FCC ID 2AILF-DL2106A
WiFi Module
by Hangzhou Delan Technology Co., Ltd.
Grantee Code: 2AILF Product Code: DL2106A
Latest application date: 2016-06-16
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-06-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-06-16 | PDF 854.3 KB |
| Internal photo | Internal Photos | 2016-06-16 | PDF 206.8 KB |
| External photo | External Photos | 2016-06-16 | PDF 171.2 KB |
| Label info | ID Label/Location Info | 2016-06-16 | PDF 9.1 KB |
| Label location | ID Label/Location Info | 2016-06-16 | PDF 90.6 KB |
| Test setup photo | Test Setup Photos | 2016-06-16 | PDF 450 KB |
| RF report | Test Report | 2016-06-16 | PDF 3.4 MB |
| Confidentiality request letter | Cover Letter(s) | 2016-06-16 | PDF 23 KB |
| Module request letter | Cover Letter(s) | 2016-06-16 | PDF 44.4 KB |
| POA | Cover Letter(s) | 2016-06-16 | PDF 619.6 KB |
| WIFI declaration | Cover Letter(s) | 2016-06-16 | PDF 28.5 KB |
| MPE | RF Exposure Info | 2016-06-16 | PDF 30.7 KB |
| Block diagram Metadata only | Block Diagram | PDF 113.5 KB | |
| Schematics Metadata only | Schematics | PDF 73.3 KB | |
| Operational description Metadata only | Operational Description | PDF 32.4 KB |
Application Information
| Application ID | nyPoxmnGdWy+woIUj5/Z2g== |
|---|---|
| Final Action Date | 2016-06-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025616996 |
| Model | DL2106A |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi Module |
| Responsible Party | Xinghai Feng, General Manager, feng@idelan.cn  , +86-0571-28137003 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Listed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| nyPoxmnGdWy+woIUj5/Z2g== | 2016-06-16 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0495000 | 15C |
Grants
TCB Grant - Application nyPoxmnGdWy+woIUj5/Z2g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 06/16/2016 Application Dated: 06/16/2016 |
| Hangzhou Delan Technology Co., Ltd. |
| 5/F, Hangzhou Qianjiang Building, No.398, |
| Tianmushan Road, Xihu District, |
| Hangzhou, Zhejiang, China |
| Attention: Xinghai Feng , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AILF-DL2106A |
| Name of Grantee: | Hangzhou Delan Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0495 |
| Listed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
EAS Grant - Application nyPoxmnGdWy+woIUj5/Z2g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Hangzhou Delan Technology Co., Ltd. 5/F, Hangzhou Qianjiang Building, No.398, Tianmushan Road, Xihu District, Hangzhou, Zhejiang, China |
Date of Grant: 06/16/2016 Application Dated: 06/16/2016 |
| Attention: Xinghai Feng , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AILF-DL2106A |
| Name of Grantee: | Hangzhou Delan Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0495 |
| Listed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
