MWH414S WiFi Module Test Setup Photos - FCC ID 2AJVQ-MWH414S

FCC ID 2AJVQ-MWH414S

Test_Setup_Photos_RF

WiFi Module

by Qingdao Intelligent&Precise; Electronics Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2AJVQ-MWH414S
Document ID7863397
Document TypeTest Setup Photos
DescriptionTest_Setup_Photos_RF
Document Title国家三合一认可授权实验室
ApplicantQingdao Intelligent&Precise; Electronics Co.,Ltd
Equipment ClassWiFi Module
Product CodeMWH414S
Application IDIyn0N7X080I5c4nHN1O2wQ==
Application PurposeOriginal Equipment
Application Date2024-11-29
Frequency Range2412-2462 MHz
FRN0025785783
Test FirmBV 7Layers Communications Technology (Shenzhen) Co
Certified ByHaining Wang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2024-11-29
Available2024-11-29
Created2024-11-27
Modified2024-11-27
Pages4
File TypeAdobe Acrobat PDF
File Size643033
File SHA-2560c9c0ed26c35c09f5a43dbb7e47eb35d76ae2da2c4059bfa0abdc9dd5f42db9c
PDF Metadata Authorhuihui
PDF Metadata ProducerMicrosoft® Word 2019 huihui
FCC.gov SourcesFCC.gov 7863397
