OPTO3 VITOCONNECT OPTO3 Test Setup Photos - FCC ID 2AIZ9-OPTO3

FCC ID 2AIZ9-OPTO3

Test_Setup_Photos_ZigBee

VITOCONNECT OPTO3

by Viessmann Elektronik GmbH

Document preview loads when visible.

Document Details

FCC ID2AIZ9-OPTO3
Document ID7908517
Document TypeTest Setup Photos
DescriptionTest_Setup_Photos_ZigBee
Document TitleTR23-1-0051601T007a_A4-C02
ApplicantViessmann Elektronik GmbH
Equipment ClassVITOCONNECT OPTO3
Product CodeOPTO3
Application IDFSKmFcIous7B8IgYs3AOEw==
Application PurposeOriginal Equipment
Application Date2024-12-17
Frequency Range2405-2480 MHz
FRN0025711722
Test Firmcetecom advanced GmbH
Certified ByStefan Peuse
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2024-12-17
Available2024-12-17
Created2024-10-29
Modified2024-10-29
Pages6
File TypeAdobe Acrobat PDF
File Size618750
File SHA-256d31f4ec6052b6e0fb6970f7ba6a9d3efcace37ca964e7dea46e45286e7cd479d
PDF Metadata AuthorYPargan
PDF Metadata ProducerNuance PDF Create YPargan
FCC.gov SourcesFCC.gov 7908517
