FCC ID 2AIWW-PD-V5
Microwave Sensor
by Ningbo Pdlux Electronic Technology CO.,LTD.
Grantee Code: 2AIWW Product Code: PDV5
Latest application date: 2016-07-28
Device Images
FCC ID Device Details
| FCC ID | 2AIWW-PD-V5 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AIWW |
| Product Code | PDV5 |
| Applicant Business | Ningbo Pdlux Electronic Technology CO.,LTD. 🇨🇳 |
| Related Domains |  lexing.com |
| Equipment Class | Microwave Sensor |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5805.25 MHz | Original Equipment | 2016-07-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-28 | PDF 2.4 MB |
| Internal Photos | Internal Photos | 2016-07-28 | PDF 746.9 KB |
| External Photos | External Photos | 2016-07-28 | PDF 1,011.9 KB |
| Label Info/Location | ID Label/Location Info | 2016-07-28 | PDF 339.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-07-28 | PDF 159.6 KB |
| Test Report | Test Report | 2016-07-28 | PDF 2.5 MB |
| Authorization Letter | Cover Letter(s) | 2016-07-28 | PDF 158.5 KB |
| Confidentiality Request | Cover Letter(s) | 2016-07-28 | PDF 94 KB |
| Modular Request | Cover Letter(s) | 2016-07-28 | PDF 128.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 65.4 KB | |
| Schematics Metadata only | Schematics | PDF 129.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 82.7 KB |
Application Information
| Application ID | 0rfLdy1Rc1DrUvPs5cTBtg== |
|---|---|
| Final Action Date | 2016-07-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025694423 |
| Model | PD-V5 |
| Frequency Range | 5805.25 MHz |
| Equipment Class | FDS - Part 15 Field Disturbance Sensor |
| Device Description | Microwave Sensor |
| Responsible Party | Shihai Xu, HJ@LEXING.COM , 86-574-65325018 |
| Technical Contact | Mark Koop, Teleconformity, mark.koop@teleconformity.com  , (31)848395867 |
| Test Firm | Chris Du, Dongguan Precise Testing Service Co., Ltd., chris.du@pts-testing.com  , 86-769-8928-2919 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the End-­user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0rfLdy1Rc1DrUvPs5cTBtg== | 2016-07-28 | Original Equipment |
Grants
TCB Grant - Application 0rfLdy1Rc1DrUvPs5cTBtg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 07/28/2016 Application Dated: 07/28/2016 |
| Ningbo Pdlux Electronic Technology CO.,LTD. |
| 17F, Commerce building of Ningbo, No 588, |
| south Tiantong road,yinzhou district |
| Ningbo, 315000 China |
| Attention: Shihai Xu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIWW-PD-V5 |
| Name of Grantee: | Ningbo Pdlux Electronic Technology CO.,LTD. |
| Equipment Class: | Part 15 Field Disturbance Sensor |
| Notes: | Microwave Sensor |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15.245 | 5805.25 - 5805.25 |
| Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the End-user has no manual instructions to remove or install the device. |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
EAS Grant - Application 0rfLdy1Rc1DrUvPs5cTBtg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ningbo Pdlux Electronic Technology CO.,LTD. 17F, Commerce building of Ningbo, No 588, south Tiantong road,yinzhou district Ningbo, 315000 China |
Date of Grant: 07/28/2016 Application Dated: 07/28/2016 |
| Attention: Shihai Xu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AIWW-PD-V5 |
| Name of Grantee: | Ningbo Pdlux Electronic Technology CO.,LTD. |
| Equipment Class: | Part 15 Field Disturbance Sensor |
| Notes: | Microwave Sensor |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15.245 | 5805.25 - 5805.25 |
| Limited Modular Approval. Installations are limited to those hosts described in the filing which provide the necessary voltage regulators. OEM integrators must be instructed to ensure that the End-user has no manual instructions to remove or install the device. |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
