FCC ID 2AIQM-214231
IEEE 802.15.4 RF Module
by Carmanah Signs Inc
Grantee Code: 2AIQM Product Code: 214231
Latest application date: 2016-08-11
Device Images
FCC ID Device Details
| FCC ID | 2AIQM-214231 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AIQM |
| Product Code | 214231 |
| Applicant Business | Carmanah Signs Inc 🇨🇦 |
| Related Domains |  carmanahsigns.com |
| Equipment Class | IEEE 802.15.4 RF Module |
| Test Firm | QAI LABORATORIES LTD. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-08-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-11 | PDF 844.1 KB |
| Internal Photos | Internal Photos | 2016-08-11 | PDF 477.5 KB |
| External Photos | External Photos | 2016-08-11 | PDF 275.8 KB |
| Label Location | ID Label/Location Info | 2016-08-11 | PDF 251.6 KB |
| Label Sample | ID Label/Location Info | 2016-08-11 | PDF 93.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-11 | PDF 751 KB |
| Test Report | Test Report | 2016-08-11 | PDF 2.8 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-08-11 | PDF 261 KB |
| Letter for Modular Approval | Cover Letter(s) | 2016-08-11 | PDF 320.3 KB |
| POA | Cover Letter(s) | 2016-08-11 | PDF 284 KB |
| Block Diagram Metadata only | Block Diagram | PDF 56.8 KB | |
| Schematics Metadata only | Schematics | PDF 257.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 328.2 KB | |
| Part List Metadata only | Parts List/Tune Up Info | PDF 214.8 KB |
Application Information
| Application ID | wqavU9WlIXPIdvq2788RhA== |
|---|---|
| Final Action Date | 2016-08-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025542697 |
| Model | 214231 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | IEEE 802.15.4 RF Module |
| Responsible Party | Bryce Klippenstein, Electrical Engineer, bklippenstein@carmanahsigns.com , 4032526047 |
| Test Firm | Parminder Singh, QAI LABORATORIES LTD., psingh@qai.org  , 604-527-8378 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The end-product must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter or in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| wqavU9WlIXPIdvq2788RhA== | 2016-08-11 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0020000 | 15C |
Grants
TCB Grant - Application wqavU9WlIXPIdvq2788RhA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 08/11/2016 Application Dated: 08/11/2016 |
| Carmanah Signs Inc |
| #5 - 6025 12th St SE. |
| Calgary, T2H 2K1 Canada |
| Attention: Bryce Klippenstein , Electrical Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIQM-214231 |
| Name of Grantee: | Carmanah Signs Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | IEEE 802.15.4 RF Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.002 |
| Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The end-product must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter or in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application wqavU9WlIXPIdvq2788RhA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Carmanah Signs Inc #5 - 6025 12th St SE. Calgary, T2H 2K1 Canada |
Date of Grant: 08/11/2016 Application Dated: 08/11/2016 |
| Attention: Bryce Klippenstein , Electrical Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIQM-214231 |
| Name of Grantee: | Carmanah Signs Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | IEEE 802.15.4 RF Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.002 |
| Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The end-product must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter or in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| Mail To: |
