FCC ID 2AJDD-IDIAGSF7S
AUTO DIAGNOSTIC SYSTEM
by SHENZHEN FCAR TECHNOLOGY CO.,LTD
Grantee Code: 2AJDD Product Code: IDIAGSF7S
Latest application date: 2016-10-24
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-10-24 |
| 2402-2480 MHz | Original Equipment | 2016-10-24 |
| 2402-2480 MHz | Original Equipment | 2016-10-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-10-24 | PDF 2.3 MB |
| Internal photos | Internal Photos | 2016-10-24 | PDF 479.9 KB |
| External photos | External Photos | 2016-10-24 | PDF 244 KB |
| Label | ID Label/Location Info | 2016-10-24 | PDF 213.7 KB |
| Test setup | Test Setup Photos | 2016-10-24 | PDF 113.4 KB |
| Test setup | Test Setup Photos | 2016-10-24 | PDF 121.5 KB |
| Test report | Test Report | 2016-10-24 | PDF 4.1 MB |
| Test report | Test Report | 2016-10-24 | PDF 1.3 MB |
| Test report | Test Report | 2016-10-24 | PDF 1.8 MB |
| Test report | Test Report | 2016-10-24 | PDF 1.8 MB |
| Cover letter | Cover Letter(s) | 2016-10-24 | PDF 18 KB |
| SAR report part 1 | RF Exposure Info | 2016-10-24 | PDF 1.3 MB |
| SAR report part 2 | RF Exposure Info | 2016-10-24 | PDF 5 MB |
| SAR report part 3 | RF Exposure Info | 2016-10-24 | PDF 1.8 MB |
| SAR report part 4 | RF Exposure Info | 2016-10-24 | PDF 1.4 MB |
| SAR report part 5 | RF Exposure Info | 2016-10-24 | PDF 350.1 KB |
| SAR report part 6 | RF Exposure Info | 2016-10-24 | PDF 300.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 17.3 KB | |
| Schematics Metadata only | Schematics | PDF 439.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 116.1 KB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 213.3 KB |
Application Information
| Application ID | g6qlCHP1yZRkGfhktLFlQg== |
|---|---|
| Final Action Date | 2016-10-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025785775 |
| Model | IDIAGSF7S |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | AUTO DIAGNOSTIC SYSTEM |
| Responsible Party | Jun Hai Zhou, Engineer Manager, zhoujh@fcar.com  , +86-755-82904729 |
| Test Firm | Robinson Lo, Global United Technology Service Co., Ltd, robinson.lo@gtstest.com  , 86-755-27798480 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This device has 20 MHz, and 40 MHz bandwidth mode. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 0.60 W/kg and 0.67 W/kg, respectively. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
