FCC ID 2AK4U-GC4BT-X81
BLE Module
by GREENCHIPS (HONGKONG) LIMITED
Grantee Code: 2AK4U Product Code: GC4BTX81
Latest application date: 2017-03-03
Device Images
FCC ID Device Details
| FCC ID | 2AK4U-GC4BT-X81 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AK4U |
| Product Code | GC4BTX81 |
| Applicant Business | GREENCHIPS (HONGKONG) LIMITED 🇨🇳 |
| Related Domains |  dycmcu.com |
| Equipment Class | BLE Module |
| Test Firm | TA Technology (Shanghai) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-03-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-03-03 | PDF 319.7 KB |
| Internal Photos | Internal Photos | 2017-03-03 | PDF 84.9 KB |
| External Photos | External Photos | 2017-03-03 | PDF 85.2 KB |
| Label Location | ID Label/Location Info | 2017-03-03 | PDF 88.7 KB |
| Test Setup Photos | Test Setup Photos | 2017-03-03 | PDF 436.6 KB |
| Test Report Part 15C | Test Report | 2017-03-03 | PDF 2 MB |
| Test Report with Host | Test Report | 2017-03-03 | PDF 1.5 MB |
| Confidentiality Request | Cover Letter(s) | 2017-03-03 | PDF 22.7 KB |
| Modular Approval Letter | Cover Letter(s) | 2017-03-03 | PDF 823.9 KB |
| POA | Cover Letter(s) | 2017-03-03 | PDF 337.9 KB |
| MPE Report | RF Exposure Info | 2017-03-03 | PDF 262.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 18.6 KB | |
| Circuit Schematics Metadata only | Schematics | PDF 61.5 KB | |
| BLE Module Technical Operational Description Metadata only | Operational Description | PDF 547.6 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 9.5 KB |
Application Information
| Application ID | gX8JAwJ4Eqf9C1IVuw/nXA== |
|---|---|
| Final Action Date | 2017-03-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026242883 |
| Model | GC4BT-X81 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | BLE Module |
| Responsible Party | Feng Zhang, feng.zhang@dycmcu.com , 0086-25-83306839 |
| Test Firm | Zhihui Liu, TA Technology (Shanghai) Co., Ltd., liuzhihui@ta-shanghai.com  , 86-21-50791141 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power listed is conducted. This module must not be incorporated into any other device or system without retesting for compliance as a composite system. This module was tested in standalone configuration and also when installed into a representative host (Host product name: Wrist electronic blood pressure monitor - Manufactured by Jiangsu Yuyue Medical Equipment & Supply Co., Ltd.). Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Approval is limited to OEM installation only. This module is restricted to installation in products for use only in mobile and fixed applications. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. OEM integrators must be provided with module installation instructions and labeling requirements for finished products. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| gX8JAwJ4Eqf9C1IVuw/nXA== | 2017-03-03 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0010000 | 15C |
Grants
TCB Grant - Application gX8JAwJ4Eqf9C1IVuw/nXA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/03/2017 Application Dated: 03/03/2017 |
| GREENCHIPS (HONGKONG) LIMITED |
| Room 1401,Tower A,Jingang mansion,251 Heyan Road, |
| Nanjing, China |
| Attention: Feng Zhang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AK4U-GC4BT-X81 |
| Name of Grantee: | GREENCHIPS (HONGKONG) LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | BLE Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.001 |
| Limited Single Modular Approval. Power listed is conducted. This module must not be incorporated into any other device or system without retesting for compliance as a composite system. This module was tested in standalone configuration and also when installed into a representative host (Host product name: Wrist electronic blood pressure monitor - Manufactured by Jiangsu Yuyue Medical Equipment & Supply Co., Ltd.). Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Approval is limited to OEM installation only. This module is restricted to installation in products for use only in mobile and fixed applications. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. OEM integrators must be provided with module installation instructions and labeling requirements for finished products. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
