YYSX6531 Mobile Phone Test Setup Photos - FCC ID 2AIZN-YYS-X6531

FCC ID 2AIZN-YYS-X6531

Test setup

Mobile Phone

by INFINIX MOBILITY LIMITED

Document preview loads when visible.

Document Details

FCC ID2AIZN-YYS-X6531
Document ID7545649
Document TypeTest Setup Photos
DescriptionTest setup
Document TitleHD 271 S1
ApplicantINFINIX MOBILITY LIMITED
Equipment ClassMobile Phone
Product CodeYYSX6531
Application IDAgOjUthn7vfyts+TFpieDQ==
Application PurposeOriginal Equipment
Application Date2024-08-08
Frequency Range1712.4-1752.6 MHz
FRN0025707605
Test FirmJianYan Testing Group Shenzhen Co., Ltd.
Certified ByBruce Zhang EMC Laboratory Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/04/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2024-08-07
Available2025-02-04
Created2024-08-05
Modified2024-08-05
Pages2
File TypeAdobe Acrobat PDF
File Size312686
File SHA-256d61b8d71d1c72d22bc6a5eddfc0d08f462e880d1afedc45d82150f836c2b3cb4
PDF Metadata AuthorLAB02
PDF Metadata ProducerLAB02 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 7545649
