FCC ID 2AIHT50T0178B
Smart Color Touch MDT
by Trapeze Software Group, Inc.
Grantee Code: 2AIHT Product Code: 50T0178B
Latest application date: 2017-03-22
Device Images
FCC ID Device Details
| FCC ID | 2AIHT50T0178B |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AIHT |
| Product Code | 50T0178B |
| Applicant Business | Trapeze Software Group, Inc. 🇺🇸 |
| Related Domains |  trapezegroup.com |
| Equipment Class | Smart Color Touch MDT |
| Test Firm | Intertek Testing Services NA |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-03-22 |
| 779.5-784.5 MHz | Original Equipment | 2017-03-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-05-06 | PDF 87.1 KB |
| User Manual | Users Manual | 2017-05-05 | PDF 87.1 KB |
| MDT Internal photos | Internal Photos | 2017-05-06 | PDF 3.6 MB |
| Original module Internal photos | Internal Photos | 2017-05-06 | PDF 233.4 KB |
| Original Module Internal Photos | Internal Photos | 2017-05-05 | PDF 220.2 KB |
| External photos | External Photos | 2017-05-06 | PDF 331.4 KB |
| Label and location info | ID Label/Location Info | 2017-03-22 | PDF 196.3 KB |
| Label artwork and location info | ID Label/Location Info | 2017-03-21 | PDF 196.3 KB |
| Test setup photos | Test Setup Photos | 2017-05-06 | PDF 249.3 KB |
| MDT Test Report radiated | Test Report | 2017-03-22 | PDF 194.2 KB |
| Original module Test Report | Test Report | 2017-03-22 | PDF 3.7 MB |
| Test Report_Original module MC7750 part 22, 24 | Test Report | 2017-03-21 | PDF 2.8 MB |
| Test Report_Original module MC7750 part 27 | Test Report | 2017-03-21 | PDF 1.6 MB |
| Test report | Test Report | 2017-03-21 | PDF 114.6 KB |
| Confidentiality request | Cover Letter(s) | 2017-03-22 | PDF 38 KB |
| Cover Letter | Cover Letter(s) | 2017-03-22 | PDF 19 KB |
| Confidentiality letter | Cover Letter(s) | 2017-03-21 | PDF 38 KB |
| MPE calculation | RF Exposure Info | 2017-03-22 | PDF 140.4 KB |
| RF Exposure analysis | RF Exposure Info | 2017-03-21 | PDF 140.4 KB |
| MDT Block diagram Metadata only | Block Diagram | PDF 120.5 KB | |
| Original module MC7750 block diagram Metadata only | Block Diagram | PDF 169.3 KB | |
| Original module block diagram Metadata only | Block Diagram | PDF 183.6 KB | |
| MDT Schematic Metadata only | Schematics | PDF 3.3 MB | |
| Original module MC7750 schematic Metadata only | Schematics | PDF 612.9 KB | |
| Original module Schematic Metadata only | Schematics | PDF 731.8 KB | |
| MDT Operational description Metadata only | Operational Description | PDF 452.1 KB | |
| Operational description Metadata only | Operational Description | PDF 658.8 KB | |
| Original module MC7750 operational description Metadata only | Operational Description | PDF 269.9 KB | |
| Original module MC7750 tune up procedure Metadata only | Parts List/Tune Up Info | PDF 29.8 KB |
Application Information
| Application ID | hshH3hc3S5DupCKov91vsQ== |
|---|---|
| Final Action Date | 2017-03-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023778913 |
| Model | 50T0178B |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Smart Color Touch MDT |
| Responsible Party | Troy Taylor, troy.taylor@trapezegroup.com , 319-743-1000 |
| Technical Contact | Adam Edabum, Trapeze Software Group, Inc., adam.edabum@trapezegroup.com , 319-743-1049 |
| Non-Technical Contact | Andrew Mossman, Trapeze Software Group, Inc., Andrew.mossman@trapezegroup.com , 3197434574 |
| Test Firm | James Sudduth, Intertek Testing Services NA, james.sudduth@intertek.com  , 859-226-1037 |
| TCB Email | TCB_Admin@intertek.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 05/06/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is maximum conducted. The antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| hshH3hc3S5DupCKov91vsQ== | 2017-03-22 | Original Equipment |
| +hkeR0TqD7//pviIKOKF5A== | 2017-03-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 779.5-784.5 MHz | 0.221 | 2.5ppm | 4M48W7D | 27 | |
| 779.5-784.5 MHz | 0.224 | 2.5ppm | 4M49G7D | 27 | |
| 782 MHz | 0.227 | 2.5ppm | 8M90G7D | 27 | |
| 782 MHz | 0.226 | 2.5ppm | 8M91W7D | 27 | |
| 824.2-848.8 MHz | 0.419 | 2.5ppm | 236KG7W | 22H | |
| 824.7-848.31 MHz | 0.34 | 2.5ppm | 1M28F9W | 22H | |
| 826.4-846.6 MHz | 0.22 | 2.5ppm | 4M14F9W | 22H | |
| 1850.2-1909.8 MHz | 0.899 | 2.5ppm | 243KGXW | 24E | |
| 1850.2-1909.8 MHz | 0.34 | 2.5ppm | 240KG7W | 22H | |
| 1851.25-1908.75 MHz | 0.337 | 2.5ppm | 1M28F9W | 22H | |
| 1852.4-1907.6 MHz | 0.182 | 2.5ppm | 4M17F9W | 22H | |
| 2412-2462 MHz | 0.128 | 15C | CC | ||
| 2412-2462 MHz | 0.082 | 15C | CC | ||
| 2422-2452 MHz | 0.067 | 15C | CC |
Grants
TCB Grant - Application hshH3hc3S5DupCKov91vsQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 |
Date of Grant: 03/22/2017 Application Dated: 03/21/2017 |
| Trapeze Software Group, Inc. |
| 5265 Rockwell Dr. NE |
| Cedar Rapids, IA 52402 |
| Attention: Troy Taylor |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIHT50T0178B |
| Name of Grantee: | Trapeze Software Group, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart Color Touch MDT |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.128 | ||
| CC | 15C | 2412.0 - 2462.0 | 0.082 | ||
| CC | 15C | 2422.0 - 2452.0 | 0.067 |
| Output power listed is maximum conducted. The antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application hshH3hc3S5DupCKov91vsQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Trapeze Software Group, Inc. 5265 Rockwell Dr. NE Cedar Rapids, IA 52402 United States |
Date of Grant: 03/22/2017 Application Dated: 03/21/2017 |
| Attention: Troy Taylor |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIHT50T0178B |
| Name of Grantee: | Trapeze Software Group, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart Color Touch MDT |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.128 | ||
| CC | 15C | 2412.0 - 2462.0 | 0.082 | ||
| CC | 15C | 2422.0 - 2452.0 | 0.067 |
| Output power listed is maximum conducted. The antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or used in conjunction with any other antenna or transmitter except the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 |
Date of Grant: 03/21/2017 Application Dated: 03/19/2017 |
| Trapeze Software Group, Inc. |
| 5265 Rockwell Dr. NE |
| Cedar Rapids, IA 52402 |
| Attention: Troy Taylor |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIHT50T0178B |
| Name of Grantee: | Trapeze Software Group, Inc. |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Smart Color Touch MDT |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.82 | 2.5 PM | 241KGXW | |
| 22H | 824.2 - 848.8 | 0.419 | 2.5 PM | 236KG7W | |
| 22H | 826.4 - 846.6 | 0.22 | 2.5 PM | 4M14F9W | |
| 22H | 824.7 - 848.31 | 0.34 | 2.5 PM | 1M28F9W | |
| 24E | 1850.2 - 1909.8 | 0.899 | 2.5 PM | 243KGXW | |
| 22H | 1850.2 - 1909.8 | 0.34 | 2.5 PM | 240KG7W | |
| 22H | 1852.4 - 1907.6 | 0.182 | 2.5 PM | 4M17F9W | |
| 22H | 1851.25 - 1908.75 | 0.337 | 2.5 PM | 1M28F9W | |
| 27 | 779.5 - 784.5 | 0.224 | 2.5 PM | 4M49G7D | |
| 27 | 779.5 - 784.5 | 0.221 | 2.5 PM | 4M48W7D | |
| 27 | 782.0 - 782.0 | 0.227 | 2.5 PM | 8M90G7D | |
| 27 | 782.0 - 782.0 | 0.226 | 2.5 PM | 8M91W7D |
| Power output is conducted at the antenna terminal. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures or as documented in this filing. Under no conditions may an antenna gain be used that would exceed the ERP and/or EIRP power limits as specified in Parts 22, 24 and 27. Users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
