FCC ID 2AJK7HT-1833611
2.4G WiFi video transmitter module
by Hi-Tech Optoelectronics Co.,Ltd.
Grantee Code: 2AJK7 Product Code: HT1833611
Latest application date: 2016-09-08
Device Images
FCC ID Device Details
| FCC ID | 2AJK7HT-1833611 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AJK7 |
| Product Code | HT1833611 |
| Applicant Business | Hi-Tech Optoelectronics Co.,Ltd. 🇨🇳 |
| Related Domains |  htoe.com.cn |
| Equipment Class | 2.4G WiFi video transmitter module |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-09-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_HT-1833611 UserMan, r1.pdf | Users Manual | 2016-09-08 | PDF 1.1 MB |
| 09_HT-1833611 IntPho.pdf | Internal Photos | 2016-09-08 | PDF 300.4 KB |
| 08_HT-1833611 ExtPho.pdf | External Photos | 2016-09-08 | PDF 300.4 KB |
| 06-07_HT-1833611 LabelSmpl-Loc.pdf | ID Label/Location Info | 2016-09-08 | PDF 264.5 KB |
| 17_HT-1833611 AntSpec, r1.pdf | Operational Description | 2016-09-08 | PDF 15.7 KB |
| 10_HT-1833611 TSup.pdf | Test Setup Photos | 2016-09-08 | PDF 184.8 KB |
| 14_HT-1833611 TestRpt.pdf | Test Report | 2016-09-08 | PDF 4.7 MB |
| 18_HT-1833611 RFExp.pdf | RF Exposure Info | 2016-09-08 | PDF 70.1 KB |
| 12_HT-1833611 BlkDia.pdf Metadata only | Block Diagram | PDF 9.6 KB | |
| 13_HT-1833611 Schem.pdf Metadata only | Schematics | PDF 79.5 KB | |
| 11_HT-1833611 OpDes.pdf Metadata only | Operational Description | PDF 227.6 KB | |
| 16_HT-1833611 PartsLst.pdf Metadata only | Parts List/Tune Up Info | PDF 192.2 KB |
Application Information
| Application ID | UX26BrdOV/J4eeQRlEnxIw== |
|---|---|
| Final Action Date | 2016-09-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025836834 |
| Model | HT-1833611 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 2.4G WiFi video transmitter module |
| Responsible Party | Charles Qin, qinbh@htoe.com.cn , 86-755-36889576 |
| Test Firm | Chris Du, Dongguan Precise Testing Service Co., Ltd., chris.du@pts-testing.com  , 86-769-8928-2919 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. Power listed is conducted. Limited Modular Approval (no RF shielding). This device supports 20MHz bandwidth operation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| UX26BrdOV/J4eeQRlEnxIw== | 2016-09-08 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0290000 | 15C |
Grants
TCB Grant - Application UX26BrdOV/J4eeQRlEnxIw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| Hi-Tech Optoelectronics Co.,Ltd. |
| Shahe Industrial Park, Changping District |
| Beijing, China |
| Attention: Charles Qin |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AJK7HT-1833611 |
| Name of Grantee: | Hi-Tech Optoelectronics Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4G WiFi video transmitter module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.029 |
| Power listed is conducted. Power listed is conducted. Limited Modular Approval (no RF shielding). This device supports 20MHz bandwidth operation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
EAS Grant - Application UX26BrdOV/J4eeQRlEnxIw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Hi-Tech Optoelectronics Co.,Ltd. Shahe Industrial Park, Changping District Beijing, China |
Date of Grant: 09/08/2016 Application Dated: 09/08/2016 |
| Attention: Charles Qin |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AJK7HT-1833611 |
| Name of Grantee: | Hi-Tech Optoelectronics Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4G WiFi video transmitter module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.029 |
| Power listed is conducted. Power listed is conducted. Limited Modular Approval (no RF shielding). This device supports 20MHz bandwidth operation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
| Mail To: |
