FCC ID 2AIIEBC0803
BOX
by ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH
Grantee Code: 2AIIE Product Code: BC0803
Latest application date: 2016-06-23
Device Images
FCC ID Device Details
| FCC ID | 2AIIEBC0803 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AIIE |
| Product Code | BC0803 |
| Applicant Business | ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH 🇨🇳 |
| Related Domains |  archermind.com  audix.com.cn |
| Equipment Class | BOX |
| Test Firm | Audix Technology (Shenzhen) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-06-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| BC0803_User manual (Backside) rev1 | Users Manual | 2016-06-23 | PDF 100.9 KB |
| BC0803_user manual(frontside) | Users Manual | 2016-06-23 | PDF 31.6 KB |
| BC0803-Int Photos rev1 | Internal Photos | 2016-06-23 | PDF 1.1 MB |
| BC0803_Inside of the Adapter | Internal Photos | 2016-06-23 | PDF 193 KB |
| BC0803-Ext Photos rev1 | External Photos | 2016-06-23 | PDF 369 KB |
| BC0801_Label rev1 | ID Label/Location Info | 2016-06-23 | PDF 276.2 KB |
| BC0803_Test Setup | Test Setup Photos | 2016-06-23 | PDF 632.6 KB |
| BC0803-FCC ID_Test Report rev2 | Test Report | 2016-06-23 | PDF 3.3 MB |
| BC0803-MPE Test Report | RF Exposure Info | 2016-06-23 | PDF 247.7 KB |
| FCC DOC DECLARATION 20160622 | Attestation Statements | 2016-06-23 | PDF 223 KB |
| ACB-Form-FCC&IC-Application-Confidential Letter | Cover Letter(s) | 2016-06-23 | PDF 116.1 KB |
| ACB-Form-FCC-Application-Authorization Letter | Cover Letter(s) | 2016-06-23 | PDF 106.4 KB |
| BC0801_Block diagrame rev1 Metadata only | Block Diagram | PDF 45.4 KB | |
| BC0801_SCH rev1 Metadata only | Schematics | PDF 666.7 KB | |
| BC0801_Operational description(Spec) rev2 Metadata only | Operational Description | PDF 84.6 KB |
Application Information
| Application ID | hN5E5iKNqRdjY8eiuPCNdQ== |
|---|---|
| Final Action Date | 2016-06-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025605825 |
| Model | BC0803 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | BOX |
| Responsible Party | Qi Li, project Manager, qi.li@archermind.com , +86-755 26498793 |
| Agent | AUDIX Technology (Shenzhen) Co., Ltd., Sunny_lu@audix.com.cn , 86-755-26639497 |
| Technical Contact | AUDIX Technology (Shenzhen) Co., Ltd., sunny_lu@audix.com.cn , 86-755-26639497 |
| Non-Technical Contact | AUDIX Technology (Shenzhen) Co., Ltd., David_jin@audix.com.cn , 86-755-26639497 |
| Test Firm | Smart Tsai, Audix Technology (Shenzhen) Co., Ltd., sindy_song@audix.com.cn , 86-755-26639495 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| hN5E5iKNqRdjY8eiuPCNdQ== | 2016-06-23 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0208000 | 15C |
Grants
TCB Grant - Application hN5E5iKNqRdjY8eiuPCNdQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 06/23/2016 Application Dated: 06/22/2016 |
| ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH |
| Building B,Idiopathic Information Port, |
| No.2 Kefeng Road,Shenzhen P.R.C |
| Shenzhen, China |
| Attention: Qi Li , project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIIEBC0803 |
| Name of Grantee: | ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH |
| Equipment Class: | Digital Transmission System |
| Notes: | BOX |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0208 |
| Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
EAS Grant - Application hN5E5iKNqRdjY8eiuPCNdQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH Building B,Idiopathic Information Port, No.2 Kefeng Road,Shenzhen P.R.C Shenzhen, China |
Date of Grant: 06/23/2016 Application Dated: 06/22/2016 |
| Attention: Qi Li , project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIIEBC0803 |
| Name of Grantee: | ArcherMind TECHNOLOGY(NANJING) CO.,LTD. SHENZHEN BRANCH |
| Equipment Class: | Digital Transmission System |
| Notes: | BOX |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0208 |
| Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
