FCC ID 2AITMDS830
DS830
by Shenzhen Smart Device Technology Co., LTD
Grantee Code: 2AITM Product Code: DS830
Latest application date: 2016-07-06
Device Images
FCC ID Device Details
| FCC ID | 2AITMDS830 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AITM |
| Product Code | DS830 |
| Applicant Business | Shenzhen Smart Device Technology Co., LTD 🇨🇳 |
| Related Domains |  smdt.com.cn |
| Equipment Class | DS830 |
| Test Firm | Shenzhen BCTC Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-07-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2016-07-06 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-07-06 | PDF 259.6 KB |
| External Photos | External Photos | 2016-07-06 | PDF 342.9 KB |
| label&label location | ID Label/Location Info | 2016-07-06 | PDF 125.3 KB |
| Setup Photos | Test Setup Photos | 2016-07-06 | PDF 163.9 KB |
| test report | Test Report | 2016-07-06 | PDF 1.8 MB |
| DoC Attestation letter | Cover Letter(s) | 2016-07-06 | PDF 116.2 KB |
| Agent Authorization Letter | Cover Letter(s) | 2016-07-06 | PDF 97.3 KB |
| Declaration Letter | Cover Letter(s) | 2016-07-06 | PDF 87 KB |
| Long Term Confidentiality Request Letter | Cover Letter(s) | 2016-07-06 | PDF 125.7 KB |
| Model Difference | Cover Letter(s) | 2016-07-06 | PDF 102.7 KB |
| MPE | RF Exposure Info | 2016-07-06 | PDF 183.1 KB |
| Block diagram Metadata only | Block Diagram | PDF 104.5 KB | |
| SCH Metadata only | Schematics | PDF 591.2 KB | |
| Operation Description Metadata only | Operational Description | PDF 131.4 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 94.6 KB |
Application Information
| Application ID | 0txD6QSBQos0eZoA6o+2gw== |
|---|---|
| Final Action Date | 2016-07-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025672015 |
| Model | DS830 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | DS830 |
| Responsible Party | Ling Zhang, Manager, lzhang@smdt.com.cn , 0755-26992276 |
| Technical Contact | James Zhang, Shenzhen BCTC Technology Co., Ltd, jams.zhang@btc-lab.com  , 86-755-33640208 |
| Test Firm | James Zhang, Shenzhen BCTC Technology Co., Ltd., jams.zhang@btc-lab.com , 86-755-33640208 |
| TCB Email | tcbinfo@metlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is conducted. The antennas as listed in this application must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device supports 20 MHz and 40 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0txD6QSBQos0eZoA6o+2gw== | 2016-07-06 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0430000 | 15C |
Grants
TCB Grant - Application 0txD6QSBQos0eZoA6o+2gw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 07/06/2016 Application Dated: 07/06/2016 |
| Shenzhen Smart Device Technology Co., LTD |
| 17th-18th floor, Guoshi Mansion, |
| Shahe West Road 1801, Nanshan, |
| Shenzhen, China |
| Attention: Ling Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AITMDS830 |
| Name of Grantee: | Shenzhen Smart Device Technology Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | DS830 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.043 |
| Output power is conducted. The antennas as listed in this application must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device supports 20 MHz and 40 MHz bandwidth modes. |
EAS Grant - Application 0txD6QSBQos0eZoA6o+2gw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen Smart Device Technology Co., LTD 17th-18th floor, Guoshi Mansion, Shahe West Road 1801, Nanshan, Shenzhen, China |
Date of Grant: 07/06/2016 Application Dated: 07/06/2016 |
| Attention: Ling Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AITMDS830 |
| Name of Grantee: | Shenzhen Smart Device Technology Co., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | DS830 |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.043 |
| Output power is conducted. The antennas as listed in this application must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device supports 20 MHz and 40 MHz bandwidth modes. |
