORIw== | 2016-09-08 | Class II permissive change or modification of presently authorized equipment |
| OMTGcYQsxyq1k0HLJdu3Yg== | 2016-09-08 | Class II permissive change or modification of presently authorized equipment |
| c3nOEeS8Zm0Tp8Fy6ZHbGg== | 2016-07-12 | Change in identification of presently authorized equipment. Original FCC ID: Z64-WL18SBMOD Grant Date: 02/03/2014 |
| 75CU60EZkfx9XoKKUx1G5Q== | 2016-07-12 | Change in identification of presently authorized equipment. Original FCC ID: Z64-WL18SBMOD Grant Date: 02/03/2014 |
Equipment Authorization
Grants
TCB Grant - Application OMTGcYQsxyq1k0HLJdu3Yg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| DELTA Dansk Elektronik, Lys & Akustik |
| Venlighedsvej 4 |
| Horsholm, DK-2970 Denmark |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WiFi and BT Module |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0173 |
| Single Modular Approval. Power listed is conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. Class II permissive change: The radio frequency radiation exposure evaluation is changed from mobile device (§2.1091) to a portable device (§2.1093). According to KDB 447498D01v06 clause 4.3 the radio module is compliant with the requirements for RF exposure with a minimum separation distance of 80 mm between the user and/or bystander for Head and Body configuration and 35 mm separation distance between the user and/or bystander of the device for Extremity / Limp worn configuration. |
EAS Grant - Application OMTGcYQsxyq1k0HLJdu3Yg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
DELTA Dansk Elektronik, Lys & Akustik Venlighedsvej 4 Horsholm, DK-2970 Denmark |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WiFi and BT Module |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0173 |
| Single Modular Approval. Power listed is conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. Class II permissive change: The radio frequency radiation exposure evaluation is changed from mobile device (§2.1091) to a portable device (§2.1093). According to KDB 447498D01v06 clause 4.3 the radio module is compliant with the requirements for RF exposure with a minimum separation distance of 80 mm between the user and/or bystander for Head and Body configuration and 35 mm separation distance between the user and/or bystander of the device for Extremity / Limp worn configuration. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| DELTA Dansk Elektronik, Lys & Akustik |
| Venlighedsvej 4 |
| Horsholm, DK-2970 Denmark |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi and BT Module |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2402.0 - 2480.0 | 0.01 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.2438 | ||
| CC MO | 15C | 2422.0 - 2452.0 | 0.1052 |
| Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. This device has a 20 and 40 MHz bandwidth mode. Class II permissive change: The radio frequency radiation exposure evaluation is changed from mobile device (§2.1091) to a portable device (§2.1093). According to KDB 447498D01v06 clause 4.3 the radio module is compliant with the requirements for RF exposure with a minimum separation distance of 80 mm between the user and/or bystander for Head and Body configuration and 35 mm separation distance between the user and/or bystander of the device for Extremity / Limp worn configuration. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application eHPQKX0eVpSSNlg3yRORIw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
DELTA Dansk Elektronik, Lys & Akustik Venlighedsvej 4 Horsholm, DK-2970 Denmark |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi and BT Module |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2402.0 - 2480.0 | 0.01 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.2438 | ||
| CC MO | 15C | 2422.0 - 2452.0 | 0.1052 |
| Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. This device has a 20 and 40 MHz bandwidth mode. Class II permissive change: The radio frequency radiation exposure evaluation is changed from mobile device (§2.1091) to a portable device (§2.1093). According to KDB 447498D01v06 clause 4.3 the radio module is compliant with the requirements for RF exposure with a minimum separation distance of 80 mm between the user and/or bystander for Head and Body configuration and 35 mm separation distance between the user and/or bystander of the device for Extremity / Limp worn configuration. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 07/12/2016 Application Dated: 07/12/2016 |
| DELTA Dansk Elektronik, Lys & Akustik |
| Venlighedsvej 4 |
| Horsholm, DK-2970 Denmark |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi and BT Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2402.0 - 2480.0 | 0.01 | ||
| MO | 15C | 2412.0 - 2462.0 | 0.2438 | ||
| MO | 15C | 2422.0 - 2452.0 | 0.1052 |
| Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 1.22dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has a 20 and 40 MHz bandwidth mode. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application c3nOEeS8Zm0Tp8Fy6ZHbGg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
DELTA Dansk Elektronik, Lys & Akustik Venlighedsvej 4 Horsholm, DK-2970 Denmark |
Date of Grant: 07/12/2016 Application Dated: 07/12/2016 |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi and BT Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2402.0 - 2480.0 | 0.01 | ||
| MO | 15C | 2412.0 - 2462.0 | 0.2438 | ||
| MO | 15C | 2422.0 - 2452.0 | 0.1052 |
| Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 1.22dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has a 20 and 40 MHz bandwidth mode. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 07/12/2016 Application Dated: 07/12/2016 |
| DELTA Dansk Elektronik, Lys & Akustik |
| Venlighedsvej 4 |
| Horsholm, DK-2970 Denmark |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WiFi and BT Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0173 |
| Single Modular Approval. Power listed is conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of -0.36dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application 75CU60EZkfx9XoKKUx1G5Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
DELTA Dansk Elektronik, Lys & Akustik Venlighedsvej 4 Horsholm, DK-2970 Denmark |
Date of Grant: 07/12/2016 Application Dated: 07/12/2016 |
| Attention: Birger Schneider , Vice President, Road Sensors & Lights |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIG4-MOD1 |
| Name of Grantee: | DELTA Dansk Elektronik, Lys & Akustik |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | WiFi and BT Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0173 |
| Single Modular Approval. Power listed is conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of -0.36dBi. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| Mail To: |
