FCC ID 2AJVQ-ZDWFM2402
IEEE 802.11 b/g/n 2.4GHz 2T2R USB Module
by Qingdao Intelligent&Precise; Electronics Co.,Ltd
Grantee Code: 2AJVQ Product Code: ZDWFM2402
Latest application date: 2017-01-09
Device Images
FCC ID Device Details
| FCC ID | 2AJVQ-ZDWFM2402 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AJVQ |
| Product Code | ZDWFM2402 |
| Applicant Business | Qingdao Intelligent&Precise; Electronics Co.,Ltd 🇨🇳 |
| Related Domains |  hisense.com |
| Equipment Class | IEEE 802.11 b/g/n 2.4GHz 2T2R USB Module |
| Test Firm | Accurate Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-01-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-01-09 | PDF 312.4 KB |
| Internal Photos | Internal Photos | 2017-01-09 | PDF 171.5 KB |
| External Photos | External Photos | 2017-01-09 | PDF 243.8 KB |
| ID Label and Label Location | ID Label/Location Info | 2017-01-09 | PDF 126.8 KB |
| Test Setup Photos | Test Setup Photos | 2017-01-09 | PDF 403.3 KB |
| Test Report_DTS_Part 1 of 4 | Test Report | 2017-01-09 | PDF 5.2 MB |
| Test Report_DTS_Part 2 of 4 | Test Report | 2017-01-09 | PDF 5.4 MB |
| Test Report_DTS_Part 3 of 4 | Test Report | 2017-01-09 | PDF 3.3 MB |
| Test Report_DTS_Part 4 of 4 | Test Report | 2017-01-09 | PDF 2.7 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-01-09 | PDF 544.8 KB |
| Declaration Letter of non-US channel | Cover Letter(s) | 2017-01-09 | PDF 245.8 KB |
| Modular Approval Letter | Cover Letter(s) | 2017-01-09 | PDF 588 KB |
| RF Exposure Info | RF Exposure Info | 2017-01-09 | PDF 85.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 165.8 KB | |
| Schematics Diagram Metadata only | Schematics | PDF 83.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 105.9 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 29.3 KB |
Application Information
| Application ID | GjM5rg727TAjg9/5GSMl8A== |
|---|---|
| Final Action Date | 2017-01-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0025785783 |
| Model | ZDWFM2402 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | IEEE 802.11 b/g/n 2.4GHz 2T2R USB Module |
| Responsible Party | CaiFeng Li, Engineer, licaifeng@hisense.com , 53280879443 |
| Test Firm | Sean Liu, Accurate Technology Co., Ltd., sean@atc-lab.com  , 86-75526503291 |
| TCB Email | fcb@us.tuv.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. Modular Approval. This device is granted for use in mobile configuration only. Device is operating in 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM and OEM integrators. OEM integrators and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install this modular. This device has 20 MHz and 40 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| GjM5rg727TAjg9/5GSMl8A== | 2017-01-09 | Original Equipment |
Grants
TCB Grant - Application GjM5rg727TAjg9/5GSMl8A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV Rheinland of North America, Inc. 1279 Quarry Lane Suite A Pleasanton, CA 94566 |
Date of Grant: 01/09/2017 Application Dated: 01/05/2017 |
| Qingdao Intelligent&Precise Electronics Co.,Ltd |
| No218,Qianwangang Road |
| Qingdao Economic&Technological Development ZoneP.O. Box 266071, |
| Qingdao, 266071 China |
| Attention: CaiFeng Li , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AJVQ-ZDWFM2402 |
| Name of Grantee: | Qingdao Intelligent&Precise Electronics Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | IEEE 802.11 b/g/n 2.4GHz 2T2R USB Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.0417 |
| Power output listed is conducted. Modular Approval. This device is granted for use in mobile configuration only. Device is operating in 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM and OEM integrators. OEM integrators and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install this modular. This device has 20 MHz and 40 MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
