FCC ID 2AIM5BKMIC
Wireless Microphone
by Legacy Direct
Grantee Code: 2AIM5 Product Code: BKMIC
Latest application date: 2017-02-11
Device Images
FCC ID Device Details
| FCC ID | 2AIM5BKMIC |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AIM5 |
| Product Code | BKMIC |
| Applicant Business | Legacy Direct 🇺🇸 |
| Related Domains |  legacy.direct |
| Equipment Class | Wireless Microphone |
| Test Firm | Shenzhen STS Test Services Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 615.15-620.85 MHz | Original Equipment | 2017-02-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2017-02-11 | PDF 3.6 MB |
| Internal photos | Internal Photos | 2017-02-11 | PDF 734.2 KB |
| External photos | External Photos | 2017-02-11 | PDF 518.7 KB |
| Label | ID Label/Location Info | 2017-02-11 | PDF 88.3 KB |
| Test setup | Test Setup Photos | 2017-02-11 | PDF 263.9 KB |
| Test report | Test Report | 2017-02-11 | PDF 2 MB |
| Cover letter | Cover Letter(s) | 2017-02-11 | PDF 192.3 KB |
| RF Exposure | RF Exposure Info | 2017-02-11 | PDF 182.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 74 KB | |
| Schematics Metadata only | Schematics | PDF 55 KB | |
| Operational Description Metadata only | Operational Description | PDF 116.1 KB | |
| Tune up Metadata only | Parts List/Tune Up Info | PDF 108.9 KB |
Application Information
| Application ID | /Y51ZrFnzZCwB8o5dtEJtg== |
|---|---|
| Final Action Date | 2017-02-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025626409 |
| Model | BKMIC |
| Frequency Range | 615.15-620.85 MHz |
| Equipment Class | TBF - Licensed Broadcast Transmitter Held to Face |
| Device Description | Wireless Microphone |
| Responsible Party | James Wang, james@legacy.direct , 9498995189 |
| Test Firm | Bovey Yang, Shenzhen STS Test Services Co., Ltd., bovey@stsapp.com  , (86)-0755-61996328 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| /Y51ZrFnzZCwB8o5dtEJtg== | 2017-02-11 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application /Y51ZrFnzZCwB8o5dtEJtg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 02/11/2017 Application Dated: 02/11/2017 |
| Legacy Direct |
| 1221 E. Dyer Rd. #110 |
| Santa Ana, CA 92705 |
| Attention: James Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIM5BKMIC |
| Name of Grantee: | Legacy Direct |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | Wireless Microphone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| M4 | 74.861 | 615.15 - 620.85 | 0.001878 | 22.8 PM | 81K4F3E |
| Output power listed is conducted. |
| M4: | Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. |
EAS Grant - Application /Y51ZrFnzZCwB8o5dtEJtg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Legacy Direct 1221 E. Dyer Rd. #110 Santa Ana, CA 92705 United States |
Date of Grant: 02/11/2017 Application Dated: 02/11/2017 |
| Attention: James Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIM5BKMIC |
| Name of Grantee: | Legacy Direct |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | Wireless Microphone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| M4 | 74.861 | 615.15 - 620.85 | 0.001878 | 22.8 PM | 81K4F3E |
| Output power listed is conducted. |
| M4: | Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. |
| Mail To: |
