TAGV1 ILT Tag Test Setup Photos - FCC ID 2AJ2A-TAGV1
FCC ID 2AJ2A-TAGV1
Test Setup Photographs
ILT Tag
Document preview loads when visible.
Document Details
| FCC ID | 2AJ2A-TAGV1 |
|---|---|
| Document ID | 4056111 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photographs |
| Document Title | Test Report No.: 2-___a/__ |
| Applicant | Intel Corporation |
| Equipment Class | ILT Tag |
| Product Code | TAGV1 |
| Application ID | Uzbtomf2YKZReRm1rdPC0A== |
| Application Purpose | Original Equipment |
| Application Date | 2018-11-02 |
| Frequency Range | 6234.6-6744.6 MHz |
| FRN | 0025953811 |
| Test Firm | CETECOM GmbH |
| Certified By | Dr. Andreas Gaede-Tsangas Product Regulatory Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/01/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-11-01 |
| Available | 2019-05-01 |
| Created | 2018-10-31 |
| Modified | 2018-10-31 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 1698572 |
| File SHA-256 | cf0ea0b5f8a39e218f349de20f19abe2a0bbd202f41b5c5c88748ba1bd1926da |
| PDF Metadata Author | Lorenz, Christian [CETECOM] |
| PDF Metadata Producer | Microsoft® Word 2016 Microsoft® Word 2016 |
| FCC.gov Sources | FCC.gov 4056111 |
