TP00143AL Notebook Computer Label Diagram - FCC ID 2AJN7-TP00143AL

FCC ID 2AJN7-TP00143AL

ID Label/Location Info

Notebook Computer

by LC Future Center

Document preview loads when visible.

Document Details

FCC ID2AJN7-TP00143AL
Document ID5832546
Document TypeID Label/Location Info
DescriptionID Label/Location Info
ApplicantLC Future Center
Equipment ClassNotebook Computer
Product CodeTP00143AL
Application IDyqIwgIcd2XzpctUyya6CwQ==
Application PurposeOriginal Equipment
Application Date2022-04-25
Frequency Range3555-3695 MHz
FRN0025849167
Test FirmBTL Inc.
Certified ByMelody Wu DOC Dept. Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2022-04-20
Available2022-04-25
Created2022-04-01
Modified2022-04-01
Pages3
File TypeAdobe Acrobat PDF
File Size3754430
File SHA-2565a4c6cc8392b5cd7acb6d4e059a48aa89aed34d86fdb03c0b668bedcb130a7a4
PDF Metadata ProducerAdobe Acrobat Pro 11.0.20 Adobe Acrobat Pro 11.0.20
FCC.gov SourcesFCC.gov 5832546, FCC.gov 5829405
