FCC ID 2AINMMT7687MODULE
MT7687 MODULE
by Silicon Application Corp.
Grantee Code: 2AINM Product Code: MT7687MODULE
Latest application date: 2016-08-09
Device Images
FCC ID Device Details
| FCC ID | 2AINMMT7687MODULE |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AINM |
| Product Code | MT7687MODULE |
| Applicant Business | Silicon Application Corp. 🇨🇳 |
| Related Domains |  sac.com.hk |
| Equipment Class | MT7687 MODULE |
| Test Firm | Bay Area Compliance Laboratories Corp. (Dongguan) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-08-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-09 | PDF 836.9 KB |
| Int Photos | Internal Photos | 2016-08-09 | PDF 234.5 KB |
| Ext Photos | External Photos | 2016-08-09 | PDF 117.8 KB |
| FCC ID Label | ID Label/Location Info | 2016-08-09 | PDF 90 KB |
| Setup Photos | Test Setup Photos | 2016-08-09 | PDF 188.3 KB |
| Test Report | Test Report | 2016-08-09 | PDF 1.4 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-08-09 | PDF 75.7 KB |
| Module Approval Letter | Cover Letter(s) | 2016-08-09 | PDF 104.5 KB |
| POA | Cover Letter(s) | 2016-08-09 | PDF 78.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 79.6 KB | |
| Schematics Metadata only | Schematics | PDF 86.6 KB | |
| Operation Description Metadata only | Operational Description | PDF 76.9 KB |
Application Information
| Application ID | 8iUDpT7nINvSn1M0v43XWw== |
|---|---|
| Final Action Date | 2016-08-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025624677 |
| Model | MT7687MODULE |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | MT7687 MODULE |
| Responsible Party | YL Qiao, YL.Qiao@sac.com.hk , +86-755-2671-1655 |
| Test Firm | John Chan, Bay Area Compliance Laboratories Corp. (Dongguan), john.chan@baclcorp.com  , 86-769-86858888 |
| TCB Email | bacl.regulatory@baclcorp.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This grant is valid only when the module is sold to OEM or OEM integrators. Modular approval for use as a module in mobile-only RF exposure conditions. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. Installation of this device into portable RF Exposure category host devices requires the submission of a Class II permissive change or new application. The device has 20 MHz and 40 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 8iUDpT7nINvSn1M0v43XWw== | 2016-08-09 | Original Equipment |
Grants
TCB Grant - Application 8iUDpT7nINvSn1M0v43XWw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bay Area Compliance Laboratory Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 |
Date of Grant: 08/09/2016 Application Dated: 08/09/2016 |
| Silicon Application Corp. |
| 7F, Block 2, Kai Da Er Building, NO.168 |
| TongSha Road, XiLi Town, Nanshan |
| Shenzhen, China |
| Attention: YL Qiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AINMMT7687MODULE |
| Name of Grantee: | Silicon Application Corp. |
| Equipment Class: | Digital Transmission System |
| Notes: | MT7687 MODULE |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.1197 | |||
| 15C | 2422.0 - 2452.0 | 0.1233 |
| Output power listed is conducted. This grant is valid only when the module is sold to OEM or OEM integrators. Modular approval for use as a module in mobile-only RF exposure conditions. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. Installation of this device into portable RF Exposure category host devices requires the submission of a Class II permissive change or new application. The device has 20 MHz and 40 MHz bandwidth modes. |
EAS Grant - Application 8iUDpT7nINvSn1M0v43XWw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Silicon Application Corp. 7F, Block 2, Kai Da Er Building, NO.168 TongSha Road, XiLi Town, Nanshan Shenzhen, China |
Date of Grant: 08/09/2016 Application Dated: 08/09/2016 |
| Attention: YL Qiao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AINMMT7687MODULE |
| Name of Grantee: | Silicon Application Corp. |
| Equipment Class: | Digital Transmission System |
| Notes: | MT7687 MODULE |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.1197 | |||
| 15C | 2422.0 - 2452.0 | 0.1233 |
| Output power listed is conducted. This grant is valid only when the module is sold to OEM or OEM integrators. Modular approval for use as a module in mobile-only RF exposure conditions. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. Installation of this device into portable RF Exposure category host devices requires the submission of a Class II permissive change or new application. The device has 20 MHz and 40 MHz bandwidth modes. |
