8VC0004 LPWA Module Teardown Internal Photos - FCC ID 2AJYU-8VC0004
FCC ID 2AJYU-8VC0004
Internal Photos
LPWA Module
Document preview loads when visible.
Document Details
| FCC ID | 2AJYU-8VC0004 |
|---|---|
| Document ID | 6163470 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | SIMCom Wireless Solutions Limited |
| Equipment Class | LPWA Module |
| Product Code | 8VC0004 |
| Application ID | uHAGvtxfwxB1rmcH7JuSxQ== |
| Application Purpose | Original Equipment |
| Application Date | 2022-10-14 |
| Frequency Range | 1710-1755 MHz |
| FRN | 0025948449 |
| Test Firm | Chongqing Academy of Information and Communcations |
| Certified By | Yongsheng Li Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2022-10-13 |
| Available | 2022-10-14 |
| Created | 2022-09-15 |
| Modified | 2022-09-15 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 158166 |
| File SHA-256 | cb2824013cb46e19b0c2837bb2f3fef5d98301b980048c8a728519c4a3a025da |
| PDF Metadata Author | 李国庆 |
| PDF Metadata Producer | WPS 文字 |
| FCC.gov Sources | FCC.gov 6163470 |
