FCC TEST REPORT
Report No: STS1807042W16
Issued for
Shanghai Unihertz E-Commerce Co., Ltd
Room 302, No. 5, Lane 59, Shennan Rd, Minhang district,
Shanghai, China 201108
Product Name:
Smart phone
Brand Name:
Unihertz
Model Name:
Atom
Series Model:
N/A
FCC ID:
Test Standard:
2AK6CATOM
FCC Part 15.407
Any reproduction of this document must be done in full. No single part of this document may be reproduced without
permission from STS, All Test Data Presented in this report is only applicable to presented Test sample.
Shenzhen STS Test Services Co., Ltd.
1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road,
Fuyong Street, Bao’an District, Shenzhen, Guangdong, China
TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:sts@stsapp.com
Page 2 of 55
Report No.: STS1807042W16
TEST RESULT CERTIFICATION
Applicant’s name ................. : Shanghai Unihertz E-Commerce Co., Ltd
Address ................................. : Room 302, No. 5, Lane 59, Shennan Rd, Minhang district,
Shanghai, China 201108
Manufacture's Name ............ : OBLUE Communication Technology Co.,Ltd.
Address ................................. : Room 406, Hivac Building,No. 2 North keji Rd,North Hi-Tech
Industry Park, Nanshan district, shenzhen, China 201108
Product description
Product Name ........................ : Smart phone
Brand Name ......................... : Unihertz
Model Name .......................... : Atom
Series Model .......................... : N/A
Test Standards ..................... : FCC Part15.407
C63.10-2013
Test procedure ...............................ANSI
This device described above has been tested by STS, the test results show that the equipment
under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested
sample identified in the report.
This report shall not be reproduced except in full, without the written approval of STS, this
document only be altered or revised by STS, personal only, and shall be noted in the revision of
the document.
Date of Test ............................................ :
Date (s) of performance of tests ............. :
25 July 2018~20 Aug. 2018
Date of Issue ........................................... :
20 Aug. 2018
Test Result ............................................... :
Pass
Testing Engineer
( Chris chen )
Technical Manager
( Sean she )
Authorized Signatory :
(Vita Li)
Page 3 of 55
Report No.: STS1807042W16
Table of Contents
1 . SUMMARY OF TEST RESULTS
Page
1.1 TEST FACTORY
1.2 MEASUREMENT UNCERTAINTY
2 . GENERAL INFORMATION
2.1 GENERAL DESCRIPTION OF EUT
2.2 DESCRIPTION OF TEST MODES
10
2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED
11
2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE)
12
2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS
13
3 . EMC EMISSION TEST
14
3.1 CONDUCTED EMISSION MEASUREMENT
14
3.2 RADIATED EMISSION AND ( BANDEDGE) MEASUREMENT
18
4. CONDUCTED SPURIOUS EMISSIONS AND BANDEDGE
40
4.1 APPLIED PROCEDURES / LIMIT
40
5. POWER SPECTRAL DENSITY TEST
42
5.1 APPLIED PROCEDURES / LIMIT
42
6. BANDWIDTH MEASUREMENT
44
6.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT
44
6.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT
45
6.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT
46
7. MAXIMUM CONDUCTED OUTPUT POWER
7.1 APPLIED PROCEDURES / LIMIT
8. AUTOMATICALLY DISCONTINUE TRANSMISSION
47
47
52
8.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION
52
8.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION
52
9. ANTENNA REQUIREMENT
53
9.1 STANDARD REQUIREMENT
53
9.2 EUT ANTENNA
53
APPENDIX - PHOTOS OF TEST SETUP
54
Page 4 of 55
Report No.: STS1807042W16
Revision History
Rev.
Issue Date
Report NO.
Effect Page
Contents
00
20 Aug. 2018
STS1807042W16
ALL
Initial Issue
Page 5 of 55
Report No.: STS1807042W16
1. SUMMARY OF TEST RESULTS
Test procedures according to the technical standards:
§ 15.407,KDB 789033 D02 General U-NII Test Procedures New Rules v02r01
FCC Part 15.407
FCC standard
Test Item
Results
15.207
AC Conducted Emission
PASS
§ 15.407 (2) (26 dB) / § 15.407 (e) (6 dB)/
§ 15.407 (a) (99%)
26dB/6dB &99% Bandwidth
PASS
15.407(a) (1).(2).(3).(4).(5)
15.407(b)& 15.209
15.407(b)7
Maximum Conducted
Output Power
Radiated Emission And
(bandedge Emissions)
Measurement
Conducted Emission And
(bandedge Emissions)
Measurement
PASS
PASS
PASS
15.407(a) (1).(2).(3).(4).(5)
Power Spectral Density
PASS
15.407(c)
Automatically Discontinue
Transmission
PASS
15.203/15.204
Antenna Requirement
PASS
NOTE:
(1)” N/A” denotes test is not applicable in this Test Report
(2)all tests are according to ANSI C63.10-2013
Page 6 of 55
Report No.: STS1807042W16
1.1 TEST FACTORY
Shenzhen STS Test Services Co., Ltd.
Add. : 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road,
Fuyong Street, Bao’an District, Shenzhen, Guangdong, China
CNAS Registration No.: L7649; FCC Registration No.: 625569
IC Registration No.: 12108A; A2LA Certificate No.: 4338.01;
1.2 MEASUREMENT UNCERTAINTY
The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a
standard uncertainty multiplied by a coverage factor of
k=2,providing a level of confidence of
approximately 95 %。
No.
Item
Uncertainty
Conducted Emission (9KHz-150KHz)
±2.88dB
Conducted Emission (150KHz-30MHz)
±2.67dB
RF power,conducted
±0.71dB
Spurious emissions,conducted
±0.63dB
All emissions,radiated(<1G) 30MHz-200MHz
±3.80dB
All emissions,radiated(<1G) 200MHz-1000MHz
±3.97dB
All emissions,radiated(>1G)
±3.03dB
Page 7 of 55
Report No.: STS1807042W16
2. GENERAL INFORMATION
2.1 GENERAL DESCRIPTION OF EUT
Product Name
Smart phone
Trade Name
Unihertz
Model Name
Atom
Series Model
N/A
Model Difference
N/A
The EUT is a Smart phone
IEEE 802.11a/ n (HT20) 5.180GHz-5.240GHz
IEEE 802.11n (HT40) 5.190GHz-5.230GHz
Operation
Frequency:
IEEE 802.11a/ n (HT20)5.260GHz-5.320GHz
IEEE 802.11n (HT40)5.270GHz-5.310GHz
IEEE 802.11a/ n (HT20)5.500GHz-5.700GHz
IEEE 802.11n (HT40)5.510GHz-5.670GHz
IEEE 802.11a/ n (HT20)5.745GHz-5.825GHz
IEEE 802.11a/ n (HT40)5.755GHz-5.795GHz
Product Description
Modulation Type:
802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM
802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM
Antenna
See Note 3
Designation:
Max.Output
11.45dBm
Power(Conducted):
Duty Cycle:
Test Channel
Adapter
Battery
Hardware version
number
Software version
number
Connecting I/O
>98%
More details of EUT technical specification, please refer to the User's
Manual.
Please refer to the Note 2.
Power supply and ADP(rating):
Input: AC100-240V, 300mA, 50/60Hz
Output: DC5V, 1500mA
Battery(rating):
Rated Voltage: 3.85V
Charge Limit: 4.4V
Capacity: 2000mAh
G35_V1.2
alps-mp-01.mp1
Please refer to the User's Manual
Port(s)
1Note:For a more detailed features description, please refer to the manufacturer’s specifications or the
. User's Manual.
Page 8 of 55
1.
Report No.: STS1807042W16
Operation Frequency of channel
5.180GHz-5.240GHz
5.500GHz-5.720GHz
Channel
Frequency
Channel
Frequency
36
5180
100
5500
38
5190
102
5510
40
5200
104
5520
42
5210
108
5540
44
5220
110
5550
46
5230
112
5560
48
5240
116
5580
118
5590
5.260GHz-5.320GHz
120
5600
Channel
Frequency
124
5620
52
5260
126
5630
54
5270
128
5640
56
5280
132
5660
58
5290
134
5670
60
5300
136
5680
62
5310
140
5700
64
5320
5.745GHz-5.825GHz
Channel
Frequency
149
5745
151
5755
153
5765
157
5785
159
5795
161
5805
165
5825
Note:
In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest
frequency, the middle frequency, and the highest frequency of channel were selected to
perform the test, and the selected channel see below:
Carrier Frequency Channel
5GHz:
For 802.11a/n (HT20)
Channel
Freq.(MHz)
Channel
Freq.(MHz)
36
40
48
5180
5200
5240
52
60
64
5260
5300
5320
Channel
Freq.(MHz)
Channel
Freq.(MHz)
100
116
140
5500
5580
5700
149
157
165
5745
5785
5825
For 802.11a/n (HT20)
Page 9 of 55
Report No.: STS1807042W16
For 802.11n (HT40)
Channel
Freq.(MHz)
Channel
Freq.(MHz)
38
46
5190
5230
54
62
5270
5310
Channel
Freq.(MHz)
Channel
Freq.(MHz)
102
110
134
5510
5550
5670
151
159
5755
5795
For 802.11n (HT40)
Ant.
Brand
Model Name
Ant Type
Connector
Unihertz
Atom
PIFA
Antenna
N/A
Gain (dBi)
Band 1: 1.07dBi
Band 2: 0.56dBi
Band 3: 2.48dBi
Band 4: 2.56dBi
NOTE
WLAN Ant.
Page 10 of 55
Report No.: STS1807042W16
2.2 DESCRIPTION OF TEST MODES
To investigate the maximum EMI emission characteristics generates from EUT, the test system
was pre-scanning tested base on the consideration of following EUT operation mode or test
configuration mode which possible have effect on EMI emission level. Each of these EUT
operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively.
Worst Mode
Description
Data Rate
Mode 1
TX IEEE 802.11a HT20 CH36&CH40&CH48
6 Mbps
Mode 2
TX IEEE 802.11a HT20 CH52&CH60&CH64
6 Mbps
Mode 3
TX IEEE 802.11a HT20 CH100&CH116&CH140
6 Mbps
Mode 4
TX IEEE 802.11a HT20 CH149&CH157&CH165
6 Mbps
Mode 5
TX IEEE 802.11n HT20 CH36&CH40&CH48
MCS 0
Mode 6
TX IEEE 802.11n HT20 CH52&CH60&CH64
MCS 0
Mode 7
TX IEEE 802.11n HT20 CH100&CH116&CH140
MCS 0
Mode 8
TX IEEE 802.11n HT20 CH149&CH157&CH165
MCS 0
Mode 9
TX IEEE 802.11n HT40 CH38&CH46
MCS 0
Mode 10
TX IEEE 802.11n HT40 CH54 &CH62
MCS 0
Mode 11
TX IEEE 802.11n HT40 CH102&CH110&CH134
MCS 0
Mode 12
TX IEEE 802.11n HT40 CH151&CH159
MCS 0
Note: (1) The measurements are performed at the highest, middle, lowest available channels.
(2) The measurements are performed at all Bit Rate of Transmitter, the worst data was
reported
(3) We have be tested for all avaiable U.S. voltage and frequencies(For 120V,50/60Hz
and 240V, 50/60Hz) for which the device is capable of operation.
AC Conducted Emission
Test Case
AC Conducted
Emission
Mode 13: Keeping TX + WLAN Link
Page 11 of 55
Report No.: STS1807042W16
2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED
Radiated Spurious EmissionTest
E-1
EUT
Conducted Emission Test
AC
Plug
E-2
Adapter
C-1
E-1
EUT
Page 12 of 55
Report No.: STS1807042W16
2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE)
The EUT has been tested as an independent unit together with other necessary accessories or
support units. The following support units or accessories were used to form a representative test
configuration during the tests.
Item
Equipment
Mfr/Brand
Model/Type No.
Series No.
Note
E-2
Adapter
Unihertz
HJ-0501500W2-US
N/A
N/A
Item
C-1
Shielded Type
USB Cable
shielded line
(Charging )
Ferrite Core
Length
Note
NO
100cm
N/A
Note:
(1)
(2)
(3)
The support equipment was authorized by Declaration of Confirmation.
For detachable type I/O cable should be specified the length in cm in『Length』column.
“YES” is means “shielded” “with core”; “NO” is means “unshielded” “without core”.
Page 13 of 55
Report No.: STS1807042W16
2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS
Radiation Test equipment
Kind of Equipment
Manufacturer
Type No.
Serial No.
Last calibration
Calibrated until
EMI Test Receiver
R&S
ESCI
102086
2017.10.15
2018.10.14
Bilog Antenna
TESEQ
CBL6111D
34678
2017.11.02
2018.11.01
Horn Antenna
Schwarzbeck
BBHA 9120D
9120D-1343
2017.10.27
2018.10.26
Horn Antenna
Schwarzbeck
BBHA 9170
9170-0741
2016.03.06
2019.03.03
PreAmplifier
Agilent
8449B
60538
2017.10.15
2018.10.14
ZHNAN
ZN3090C
16035
2018.03.11
2019.03.10
EM
R01
N/A
NCR
NCR
SCHWARZBECK
AK9515H
SN-96286/9628
NCR
NCR
R&S
ESW44
101535
2018.07.10
2019.07.09
Passive Loop
(9K--30MHz)
Low frequency
cable
High frequency
cable
EMI Test Receiver
Conduction Test equipment
Kind of Equipment
Manufacturer
Type No.
Serial No.
Last calibration Calibrated until
Test Receiver
R&S
ESCI
101427
2017.10.15
2018.10.14
LISN
R&S
ENV216
101242
2017.10.15
2018.10.14
Conduction Cable
EM
C01
N/A
2018.03.11
2019.03.10
Kind of Equipment
Manufacturer
Type No.
Serial No.
USB RF power sensor
DARE
RPR3006W
15I00041SNO03
2017.10.15
2018.10.14
Spectrum Analyzer
Agilent
N9020A
MY51110105
2018.03.08
2019.03.07
Signal Analyzer
Agilent
N9020A
MY49100060
2017.10.15
2018.10.14
RF Connected Test
Last calibration Calibrated until
Page 14 of 55
Report No.: STS1807042W16
3. EMC EMISSION TEST
3.1CONDUCTED EMISSION MEASUREMENT
3.1.1 POWER LINE CONDUCTED EMISSION Limits
FREQUENCY (MHz)
(Frequency Range 150KHz-30MHz)
Class B (dBuV)
Standard
Quasi-peak
Average
0.15 -0.5
66 - 56 *
56 - 46 *
CISPR
0.50 -5.0
56.00
46.00
CISPR
5.0 -30.0
60.00
50.00
CISPR
0.15 -0.5
66 - 56 *
56 - 46 *
FCC
0.50 -5.0
56.00
46.00
FCC
5.0 -30.0
60.00
50.00
FCC
Note:
(1) The tighter limit applies at the band edges.
(2) The limit of " * " marked band means the limitation decreases linearly with the
logarithm of the frequency in the range.
The following table is the setting of the receiver
Receiver Parameters
Attenuation
Start Frequency
Stop Frequency
IF Bandwidth
Setting
10 dB
0.15 MHz
30 MHz
9 kHz
Page 15 of 55
Report No.: STS1807042W16
3.1.2 TEST PROCEDURE
a. The EUT was placed 0.8 meters from the horizontal ground plane with EUT being connected
to the power mains through a line impedance stabilization network (LISN). All other support
equipments powered from additional LISN(s). The LISN provide 50 Ohm/ 50uH of coupling
impedance for the measuring instrument.
b. Interconnecting cables that hang closer than 40 cm to the ground plane shall be folded back
and forth in the center forming a bundle 30 to 40 cm long.
c. I/O cables that are not connected to a peripheral shall be bundled in the center. The end of the
cable may be terminated, if required, using the correct terminating impedance. The overall
length shall not exceed 1 m.
d. LISN at least 80 cm from nearest part of EUT chassis.
e. For the actual test configuration, please refer to the related Item –EUT Test Photos.
3.1.3 DEVIATION FROM TEST STANDARD
No deviation
3.1.4 TEST SETUP
Vertical Reference
Test Receiver
Ground Plane
40cm
EUT
80cm
LISN
Horizontal Reference
Ground Plane
Note: 1.Support units were connected to second LISN.
2.Both of LISNs (AMN) are 80 cm from EUT and at least 80
cm
from other units and other metal planes
support.
units.
3.1.5 EUT OPERATING CONDITIONS
The EUT was configured for testing in a typical fashion (as a customer would normally use it). The
EUT has been programmed to continuously transmit during test. This operating condition was
tested and used to collect the included data.
Page 16 of 55
Report No.: STS1807042W16
3.1.6 TEST RESULTS
Temperature:
Test Voltage:
26.7 ℃
AC 120V/60Hz
Test Mode:
Mode 13
Relative Humidity:
Phase:
65%
Frequency
Reading
Correct
Result
Limit
Margin
(MHz)
(dBuV)
Factor(dB)
(dBuV)
(dBuV)
(dB)
0.1540
50.49
9.79
60.28
65.78
-5.50
QP
0.1540
32.92
9.79
42.71
55.78
-13.07
AVG
0.2380
43.98
9.95
53.93
62.17
-8.24
QP
0.2380
27.13
9.95
37.08
52.17
-15.09
AVG
0.5580
37.96
9.97
47.93
56.00
-8.07
QP
0.5580
21.18
9.97
31.15
46.00
-14.85
AVG
1.2060
31.58
9.80
41.38
56.00
-14.62
QP
1.2060
15.91
9.80
25.71
46.00
-20.29
AVG
3.7820
32.19
9.83
42.02
56.00
-13.98
QP
3.7820
15.25
9.83
25.08
46.00
-20.92
AVG
12.0980
28.50
10.22
38.72
60.00
-21.28
QP
12.0980
13.32
10.22
23.54
50.00
-26.46
AVG
Remark:
1. All readings are Quasi-Peak and Average values.
2. Margin = Result (Result =Reading + Factor )–Limit
Remark
Page 17 of 55
Temperature:
Test Voltage
Test Mode
26.7 ℃
AC 120V/60Hz
Mode 13
Report No.: STS1807042W16
Relative Humidity: 65%
Phase:
Frequency
Reading
Correct
Result
Limit
Margin
(MHz)
(dBuV)
Factor(dB)
(dBuV)
(dBuV)
(dB)
0.1540
49.62
9.76
59.38
65.78
-6.40
QP
0.1540
31.80
9.76
41.56
55.78
-14.22
AVG
0.2340
44.61
10.01
54.62
62.31
-7.69
QP
0.2340
26.32
10.01
36.33
52.31
-15.98
AVG
0.5580
41.26
9.95
51.21
56.00
-4.79
QP
0.5580
28.55
9.95
38.50
46.00
-7.50
AVG
1.4860
33.05
9.83
42.88
56.00
-13.12
QP
1.4860
17.43
9.83
27.26
46.00
-18.74
AVG
3.8420
31.34
9.94
41.28
56.00
-14.72
QP
3.8420
14.29
9.94
24.23
46.00
-21.77
AVG
13.2940
29.87
10.02
39.89
60.00
-20.11
QP
13.2940
14.45
10.02
24.47
50.00
-25.53
AVG
Remark:
1. All readings are Quasi-Peak and Average values.
2. Margin = Result (Result =Reading + Factor )–Limit
Remark
Page 18 of 55
Report No.: STS1807042W16
3.2 RADIATED EMISSION AND ( BANDEDGE) MEASUREMENT
3.2.1 RADIATED EMISSION LIMITS (Frequency Range 9kHz-1000MHz)
In case the emission fall within the restricted band specified on 15.407(b)7& 15.205/209(a), then
the (a); limit in the table below has to be followed.
Frequencies
Field Strength
Measurement Distance
(MHz)
(micorvolts/meter)
(meters)
0.009~0.490
2400/F(KHz)
300
0.490~1.705
24000/F(KHz)
30
1.705~30.0
30
30
30~88
100
88~216
150
216~960
200
Above 960
500
LIMITS OF RADIATED EMISSION MEASUREMENT (Above 1000MHz)
FREQUENCY (MHz)
Class B (dBuV/m) (at 3M)
PEAK
AVERAGE
Above 1000
74
54
Notes:
(1) The limit for radiated test was performed according to FCC PART 15E.
(2) The tighter limit applies at the band edges.
(3) Emission level (dBuV/m)=20log Emission level (uV/m).
Spectrum Parameter
Setting
Attenuation
Auto
Detector
Peak
Start Frequency
1000 MHz(Peak/AV)
Stop Frequency
10th carrier harmonic(Peak/AV)
RB / VB (emission in restricted band)
For Band edge
Spectrum Parameter
1 MHz / 1 MHz, AV=1 MHz /3 MHz
Setting
Detector
Peak
RB / VB (emission in restricted band)
1 MHz / 1 MHz, AV=1 MHz /3 MHz
Page 19 of 55
Report No.: STS1807042W16
Receiver Parameter
Setting
Attenuation
Auto
Start ~ Stop Frequency
9kHz~90kHz / RB 200Hz for PK & AV
Start ~ Stop Frequency
90kHz~110kHz / RB 200Hz for QP
Start ~ Stop Frequency
110kHz~490kHz / RB 200Hz for PK & AV
Start ~ Stop Frequency
490kHz~30MHz / RB 9kHz for QP
Start ~ Stop Frequency
30MHz~1000MHz / RB 120kHz for QP
3.2.2 TEST PROCEDURE
a. The measuring distance of at 3 m shall be used for measurements at frequency 0.009MHz up
to 1GHz. For frequencies above 1GHz, any suitable measuring distance may be used.
b. The EUT was placed on the top of a rotating table 0.8 meters(above 1GHz is 1.5 m) above the
ground at a 3 meter anechoic chamber. The table was rotated 360 degrees to determine the
position of the highest radiation.
c. The height of the equipment shall be 0.8 m(above 1GHz is 1.5 m); the height of the test
antenna shall vary between 1 m to 4 m. Horizontal and vertical polarizations of the antenna
are set to make the measurement
d. The initial step in collecting conducted emission data is a spectrum analyzer peak detector
mode pre-scanning the measurement frequency range. Significant peaks are then marked and
then Quasi Peak detector mode re-measured.
e. If the Peak Mode measured value compliance with and lower than Quasi Peak Mode Limit, the
EUT shall be deemed to meet QP Limits and then no additional QP Mode measurement
performed.
f. For the actual test configuration, please refer to the related Item –EUT Test Photos.
Note:
Both horizontal and vertical antenna polarities were tested and performed test to three
orthogonal axis. The worst case emissions were reported
3.2.2 DEVIATION FROM TEST STANDARD
No deviation
Page 20 of 55
3.2.3 TEST SETUP
(A)Radiated Emission Test-Up Frequency Below 30MHz
(B)Radiated Emission Test-Up Frequency 30MHz~1GHz
(C)Radiated Emission Test-Up Frequency Above 1GHz
Report No.: STS1807042W16
Page 21 of 55
Report No.: STS1807042W16
3.2.4 EUT OPERATING CONDITIONS
The EUT tested system was configured as the statements of 2.4 Unless otherwise a special
operating condition is specified in the follows during the testing.
3.2.5 FIELD STRENGTH CALCULATION
The field strength is calculated by adding the Antenna Factor and Cable Factor and subtracting
the Amplifier Gain and Duty Cycle Correction Factor (if any) from the measured reading. The basic
equation with a sample calculation is as follows:
FS = RA + AF + CL - AG
Where
FS = Field Strength
CL = Cable Attenuation Factor (Cable Loss)
RA = Reading Amplitude
AG = Amplifier Gain
AF = Antenna Factor
For example
Frequency
FS
RA
AF
CL
AG
Factor
(MHz)
(dBμV/m)
(dBμV/m)
(dB)
(dB)
(dB)
(dB)
300
Factor=AF+CL-AG
40
58.1
12.2
1.6
31.9
-18.1
Page 22 of 55
Report No.: STS1807042W16
3.2.6 TEST RESULTS (Between 9KHz – 30 MHz)
Temperature: 24.8 ℃
Test Voltage : DC 3.85V from Battery
Test Mode : TX Mode
Relative Humidtity: 60%
Polarization :
--
Freq.
Reading
Limit
Margin
State
(MHz)
(dBuV/m)
(dBuV/m)
(dB)
P/F
--
--
--
--
PASS
--
--
--
--
PASS
Note:
The amplitude of spurious emissions which are attenuated by more than 20dB below the
permissible value has no need to be reported.
Distance extrapolation factor =40 log (specific distance/test distance)(dB);
Limit line = specific limits(dBuv) + distance extrapolation factor.
Page 23 of 55
Report No.: STS1807042W16
3.2.7 TEST RESULTS (Between 30MHz – 1GHz)
Relative
Humidity
Polarization
Temperature 24.8 ℃
Test Voltage DC 3.85V from Battery
Test Mode
Mode 1-12(Mode 5-6M worst mode)
60%
Horizontal
Frequency
Reading
Correct
Result
Limit
Margin
(MHz)
(dBuV)
Factor(dB/m)
(dBuV/m)
(dBuV/m)
(dB)
30.2110
34.00
-11.30
22.70
40.00
-17.30
QP
67.9128
46.54
-24.15
22.39
40.00
-17.61
QP
100.2286
41.92
-19.17
22.75
43.50
-20.75
QP
209.3130
45.67
-19.78
25.89
43.50
-17.61
QP
318.8170
37.14
-14.21
22.93
46.00
-23.07
QP
543.2740
31.61
-6.92
24.69
46.00
-21.31
QP
Remark:
1. Margin = Result (Result =Reading + Factor )–Limit
Remark
Page 24 of 55
Report No.: STS1807042W16
Relative
Humidity
Polarization
Temperature 24.8℃
Test Voltage DC 3.85V from Battery
Test Mode
Mode 1-12(Mode 5-6M worst mode)
60%
Vertical
Frequency
Reading
Correct
Result
Limit
Margin
(MHz)
(dBuV)
Factor(dB/m)
(dBuV/m)
(dBuV/m)
(dB)
48.5016
41.53
-20.71
20.82
40.00
-19.18
QP
68.6310
45.58
-24.14
21.44
40.00
-18.56
QP
100.2286
42.92
-19.17
23.75
43.50
-19.75
QP
198.5880
44.24
-20.19
24.05
43.50
-19.45
QP
752.7432
30.78
-3.57
27.21
46.00
-18.79
QP
916.0687
30.71
-1.71
29.00
46.00
-17.00
QP
Remark:
1. Margin = Result (Result =Reading + Factor )–Limit
Remark
Page 25 of 55
Report No.: STS1807042W16
3.2.8 TEST RESULTS (Above 1000 MHz)
Band I 5150-5250MHz
Band I(5.15-5.25) GHz
Frequency
Reading
Amplifier
Antenna
Corrected
Emission
Factor
Factor
Level
Loss
Limit
(MHz)
Margin
Detector
Comment
(dBuV/m)
(dBuV)
(dB)
(dB)
(dB/m)
(dB)
(dBμV/m)
(dB)
Low Channel (802.11n20/ 5180 MHz)
3257.41
43.78
44.70
6.70
28.20
-9.80
33.98
74.00
-40.02
PK
Vertical
3257.41
41.07
44.70
6.70
28.20
-9.80
31.27
54.00
-22.73
AV
Vertical
3262.55
44.70
44.70
6.70
28.20
-9.80
34.90
74.00
-39.10
PK
Horizontal
3262.55
41.77
44.70
6.70
28.20
-9.80
31.97
54.00
-22.03
AV
Horizontal
3998.93
38.93
44.20
7.90
29.70
-6.60
32.33
74.00
-41.67
PK
Vertical
3998.93
36.08
44.20
7.90
29.70
-6.60
29.48
54.00
-24.52
AV
Vertical
3981.69
38.79
44.20
7.90
29.70
-6.60
32.19
74.00
-41.81
PK
Horizontal
3981.69
36.38
44.20
7.90
29.70
-6.60
29.78
54.00
-24.22
AV
Horizontal
7225.27
37.45
43.50
11.40
35.50
3.40
40.85
74.00
-33.15
PK
Vertical
7225.27
33.53
43.50
11.40
35.50
3.40
36.93
54.00
-17.07
AV
Vertical
7219.09
37.26
43.50
11.40
35.50
3.40
40.66
74.00
-33.34
PK
Horizontal
7219.09
33.88
43.50
11.40
35.50
3.40
37.28
54.00
-16.72
AV
Horizontal
10360.03
39.31
44.50
13.80
38.80
8.10
47.41
74.00
-26.59
PK
Vertical
10360.03
37.06
44.50
13.80
38.80
8.10
45.16
54.00
-8.84
AV
Vertical
10360.02
39.34
44.50
13.80
38.80
8.10
47.44
74.00
-26.56
PK
Horizontal
10360.02
36.82
44.50
13.80
38.80
8.10
44.92
54.00
-9.08
AV
Horizontal
11018.74
32.84
43.60
14.30
39.50
10.20
43.04
74.00
-30.96
PK
Vertical
11018.74
30.13
43.60
14.30
39.50
10.20
40.33
54.00
-13.67
AV
Vertical
11017.81
32.94
43.60
14.30
39.50
10.20
43.14
74.00
-30.86
PK
Horizontal
11017.81
29.86
43.60
14.30
39.50
10.20
40.06
54.00
-13.94
AV
Horizontal
13286.74
31.62
42.60
15.90
38.90
12.20
43.82
74.00
-30.18
PK
Vertical
13286.74
28.93
42.60
15.90
38.90
12.20
41.13
54.00
-12.87
AV
Vertical
13287.69
31.78
42.60
15.90
38.90
12.20
43.98
74.00
-30.02
PK
Horizontal
13287.69
29.38
42.60
15.90
38.90
12.20
41.58
54.00
-12.42
AV
Horizontal
Page 26 of 55
Report No.: STS1807042W16
Mid Channel (802.11 n20/ 5200 MHz)
3251.87
44.26
44.70
6.70
28.20
-9.80
34.46
74.00
-39.54
PK
Vertical
3251.87
41.36
44.70
6.70
28.20
-9.80
31.56
54.00
-22.44
AV
Vertical
3248.00
44.65
44.70
6.70
28.20
-9.80
34.85
74.00
-39.15
PK
Horizontal
3248.00
41.85
44.70
6.70
28.20
-9.80
32.05
54.00
-21.95
AV
Horizontal
3993.48
39.19
44.20
7.90
29.70
-6.60
32.59
74.00
-41.41
PK
Vertical
3993.48
36.73
44.20
7.90
29.70
-6.60
30.13
54.00
-23.87
AV
Vertical
3996.10
38.81
44.20
7.90
29.70
-6.60
32.21
74.00
-41.79
PK
Horizontal
3996.10
36.95
44.20
7.90
29.70
-6.60
30.35
54.00
-23.65
AV
Horizontal
7220.89
36.54
43.50
11.40
35.50
3.40
39.94
74.00
-34.06
PK
Vertical
7220.89
34.19
43.50
11.40
35.50
3.40
37.59
54.00
-16.41
AV
Vertical
7231.12
37.66
43.50
11.40
35.50
3.40
41.06
74.00
-32.94
PK
Horizontal
7231.12
33.73
43.50
11.40
35.50
3.40
37.13
54.00
-16.87
AV
Horizontal
10399.96
39.70
44.50
13.80
38.80
8.10
47.80
74.00
-26.20
PK
Vertical
10399.96
36.98
44.50
13.80
38.80
8.10
45.08
54.00
-8.92
AV
Vertical
10400.30
39.24
44.50
13.80
38.80
8.10
47.34
74.00
-26.66
PK
Horizontal
10400.30
35.94
44.50
13.80
38.80
8.10
44.04
54.00
-9.96
AV
Horizontal
11033.44
34.03
43.60
14.30
39.50
10.20
44.23
74.00
-29.77
PK
Vertical
11033.44
30.16
43.60
14.30
39.50
10.20
40.36
54.00
-13.64
AV
Vertical
11023.66
33.62
43.60
14.30
39.50
10.20
43.82
74.00
-30.18
PK
Horizontal
11023.66
30.90
43.60
14.30
39.50
10.20
41.10
54.00
-12.90
AV
Horizontal
13286.67
32.56
42.60
15.90
38.90
12.20
44.76
74.00
-29.24
PK
Vertical
13286.67
28.87
42.60
15.90
38.90
12.20
41.07
54.00
-12.93
AV
Vertical
13285.47
31.75
42.60
15.90
38.90
12.20
43.95
74.00
-30.05
PK
Horizontal
13285.47
29.70
42.60
15.90
38.90
12.20
41.90
54.00
-12.10
AV
Horizontal
Page 27 of 55
Report No.: STS1807042W16
High Channel (802.11 n20/ 5240 MHz)
3255.68
43.99
44.70
6.70
28.20
-9.80
34.19
74.00
-39.81
PK
Vertical
3255.68
41.71
44.70
6.70
28.20
-9.80
31.91
54.00
-22.09
AV
Vertical
3256.59
45.10
44.70
6.70
28.20
-9.80
35.30
74.00
-38.70
PK
Horizontal
3256.59
42.07
44.70
6.70
28.20
-9.80
32.27
54.00
-21.73
AV
Horizontal
3992.62
39.55
44.20
7.90
29.70
-6.60
32.95
74.00
-41.05
PK
Vertical
3992.62
35.93
44.20
7.90
29.70
-6.60
29.33
54.00
-24.67
AV
Vertical
3980.67
39.65
44.20
7.90
29.70
-6.60
33.05
74.00
-40.95
PK
Horizontal
3980.67
36.69
44.20
7.90
29.70
-6.60
30.09
54.00
-23.91
AV
Horizontal
7220.57
37.73
43.50
11.40
35.50
3.40
41.13
74.00
-32.87
PK
Vertical
7220.57
34.38
43.50
11.40
35.50
3.40
37.78
54.00
-16.22
AV
Vertical
7227.35
36.46
43.50
11.40
35.50
3.40
39.86
74.00
-34.14
PK
Horizontal
7227.35
34.63
43.50
11.40
35.50
3.40
38.03
54.00
-15.97
AV
Horizontal
10480.21
39.12
44.50
13.80
38.80
8.10
47.22
74.00
-26.78
PK
Vertical
10480.21
37.06
44.50
13.80
38.80
8.10
45.16
54.00
-8.84
AV
Vertical
10479.95
39.15
44.50
13.80
38.80
8.10
47.25
74.00
-26.75
PK
Horizontal
10479.95
36.37
44.50
13.80
38.80
8.10
44.47
54.00
-9.53
AV
Horizontal
11019.68
33.19
43.60
14.30
39.50
10.20
43.39
74.00
-30.61
PK
Vertical
11019.68
29.94
43.60
14.30
39.50
10.20
40.14
54.00
-13.86
AV
Vertical
11017.56
33.53
43.60
14.30
39.50
10.20
43.73
74.00
-30.27
PK
Horizontal
11017.56
30.73
43.60
14.30
39.50
10.20
40.93
54.00
-13.07
AV
Horizontal
13286.74
31.87
42.60
15.90
38.90
12.20
44.07
74.00
-29.93
PK
Vertical
13286.74
29.61
42.60
15.90
38.90
12.20
41.81
54.00
-12.19
AV
Vertical
13284.78
32.27
42.60
15.90
38.90
12.20
44.47
74.00
-29.53
PK
Horizontal
13284.78
29.92
42.60
15.90
38.90
12.20
42.12
54.00
-11.88
AV
Horizontal
Remark:
1.Factor = Antenna Factor + Cable Loss – Pre-amplifier.
2. Scan with 802.11a,802.11n (HT-20),802.11n (HT-40), the worst case is 802.11n (HT-20).
3. The frequency emission of peak points that did not show above the forms are at least 20dB below
the limit, the frequency emission is mainly from the environment noise.
Page 28 of 55
Report No.: STS1807042W16
Band II 5250-5350MHz
Band II(5.25-5.35) GHz
Frequency
Reading
Amplifier
Antenna
Corrected
Emission
Factor
Factor
Level
Loss
Limit
(MHz)
Margin
Detector
Comment
(dBuV/m)
(dBuV)
(dB)
(dB)
(dB/m)
(dB)
(dBμV/m)
(dB)
Low Channel (802.11 n20/ 5260 MHz)
3248.53
44.98
44.70
6.70
28.20
-9.80
35.18
74.00
-38.82
PK
Vertical
3248.53
41.79
44.70
6.70
28.20
-9.80
31.99
54.00
-22.01
AV
Vertical
3253.75
45.05
44.70
6.70
28.20
-9.80
35.25
74.00
-38.75
PK
Horizontal
3253.75
42.22
44.70
6.70
28.20
-9.80
32.42
54.00
-21.58
AV
Horizontal
3982.58
38.64
44.20
7.90
29.70
-6.60
32.04
74.00
-41.96
PK
Vertical
3982.58
35.82
44.20
7.90
29.70
-6.60
29.22
54.00
-24.78
AV
Vertical
3984.94
39.69
44.20
7.90
29.70
-6.60
33.09
74.00
-40.91
PK
Horizontal
3984.94
36.02
44.20
7.90
29.70
-6.60
29.42
54.00
-24.58
AV
Horizontal
7229.51
36.47
43.50
11.40
35.50
3.40
39.87
74.00
-34.13
PK
Vertical
7229.51
34.15
43.50
11.40
35.50
3.40
37.55
54.00
-16.45
AV
Vertical
7232.59
36.90
43.50
11.40
35.50
3.40
40.30
74.00
-33.70
PK
Horizontal
7232.59
34.62
43.50
11.40
35.50
3.40
38.02
54.00
-15.98
AV
Horizontal
10520.21
39.85
44.50
13.90
38.80
8.20
48.05
74.00
-25.95
PK
Vertical
10520.21
35.75
44.50
13.90
38.80
8.20
43.95
54.00
-10.05
AV
Vertical
10520.12
38.80
44.50
13.90
38.80
8.20
47.00
74.00
-27.00
PK
Horizontal
10520.12
35.78
44.50
13.90
38.80
8.20
43.98
54.00
-10.02
AV
Horizontal
11034.36
32.88
43.60
14.30
39.50
10.20
43.08
74.00
-30.92
PK
Vertical
11034.36
29.69
43.60
14.30
39.50
10.20
39.89
54.00
-14.11
AV
Vertical
11029.21
32.80
43.60
14.30
39.50
10.20
43.00
74.00
-31.00
PK
Horizontal
11029.21
30.02
43.60
14.30
39.50
10.20
40.22
54.00
-13.78
AV
Horizontal
13283.30
32.63
42.60
15.90
38.90
12.20
44.83
74.00
-29.17
PK
Vertical
13283.30
29.17
42.60
15.90
38.90
12.20
41.37
54.00
-12.63
AV
Vertical
13284.27
32.73
42.60
15.90
38.90
12.20
44.93
74.00
-29.07
PK
Horizontal
13284.27
28.63
42.60
15.90
38.90
12.20
40.83
54.00
-13.17
AV
Horizontal
Page 29 of 55
Report No.: STS1807042W16
Mid Channel (802.11 n20/ 5300 MHz)
3259.96
43.93
44.70
6.70
28.20
-9.80
34.13
74.00
-39.87
PK
Vertical
3259.96
41.43
44.70
6.70
28.20
-9.80
31.63
54.00
-22.37
AV
Vertical
3257.30
44.55
44.70
6.70
28.20
-9.80
34.75
74.00
-39.25
PK
Horizontal
3257.30
41.15
44.70
6.70
28.20
-9.80
31.35
54.00
-22.65
AV
Horizontal
3984.54
39.27
44.20
7.90
29.70
-6.60
32.67
74.00
-41.33
PK
Vertical
3984.54
36.21
44.20
7.90
29.70
-6.60
29.61
54.00
-24.39
AV
Vertical
3995.27
39.49
44.20
7.90
29.70
-6.60
32.89
74.00
-41.11
PK
Horizontal
3995.27
37.05
44.20
7.90
29.70
-6.60
30.45
54.00
-23.55
AV
Horizontal
7224.51
37.51
43.50
11.40
35.50
3.40
40.91
74.00
-33.09
PK
Vertical
7224.51
34.41
43.50
11.40
35.50
3.40
37.81
54.00
-16.19
AV
Vertical
7220.16
37.62
43.50
11.40
35.50
3.40
41.02
74.00
-32.98
PK
Horizontal
7220.16
34.65
43.50
11.40
35.50
3.40
38.05
54.00
-15.95
AV
Horizontal
10600.31
39.65
44.50
13.80
38.80
8.10
47.75
74.00
-26.25
PK
Vertical
10600.31
35.92
44.50
13.80
38.80
8.10
44.02
54.00
-9.98
AV
Vertical
10600.42
39.96
44.50
13.80
38.80
8.10
48.06
74.00
-25.94
PK
Horizontal
10600.42
36.93
44.50
13.80
38.80
8.10
45.03
54.00
-8.97
AV
Horizontal
11017.53
33.45
43.60
14.30
39.50
10.20
43.65
74.00
-30.35
PK
Vertical
11017.53
30.06
43.60
14.30
39.50
10.20
40.26
54.00
-13.74
AV
Vertical
11034.95
33.89
43.60
14.30
39.50
10.20
44.09
74.00
-29.91
PK
Horizontal
11034.95
30.03
43.60
14.30
39.50
10.20
40.23
54.00
-13.77
AV
Horizontal
13292.38
32.45
42.60
15.90
38.90
12.20
44.65
74.00
-29.35
PK
Vertical
13292.38
29.79
42.60
15.90
38.90
12.20
41.99
54.00
-12.01
AV
Vertical
13288.30
32.58
42.60
15.90
38.90
12.20
44.78
74.00
-29.22
PK
Horizontal
Page 30 of 55
Report No.: STS1807042W16
High Channel (802.11 n20/ 5320 MHz)
3247.15
43.87
44.70
6.70
28.20
-9.80
34.07
74.00
-39.93
PK
Vertical
3247.15
41.05
44.70
6.70
28.20
-9.80
31.25
54.00
-22.75
AV
Vertical
3256.62
44.78
44.70
6.70
28.20
-9.80
34.98
74.00
-39.02
PK
Horizontal
3256.62
41.72
44.70
6.70
28.20
-9.80
31.92
54.00
-22.08
AV
Horizontal
3998.19
39.48
44.20
7.90
29.70
-6.60
32.88
74.00
-41.12
PK
Vertical
3998.19
37.14
44.20
7.90
29.70
-6.60
30.54
54.00
-23.46
AV
Vertical
3996.90
39.57
44.20
7.90
29.70
-6.60
32.97
74.00
-41.03
PK
Horizontal
3996.90
36.10
44.20
7.90
29.70
-6.60
29.50
54.00
-24.50
AV
Horizontal
7223.15
37.39
43.50
11.40
35.50
3.40
40.79
74.00
-33.21
PK
Vertical
7223.15
34.66
43.50
11.40
35.50
3.40
38.06
54.00
-15.94
AV
Vertical
7223.17
37.05
43.50
11.40
35.50
3.40
40.45
74.00
-33.55
PK
Horizontal
7223.17
34.47
43.50
11.40
35.50
3.40
37.87
54.00
-16.13
AV
Horizontal
10640.13
39.18
44.50
13.80
38.80
8.10
47.28
74.00
-26.72
PK
Vertical
10640.13
36.95
44.50
13.80
38.80
8.10
45.05
54.00
-8.95
AV
Vertical
10640.36
40.00
44.50
13.80
38.80
8.10
48.10
74.00
-25.90
PK
Horizontal
10640.36
36.34
44.50
13.80
38.80
8.10
44.44
54.00
-9.56
AV
Horizontal
11029.81
33.13
43.60
14.30
39.50
10.20
43.33
74.00
-30.67
PK
Vertical
11029.81
31.10
43.60
14.30
39.50
10.20
41.30
54.00
-12.70
AV
Vertical
11019.23
33.78
43.60
14.30
39.50
10.20
43.98
74.00
-30.02
PK
Horizontal
11019.23
30.46
43.60
14.30
39.50
10.20
40.66
54.00
-13.34
AV
Horizontal
13297.42
32.44
42.70
18.00
37.10
12.40
44.84
74.00
-29.16
PK
Vertical
13297.42
29.90
42.70
18.00
37.10
12.40
42.30
54.00
-11.70
AV
Vertical
13291.98
32.53
42.70
18.00
37.10
12.40
44.93
74.00
-29.07
PK
Horizontal
13291.98
28.62
42.70
18.00
37.10
12.40
41.02
54.00
-12.98
AV
Horizontal
Remark:
1.Factor = Antenna Factor + Cable Loss – Pre-amplifier.
2. Scan with 802.11a,802.11n (HT-20),802.11n (HT-40), the worst case is 802.11n (HT-20).
3. The frequency emission of peak points that did not show above the forms are at least 20dB below
the limit, the frequency emission is mainly from the environment noise.
Page 31 of 55
Report No.: STS1807042W16
Band III 5470-5725MHz
Band III(5.47-5.725) GHz
Frequency
Reading
Amplifier
Antenna
Corrected
Emission
Factor
Factor
Level
Loss
Limit
(MHz)
Margin
Detector
Comment
(dBuV/m)
(dBuV)
(dB)
(dB)
(dB/m)
(dB)
(dBμV/m)
(dB)
Low Channel (802.11 n20/ 5500 MHz)
3249.06
44.16
44.70
6.70
28.20
-9.80
34.36
74.00
-39.64
PK
Vertical
3249.06
41.24
44.70
6.70
28.20
-9.80
31.44
54.00
-22.56
AV
Vertical
3254.92
43.78
44.70
6.70
28.20
-9.80
33.98
74.00
-40.02
PK
Horizontal
3254.92
42.23
44.70
6.70
28.20
-9.80
32.43
54.00
-21.57
AV
Horizontal
3984.43
39.74
44.20
7.90
29.70
-6.60
33.14
74.00
-40.86
PK
Vertical
3984.43
35.90
44.20
7.90
29.70
-6.60
29.30
54.00
-24.70
AV
Vertical
3998.66
39.69
44.20
7.90
29.70
-6.60
33.09
74.00
-40.91
PK
Horizontal
3998.66
36.50
44.20
7.90
29.70
-6.60
29.90
54.00
-24.10
AV
Horizontal
7233.95
36.82
43.50
11.40
35.50
3.40
40.22
74.00
-33.78
PK
Vertical
7233.95
34.39
43.50
11.40
35.50
3.40
37.79
54.00
-16.21
AV
Vertical
7230.99
37.72
43.50
11.40
35.50
3.40
41.12
74.00
-32.88
PK
Horizontal
7230.99
34.12
43.50
11.40
35.50
3.40
37.52
54.00
-16.48
AV
Horizontal
10348.54
39.17
44.50
13.80
38.80
8.10
47.27
74.00
-26.73
PK
Vertical
10348.54
35.90
44.50
13.80
38.80
8.10
44.00
54.00
-10.00
AV
Vertical
10356.51
39.12
44.50
13.80
38.80
8.10
47.22
74.00
-26.78
PK
Horizontal
10356.51
36.38
44.50
13.80
38.80
8.10
44.48
54.00
-9.52
AV
Horizontal
11000.19
33.87
43.60
14.30
39.50
10.20
44.07
74.00
-29.93
PK
Vertical
11000.19
30.20
43.60
14.30
39.50
10.20
40.40
54.00
-13.60
AV
Vertical
11000.39
32.88
43.60
14.30
39.50
10.20
43.08
74.00
-30.92
PK
Horizontal
11000.39
30.75
43.60
14.30
39.50
10.20
40.95
54.00
-13.05
AV
Horizontal
13280.11
33.01
42.60
15.90
38.90
12.20
45.21
74.00
-28.79
PK
Vertical
13280.11
28.87
42.60
15.90
38.90
12.20
41.07
54.00
-12.93
AV
Vertical
13282.85
31.67
42.60
15.90
38.90
12.20
43.87
74.00
-30.13
PK
Horizontal
13282.85
28.87
42.60
15.90
38.90
12.20
41.07
54.00
-12.93
AV
Horizontal
Page 32 of 55
Report No.: STS1807042W16
Mid Channel (802.11 n20/ 5580 MHz)
3254.15
45.15
44.70
6.70
28.20
-9.80
35.35
74.00
-38.65
PK
Vertical
3254.15
41.27
44.70
6.70
28.20
-9.80
31.47
54.00
-22.53
AV
Vertical
3261.12
44.30
44.70
6.70
28.20
-9.80
34.50
74.00
-39.50
PK
Horizontal
3261.12
41.50
44.70
6.70
28.20
-9.80
31.70
54.00
-22.30
AV
Horizontal
3981.12
38.94
44.20
7.90
29.70
-6.60
32.34
74.00
-41.66
PK
Vertical
3981.12
37.08
44.20
7.90
29.70
-6.60
30.48
54.00
-23.52
AV
Vertical
3996.22
39.75
44.20
7.90
29.70
-6.60
33.15
74.00
-40.85
PK
Horizontal
3996.22
36.02
44.20
7.90
29.70
-6.60
29.42
54.00
-24.58
AV
Horizontal
7218.83
37.87
43.50
11.40
35.50
3.40
41.27
74.00
-32.73
PK
Vertical
7218.83
33.78
43.50
11.40
35.50
3.40
37.18
54.00
-16.82
AV
Vertical
7229.79
36.93
43.50
11.40
35.50
3.40
40.33
74.00
-33.67
PK
Horizontal
7229.79
34.90
43.50
11.40
35.50
3.40
38.30
54.00
-15.70
AV
Horizontal
10400.31
39.42
44.50
13.80
38.80
8.10
47.52
74.00
-26.48
PK
Vertical
10400.31
36.22
44.50
13.80
38.80
8.10
44.32
54.00
-9.68
AV
Vertical
10389.06
39.50
44.50
13.80
38.80
8.10
47.60
74.00
-26.40
PK
Horizontal
10389.06
37.14
44.50
13.80
38.80
8.10
45.24
54.00
-8.76
AV
Horizontal
11160.33
32.88
43.60
14.30
39.50
10.20
43.08
74.00
-30.92
PK
Vertical
11160.33
30.92
43.60
14.30
39.50
10.20
41.12
54.00
-12.88
AV
Vertical
11160.29
32.88
43.60
14.30
39.50
10.20
43.08
74.00
-30.92
PK
Horizontal
11160.29
31.02
43.60
14.30
39.50
10.20
41.22
54.00
-12.78
AV
Horizontal
13292.61
32.08
42.60
15.90
38.90
12.20
44.28
74.00
-29.72
PK
Vertical
13292.61
29.10
42.60
15.90
38.90
12.20
41.30
54.00
-12.70
AV
Vertical
13287.80
32.29
42.60
15.90
38.90
12.20
44.49
74.00
-29.51
PK
Horizontal
13287.80
28.56
42.60
15.90
38.90
12.20
40.76
54.00
-13.24
AV
Horizontal
Page 33 of 55
Report No.: STS1807042W16
High Channel (802.11 n20/ 5700 MHz)
3251.02
44.87
44.70
6.70
28.20
-9.80
35.07
74.00
-38.93
PK
Vertical
3251.02
42.12
44.70
6.70
28.20
-9.80
32.32
54.00
-21.68
AV
Vertical
3255.98
43.82
44.70
6.70
28.20
-9.80
34.02
74.00
-39.98
PK
Horizontal
3255.98
42.07
44.70
6.70
28.20
-9.80
32.27
54.00
-21.73
AV
Horizontal
3995.57
39.42
44.20
7.90
29.70
-6.60
32.82
74.00
-41.18
PK
Vertical
3995.57
36.99
44.20
7.90
29.70
-6.60
30.39
54.00
-23.61
AV
Vertical
3999.97
39.08
44.20
7.90
29.70
-6.60
32.48
74.00
-41.52
PK
Horizontal
3999.97
36.16
44.20
7.90
29.70
-6.60
29.56
54.00
-24.44
AV
Horizontal
7235.26
36.75
43.50
11.40
35.50
3.40
40.15
74.00
-33.85
PK
Vertical
7235.26
34.34
43.50
11.40
35.50
3.40
37.74
54.00
-16.26
AV
Vertical
7227.09
37.72
43.50
11.40
35.50
3.40
41.12
74.00
-32.88
PK
Horizontal
7227.09
34.88
43.50
11.40
35.50
3.40
38.28
54.00
-15.72
AV
Horizontal
10471.88
39.16
44.50
13.80
38.80
8.10
47.26
74.00
-26.74
PK
Vertical
10471.88
36.95
44.50
13.80
38.80
8.10
45.05
54.00
-8.95
AV
Vertical
10468.45
39.22
44.50
13.80
38.80
8.10
47.32
74.00
-26.68
PK
Horizontal
10468.45
36.82
44.50
13.80
38.80
8.10
44.92
54.00
-9.08
AV
Horizontal
11400.38
33.42
43.60
14.30
39.50
10.20
43.62
74.00
-30.38
PK
Vertical
11400.38
31.02
43.60
14.30
39.50
10.20
41.22
54.00
-12.78
AV
Vertical
11400.17
32.88
43.60
14.30
39.50
10.20
43.08
74.00
-30.92
PK
Horizontal
11400.17
29.89
43.60
14.30
39.50
10.20
40.09
54.00
-13.91
AV
Horizontal
13298.67
31.59
42.60
15.90
38.90
12.20
43.79
74.00
-30.21
PK
Vertical
13298.67
29.09
42.60
15.90
38.90
12.20
41.29
54.00
-12.71
AV
Vertical
13294.92
32.50
42.60
15.90
38.90
12.20
44.70
74.00
-29.30
PK
Horizontal
13294.92
28.91
42.60
15.90
38.90
12.20
41.11
54.00
-12.89
AV
Horizontal
Remark:
1.Factor = Antenna Factor + Cable Loss – Pre-amplifier.
2. Scan with 802.11a,802.11n (HT-20),802.11n (HT-40), the worst case is 802.11n (HT-20).
3. The frequency emission of peak points that did not show above the forms are at least 20dB below
the limit, the frequency emission is mainly from the environment noise.
Page 34 of 55
Report No.: STS1807042W16
Band IV(5.725-5.850) GHz
Band IV(5.725-5.85) GHz
Frequency
Reading
Amplifier
Antenna
Corrected
Emission
Factor
Factor
Level
Loss
Limit
(MHz)
Margin
Detector
Comment
(dBuV/m)
(dBuV)
(dB)
(dB)
(dB/m)
(dB)
(dBμV/m)
(dB)
Low Channel (802.11 a/ 5745 MHz)
3264.39
44.79
44.70
6.70
28.20
-9.80
34.99
74.00
-39.01
PK
Vertical
3264.39
41.14
44.70
6.70
28.20
-9.80
31.34
54.00
-22.66
AV
Vertical
3254.66
44.52
44.70
6.70
28.20
-9.80
34.72
74.00
-39.28
PK
Horizontal
3254.66
41.48
44.70
6.70
28.20
-9.80
31.68
54.00
-22.32
AV
Horizontal
3983.16
39.16
44.20
7.90
29.70
-6.60
32.56
74.00
-41.44
PK
Vertical
3983.16
36.46
44.20
7.90
29.70
-6.60
29.86
54.00
-24.14
AV
Vertical
3998.31
38.83
44.20
7.90
29.70
-6.60
32.23
74.00
-41.77
PK
Horizontal
3998.31
36.07
44.20
7.90
29.70
-6.60
29.47
54.00
-24.53
AV
Horizontal
7225.86
37.00
43.50
11.40
35.50
3.40
40.40
74.00
-33.60
PK
Vertical
7225.86
33.68
43.50
11.40
35.50
3.40
37.08
54.00
-16.92
AV
Vertical
7230.14
36.58
43.50
11.40
35.50
3.40
39.98
74.00
-34.02
PK
Horizontal
7230.14
34.87
43.50
11.40
35.50
3.40
38.27
54.00
-15.73
AV
Horizontal
10510.09
39.61
44.50
13.90
38.80
8.20
47.81
74.00
-26.19
PK
Vertical
10510.09
36.24
44.50
13.90
38.80
8.20
44.44
54.00
-9.56
AV
Vertical
10518.63
39.96
44.50
13.90
38.80
8.20
48.16
74.00
-25.84
PK
Horizontal
10518.63
36.47
44.50
13.90
38.80
8.20
44.67
54.00
-9.33
AV
Horizontal
11490.21
33.10
43.60
14.30
39.50
10.20
43.30
74.00
-30.70
PK
Vertical
11490.21
30.35
43.60
14.30
39.50
10.20
40.55
54.00
-13.45
AV
Vertical
11490.30
33.24
43.60
14.30
39.50
10.20
43.44
74.00
-30.56
PK
Horizontal
11490.30
29.83
43.60
14.30
39.50
10.20
40.03
54.00
-13.97
AV
Horizontal
13287.38
32.15
42.60
15.90
38.90
12.20
44.35
74.00
-29.65
PK
Vertical
13287.38
28.56
42.60
15.90
38.90
12.20
40.76
54.00
-13.24
AV
Vertical
13295.75
32.64
42.60
15.90
38.90
12.20
44.84
74.00
-29.16
PK
Horizontal
13295.75
29.16
42.60
15.90
38.90
12.20
41.36
54.00
-12.64
AV
Horizontal
Page 35 of 55
Report No.: STS1807042W16
Mid Channel (802.11 a/ 5785 MHz)
3259.33
44.47
44.70
6.70
28.20
-9.80
34.67
74.00
-39.33
PK
Vertical
3259.33
41.40
44.70
6.70
28.20
-9.80
31.60
54.00
-22.40
AV
Vertical
3249.68
45.06
44.70
6.70
28.20
-9.80
35.26
74.00
-38.74
PK
Horizontal
3249.68
42.23
44.70
6.70
28.20
-9.80
32.43
54.00
-21.57
AV
Horizontal
3990.18
39.90
44.20
7.90
29.70
-6.60
33.30
74.00
-40.70
PK
Vertical
3990.18
36.75
44.20
7.90
29.70
-6.60
30.15
54.00
-23.85
AV
Vertical
3990.67
38.92
44.20
7.90
29.70
-6.60
32.32
74.00
-41.68
PK
Horizontal
3990.67
36.13
44.20
7.90
29.70
-6.60
29.53
54.00
-24.47
AV
Horizontal
7236.17
37.56
43.50
11.40
35.50
3.40
40.96
74.00
-33.04
PK
Vertical
7236.17
33.58
43.50
11.40
35.50
3.40
36.98
54.00
-17.02
AV
Vertical
7227.25
37.39
43.50
11.40
35.50
3.40
40.79
74.00
-33.21
PK
Horizontal
7227.25
34.21
43.50
11.40
35.50
3.40
37.61
54.00
-16.39
AV
Horizontal
10584.55
40.00
44.50
13.80
38.80
8.10
48.10
74.00
-25.90
PK
Vertical
10584.55
37.12
44.50
13.80
38.80
8.10
45.22
54.00
-8.78
AV
Vertical
10586.23
39.56
44.50
13.80
38.80
8.10
47.66
74.00
-26.34
PK
Horizontal
10586.23
36.23
44.50
13.80
38.80
8.10
44.33
54.00
-9.67
AV
Horizontal
11570.36
33.97
43.60
14.30
39.50
10.20
44.17
74.00
-29.83
PK
Vertical
11570.36
30.06
43.60
14.30
39.50
10.20
40.26
54.00
-13.74
AV
Vertical
11570.38
32.93
43.60
14.30
39.50
10.20
43.13
74.00
-30.87
PK
Horizontal
11570.38
30.97
43.60
14.30
39.50
10.20
41.17
54.00
-12.83
AV
Horizontal
13280.43
32.19
42.60
15.90
38.90
12.20
44.39
74.00
-29.61
PK
Vertical
13280.43
28.84
42.60
15.90
38.90
12.20
41.04
54.00
-12.96
AV
Vertical
13290.78
32.15
42.60
15.90
38.90
12.20
44.35
74.00
-29.65
PK
Horizontal
13290.78
28.61
42.60
15.90
38.90
12.20
40.81
54.00
-13.19
AV
Horizontal
Page 36 of 55
Report No.: STS1807042W16
High Channel (802.11 a/ 5825 MHz)
3252.42
45.11
44.70
6.70
28.20
-9.80
35.31
74.00
-38.69
PK
Vertical
3252.42
41.19
44.70
6.70
28.20
-9.80
31.39
54.00
-22.61
AV
Vertical
3253.81
45.15
44.70
6.70
28.20
-9.80
35.35
74.00
-38.65
PK
Horizontal
3253.81
40.76
44.70
6.70
28.20
-9.80
30.96
54.00
-23.04
AV
Horizontal
3999.01
38.70
44.20
7.90
29.70
-6.60
32.10
74.00
-41.90
PK
Vertical
3999.01
35.72
44.20
7.90
29.70
-6.60
29.12
54.00
-24.88
AV
Vertical
3982.46
39.35
44.20
7.90
29.70
-6.60
32.75
74.00
-41.25
PK
Horizontal
3982.46
36.21
44.20
7.90
29.70
-6.60
29.61
54.00
-24.39
AV
Horizontal
7218.89
36.58
43.50
11.40
35.50
3.40
39.98
74.00
-34.02
PK
Vertical
7218.89
34.00
43.50
11.40
35.50
3.40
37.40
54.00
-16.60
AV
Vertical
7229.75
36.56
43.50
11.40
35.50
3.40
39.96
74.00
-34.04
PK
Horizontal
7229.75
34.79
43.50
11.40
35.50
3.40
38.19
54.00
-15.81
AV
Horizontal
10639.33
38.80
44.50
13.80
38.80
8.10
46.90
74.00
-27.10
PK
Vertical
10639.33
37.07
44.50
13.80
38.80
8.10
45.17
54.00
-8.83
AV
Vertical
10640.22
38.95
44.50
13.80
38.80
8.10
47.05
74.00
-26.95
PK
Horizontal
10640.22
36.16
44.50
13.80
38.80
8.10
44.26
54.00
-9.74
AV
Horizontal
11650.40
34.12
43.60
14.30
39.50
10.20
44.32
74.00
-29.68
PK
Vertical
11650.40
30.04
43.60
14.30
39.50
10.20
40.24
54.00
-13.76
AV
Vertical
11650.09
33.95
43.60
14.30
39.50
10.20
44.15
74.00
-29.85
PK
Horizontal
11650.09
30.71
43.60
14.30
39.50
10.20
40.91
54.00
-13.09
AV
Horizontal
13284.79
31.56
42.70
18.00
37.10
12.40
43.96
74.00
-30.04
PK
Vertical
13284.79
28.66
42.70
18.00
37.10
12.40
41.06
54.00
-12.94
AV
Vertical
13293.24
32.41
42.70
18.00
37.10
12.40
44.81
74.00
-29.19
PK
Horizontal
13293.24
29.25
42.70
18.00
37.10
12.40
41.65
54.00
-12.35
AV
Horizontal
Remark:
1.Factor = Antenna Factor + Cable Loss – Pre-amplifier.
2. Scan with 802.11a,802.11n (HT-20),802.11n (HT-40), the worst case is 802.11a.
3. The frequency emission of peak points that did not show above the forms are at least 20dB below
the limit, the frequency emission is mainly from the environment noise.
Page 37 of 55
Report No.: STS1807042W16
3.2.9 Band Edge
Band I&II(5.15-5.35)GHz
Band I&II(5.15-5.35)GHz
Meter
Frequency
Amplifier
Reading
(MHz)
(dBμV)
(dB)
Antenna
Corrected
Emission
Factor
Factor
Level
(dB/m)
(dB)
(dBμV/m)
Loss
(dB)
Limits
Margin
Detector
Comment
(dBμV/m)
(dB)
Type
802.11a BW20MHz
5150
41.43
44.20
8.98
31.60
-3.62
37.81
74
5150
Peak
Vertical
5150
28.98
44.20
8.98
31.60
-3.62
25.36
54
5150
AVG
Vertical
5150
42.15
44.20
8.98
31.60
-3.62
38.53
74
5150
Peak
Horizontal
5150
30.69
44.20
8.98
31.60
-3.62
27.07
54
5150
AVG
Horizontal
5350
46.05
44.20
9.35
31.60
-3.25
42.80
74
5350
Peak
Vertical
5350
28.92
44.20
9.35
31.60
-3.25
25.67
54
5350
AVG
Vertical
5350
38.84
44.20
9.35
31.60
-3.25
35.59
74
5350
Peak
Horizontal
5350
28.15
44.20
9.35
31.60
-3.25
24.90
54
5350
AVG
Horizontal
802.11n BW20MHz
5150
40.49
44.20
8.98
31.60
-3.62
36.87
74
-37.13
Peak
Vertical
5150
28.40
44.20
8.98
31.60
-3.62
24.78
54
-29.22
AVG
Vertical
5150
42.16
44.20
8.98
31.60
-3.62
38.54
74
-35.46
Peak
Horizontal
5150
30.59
44.20
8.98
31.60
-3.62
26.97
54
-27.03
AVG
Horizontal
5350
44.98
44.20
9.35
31.60
-3.25
41.73
74
-32.27
Peak
Vertical
5350
29.34
44.20
9.35
31.60
-3.25
26.09
54
-27.91
AVG
Vertical
5350
38.48
44.20
9.35
31.60
-3.25
35.23
74
-38.77
Peak
Horizontal
5350
30.51
44.20
9.35
31.60
-3.25
27.26
54
-26.74
AVG
Horizontal
802.11n BW40MHz
5150
39.47
44.20
8.98
31.60
-3.62
35.85
74
-38.15
Peak
Vertical
5150
31.24
44.20
8.98
31.60
-3.62
27.62
54
-26.38
AVG
Vertical
5150
38.54
44.20
8.98
31.60
-3.62
34.92
74
-39.08
Peak
Horizontal
5150
29.09
44.20
8.98
31.60
-3.62
25.47
54
-28.53
AVG
Horizontal
5350
42.59
44.20
9.35
31.60
-3.25
39.34
74
-34.66
Peak
Vertical
5350
27.60
44.20
9.35
31.60
-3.25
24.35
54
-29.65
AVG
Vertical
5350
40.95
44.20
9.35
31.60
-3.25
37.70
74
-36.30
Peak
Horizontal
5350
28.28
44.20
9.35
31.60
-3.25
25.03
54
-28.97
AVG
Horizontal
Page 38 of 55
Report No.: STS1807042W16
Band III 5470-5725MHz
Band III(5.47-5.725 GHz)
Meter
Frequency
Amplifier
Reading
(MHz)
(dBμV)
(dB)
Antenna
Corrected
Emission
Factor
Factor
Level
(dB/m)
(dB)
(dBμV/m)
Loss
(dB)
Limits
Margin
Detector
(dBμV/m)
(dB)
Type
Comment
802.11a BW20MHz
5470
40.45
44.20
9.67
32.00
-2.53
37.92
74
-36.08
Peak
Vertical
5470
28.97
44.20
9.67
32.00
-2.53
26.44
54
-27.56
AVG
Vertical
5470
41.97
44.20
9.67
32.00
-2.53
39.44
74
-34.56
Peak
Horizontal
5470
30.27
44.20
9.67
32.00
-2.53
27.74
54
-26.26
AVG
Horizontal
5725
46.49
44.20
10.00
32.00
-2.20
44.29
74
-29.71
Peak
Vertical
5725
31.71
44.20
10.00
32.00
-2.20
29.51
54
-24.49
AVG
Vertical
5725
41.65
44.20
10.00
32.00
-2.20
39.45
74
-34.55
Peak
Horizontal
5725
29.26
44.20
10.00
32.00
-2.20
27.06
54
-26.94
AVG
Horizontal
802.11n BW20MHz
5470
38.60
44.20
9.67
32.00
-2.53
36.07
74
-37.93
Peak
Vertical
5470
27.44
44.20
9.67
32.00
-2.53
24.91
54
-29.09
AVG
Vertical
5470
41.37
44.20
9.67
32.00
-2.53
38.84
74
-35.16
Peak
Horizontal
5470
28.45
44.20
9.67
32.00
-2.53
25.92
54
-28.08
AVG
Horizontal
5725
43.61
44.20
10.00
32.00
-2.20
41.41
74
-32.59
Peak
Vertical
5725
29.61
44.20
10.00
32.00
-2.20
27.41
54
-26.59
AVG
Vertical
5725
41.02
44.20
10.00
32.00
-2.20
38.82
74
-35.18
Peak
Horizontal
5725
27.99
44.20
10.00
32.00
-2.20
25.79
54
-28.21
AVG
Horizontal
802.11n BW40MHz
5470
38.56
44.20
9.67
32.00
-2.53
36.03
74
-37.97
Peak
Vertical
5470
30.11
44.20
9.67
32.00
-2.53
27.58
54
-26.42
AVG
Vertical
5470
38.06
44.20
9.67
32.00
-2.53
35.53
74
-38.47
Peak
Horizontal
5470
30.12
44.20
9.67
32.00
-2.53
27.59
54
-26.41
AVG
Horizontal
5725
45.92
44.20
10.00
32.00
-2.20
43.72
74
-30.28
Peak
Vertical
5725
28.06
44.20
10.00
32.00
-2.20
25.86
54
-28.14
AVG
Vertical
5725
38.69
44.20
10.00
32.00
-2.20
36.49
74
-37.51
Peak
Horizontal
5725
30.38
44.20
10.00
32.00
-2.20
28.18
54
-25.82
AVG
Horizontal
Page 39 of 55
Report No.: STS1807042W16
Band IV(5.725-5.85 GHz)
Band IV(5.725-5.85 GHz)
Meter
Frequency
Amplifier
Reading
(MHz)
(dBμV)
(dB)
Antenna
Corrected
Emission
Factor
Factor
Level
(dB/m)
(dB)
(dBμV/m)
Loss
(dB)
Limits
Margin
Detector
(dBμV/m)
(dB)
Type
Comment
802.11a BW20MHz
5725
40.56
44.20
10.00
32.00
-2.20
38.36
74
-35.64
Peak
Vertical
5725
27.65
44.20
10.00
32.00
-2.20
25.45
54
-28.55
AVG
Vertical
5725
40.30
44.20
10.00
32.00
-2.20
38.10
74
-35.90
Peak
Horizontal
5725
28.71
44.20
10.00
32.00
-2.20
26.51
54
-27.49
AVG
Horizontal
5850
44.15
44.20
10.20
32.00
-2.00
42.15
74
-31.85
Peak
Vertical
5850
28.79
44.20
10.20
32.00
-2.00
26.79
54
-27.21
AVG
Vertical
5850
39.66
44.20
10.20
32.00
-2.00
37.66
74
-36.34
Peak
Horizontal
5850
29.47
44.20
10.20
32.00
-2.00
27.47
54
-26.53
AVG
Horizontal
802.11n BW20MHz
5725
41.16
44.20
10.00
32.00
-2.20
38.96
74
-35.04
Peak
Vertical
5725
28.32
44.20
10.00
32.00
-2.20
26.12
54
-27.88
AVG
Vertical
5725
37.92
44.20
10.00
32.00
-2.20
35.72
74
-38.28
Peak
Horizontal
5725
28.98
44.20
10.00
32.00
-2.20
26.78
54
-27.22
AVG
Horizontal
5850
46.00
44.20
10.20
32.00
-2.00
44.00
74
-30.00
Peak
Vertical
5850
31.26
44.20
10.20
32.00
-2.00
29.26
54
-24.74
AVG
Vertical
5850
39.31
44.20
10.20
32.00
-2.00
37.31
74
-36.69
Peak
Horizontal
5850
29.37
44.20
10.20
32.00
-2.00
27.37
54
-26.63
AVG
Horizontal
802.11n BW40MHz
5725
41.80
44.20
10.00
32.00
-2.20
39.60
74
-34.40
Peak
Vertical
5725
27.57
44.20
10.00
32.00
-2.20
25.37
54
-28.63
AVG
Vertical
5725
38.75
44.20
10.00
32.00
-2.20
36.55
74
-37.45
Peak
Horizontal
5725
31.00
44.20
10.00
32.00
-2.20
28.80
54
-25.20
AVG
Horizontal
5850
44.45
44.20
10.20
32.00
-2.00
42.45
74
-31.55
Peak
Vertical
5850
28.90
44.20
10.20
32.00
-2.00
26.90
54
-27.10
AVG
Vertical
5850
38.89
44.20
10.20
32.00
-2.00
36.89
74
-37.11
Peak
Horizontal
5850
28.38
44.20
10.20
32.00
-2.00
26.38
54
-27.62
AVG
Horizontal
Page 40 of 55
Report No.: STS1807042W16
4. CONDUCTED SPURIOUS EMISSIONS AND BANDEDGE
4.1 APPLIED PROCEDURES / LIMIT
Undesirable emission limits. Except as shown in paragraph (b)(7) of this section, the maximum
emissions outside of the frequency bands of operation shall be attenuated in accordance with the
following limits:
(1) For transmitters operating in the 5.15-5.25 GHz band: All emissions outside of the 5.15-5.35 GHz
band shall not exceed an e.i.r.p. of −27 dBm/MHz.
(2) For transmitters operating in the 5.25-5.35 GHz band: All emissions outside of the 5.15-5.35 GHz
band shall not exceed an e.i.r.p. of −27 dBm/MHz.
(3) For transmitters operating in the 5.47-5.725 GHz band: All emissions outside of the 5.47-5.725 GHz
band shall not exceed an e.i.r.p. of −27 dBm/MHz.
(4) For transmitters operating in the 5.725-5.85 GHz band:
(i) All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the
band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25
MHz above or below the band edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or
below the band edge, and from 5 MHz above or below the band edge increasing linearly to a level of
27 dBm/MHz at the band edge.
4.1.1 TEST PROCEDURE
Spectrum Parameter
Setting
Detector
Peak
Start/Stop Frequency
30 MHz to 10th carrier harmonic
RB / VB (emission in restricted band)
1000 KHz/3000 KHz
Trace-Mode:
Max hold
For Band edge
Spectrum Parameter
Detector
Start/Stop Frequency
Setting
Peak
Lower Band Edge: 5700 to 5725 MHz
Upper Band Edge: 5850 to 5870 MHz
RB / VB (emission in restricted band)
1000 KHz/3000 KHz
Trace-Mode:
Max hold
4.1.2 DEVIATION FROM STANDARD
No deviation.
Page 41 of 55
Report No.: STS1807042W16
4.1.3 TEST SETUP
The EUT which is powered by the Battery, is coupled to the Spectrum Analyzer; the RF load
attached to the EUT antenna terminal is 50Ohm; the path loss as the factor is calibrated to correct
the reading.
Make the measurement with the spectrum analyzer's resolution bandwidth (RBW) = 1000 kHz. In
order to make an accurate measurement, set the span greater than RBW.
4.1.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 2.3 Unless otherwise a special operating
condition is specified in the follows during the testing.
4.1.5 TEST RESULTS
Data See Appendix A
Page 42 of 55
Report No.: STS1807042W16
5. POWER SPECTRAL DENSITY TEST
5.1 APPLIED PROCEDURES / LIMIT
1. For mobile and portable client devices in the 5.15-5.25 GHz band, , the maximum power spectral
density shall not exceed 11 dBm in any 1 megahertz band. If transmitting antennas of directional
gain greater than 6 dBi are used, both the maximum conducted output power and the maximum
power spectral density shall be reduced by the amount in dB that the directional gain of the antenna
exceeds 6 dBi.
2. For the 5.25-5.35 GHz and 5.47-5.725 GHz bands, the maximum power spectral density shall not
exceed 11 dBm in any 1 megahertz band. If transmitting antennas of directional gain greater than 6
dBi are used, both the maximum conducted output power and the maximum power spectral density
shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi.
3.For the band 5.725-5.850 GHz, the peak power spectral density shall not exceed 30 dBm in
any 500KHz band. If transmitting antenna directional gain is greater than 6 dBi, both the maximum
conducted output power and the peak power spectral density shall be reduced by the amount in dB
that the directional gain of the antenna exceeds 6 dBi.
5.1.1 TEST PROCEDURE
1. The setting follows Method SA-1 of FCC KDB D02 General UNII Test Procedures New Rules
v01r03.
For devices operating in the band, the rules specify a measurement bandwidth of 500 kHz.
Many spectrum analyzers do not have 500 kHz RBW, thus a narrower RBW may need to be used.
The rules permit the use of a RBWs less than 1 MHz, or 500 kHz, “provided that the measured
power is integrated over the full reference bandwidth” to show the total power over the specified
measurement bandwidth (i.e., 1 MHz, or 500 kHz). If measurements are performed using a
reduced resolution bandwidth (< 1 MHz, or < 500 kHz) and integrated over 1 MHz, or 500 KHz
bandwidth, the following adjustments to the procedures apply:
a) Set RBW ≥ 1/T, where T is defined in section II.B.l.a).
b) Set VBW ≥ 3 RBW.
c) If measurement bandwidth of Maximum PSD is specified in 500 kHz, add 10 log (500kHz/RBW)
to the measured result, whereas RBW (< 500 kHz) is the reduced resolution bandwidth of the
spectrum analyzer set during measurement.
d) If measurement bandwidth of Maximum PSD is specified in 1 MHz, add 10 log (1MHz/RBW) to
the measured result, whereas RBW (< 1 MHz) is the reduced resolution bandwidth of spectrum
analyzer set during measurement.
e) Care must be taken to ensure that the measurements are performed during a period of
continuous transmission or are corrected upward for duty cycle.
Note: As a practical matter, it is recommended to use reduced RBW of 100 kHz for the
sections5.c) and 5.d) above, since RBW=100 KHZ is available on nearly all spectrum analyzers.
Page 43 of 55
Report No.: STS1807042W16
5.1.2 DEVIATION FROM STANDARD
No deviation.
5.1.3 TEST SETUP
5.1.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 2.1 Unless otherwise a special
operating condition is specified in the follows during the testing.
5.1.5 TEST RESULTS
Data see Appendix B
Page 44 of 55
Report No.: STS1807042W16
6. BANDWIDTH MEASUREMENT
6.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT
See list of measuring instruments of this test report.
6.1.1 TEST PROCEDURE
1. The testing follows FCC KDB 789033 D02 General UNII Test Procedures New Rules v02r01
2. Set RBW = approximately 1% of the emission bandwidth.
3. Set the VBW > =RBW.
4. Detector = Peak.
5. Trace mode = max hold.
6. Measure the maximum width of the emission that is 26 dB down from the peak of the emission.
Compare this with the RBW setting of the analyzer. Readjust RBW and repeat measurement
as needed until the RBW/EBW ratio is approximately 1%.
6.1.2 DEVIATION FROM STANDARD
No deviation.
6.1.3 TEST SETUP
6.1.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 2.4 Unless otherwise a special
operating condition is specified in the follows during the testing.
6.1.5 TEST RESULTS
Data see Appendix C
Page 45 of 55
Report No.: STS1807042W16
6.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT
The following procedure shall be used for measuring (99 %) power bandwidth:
6.2.1 TEST PROCEDURE
1. The testing follows FCC KDB 789033 D02 General UNII Test Procedures v02r01.
The following procedure shall be used for measuring (99 %) power bandwidth:
1. Set center frequency to the nominal EUT channel center frequency.
2. Set span = 1.5 times to 5.0 times the OBW.
3. Set RBW = 1 % to 5 % of the OBW
4. Set VBW ≥ 3 · RBW
5. Video averaging is not permitted. Where practical, a sample detection and single sweep mode
shall be used. Otherwise, peak detection and max hold mode (until the trace stabilizes) shall be
used.
6. Use the 99 % power bandwidth function of the instrument (if available).
7. If the instrument does not have a 99 % power bandwidth function, the trace data points are
recovered and directly summed in power units. The recovered amplitude data points, beginning at
the lowest frequency, are placed in a running sum until 0.5 % of the total is reached; that
frequency is recorded as the lower frequency. The process is repeated until 99.5 % of the total is
reached; that frequency is recorded as the upper frequency. The 99% occupied bandwidth is the
difference between these two frequencies.
6.2.2 DEVIATION FROM STANDARD
No deviation.
6.2.3 TEST SETUP
6.2.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 2.4 Unless otherwise a special
operating condition is specified in the follows during the testing.
6.2.5 TEST RESULTS
Data See Appendix C
Page 46 of 55
Report No.: STS1807042W16
6.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT
Section 15.407(e) specifies the minimum 6 dB emission bandwidth of at least 500 KHz for the band
5.725-5.85 GHz. The following procedure shall be used for measuring this bandwidth:
6.3.1 TEST PROCEDURE
1. The testing follows FCC KDB 789033 D02 General UNII Test Procedures v02r01.
a) Set RBW = 100 kHz.
b) Set the video bandwidth (VBW) ≥ 3 × RBW.
c) Detector = Peak.
d) Trace mode = max hold.
e) Sweep = auto couple.
f) Allow the trace to stabilize.
g) Measure the maximum width of the emission that is constrained by the frequencies associated
with the two outermost amplitude points (upper and lower frequencies) that are attenuated by 6 dB
relative to the maximum level measured in the fundamental emission.
6.3.2 DEVIATION FROM STANDARD
No deviation.
6.3.3 TEST SETUP
6.3.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 2.4 Unless otherwise a special
operating condition is specified in the follows during the testing.
6.3.5 TEST RESULTS
Data see Appendix D
Page 47 of 55
Report No.: STS1807042W16
7. MAXIMUM CONDUCTED OUTPUT POWER
7.1 APPLIED PROCEDURES / LIMIT
For mobile and portable client devices in the 5.15-5.25 GHz band, the maximum conducted output
power over the frequency band of operation shall not exceed 250 mW provided the maximum
antenna gain does not exceed 6 dBi. If transmitting antennas of directional gain greater than 6 dBi are
used, both the maximum conducted output power and the maximum power spectral density shall be
reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi.
For the 5.25-5.35 GHz and 5.47-5.725 GHz bands, the maximum conducted output power over the
frequency bands of operation shall not exceed the lesser of 250 mW or 11 dBm + 10 log B, where B is
the 26 dB emission bandwidth in megahertz,If transmitting antennas of directional gain greater than 6
dBi are used.
For the band 5.725-5.85 GHz, the maximum conducted output power over the frequency band of
operation shall not exceed 1 W. If transmitting antennas of directional gain greater than 6 dBi are
used.
FCC Part15 (15.407) , Subpart E
Section
Test Item
Limit
0.25 watt
The lesser of 250 mW
15.407(a) (1) (iv) Peak Output Power or 11 dBm + 10 log (26
dB emission bandwidth)
15.407(a) (3)
1 watt
Frequency Range
Result
(MHz)
5150-5250
5250-5350
5470-5725
PASS
5725-5825
7.1.1 TEST PROCEDURE
The EUT was directly connected to the Power Sensor&PC
7.1.2 DEVIATION FROM STANDARD
No deviation.
7.1.3 TEST SETUP
EUT
Spectrum Analyzer
7.1.4 EUT OPERATION CONDITIONS
The EUT tested system was configured as the statements of 5 Unless otherwise a special
operating condition is specified in the follows during the testing.
Page 48 of 55
Report No.: STS1807042W16
7.1.5 TEST RESULTS
Band I (5.15-5.25GHz)
Band I (5.15-5.25GHz)
Test Channel
Frequency (MHz)
PK Power
AV Power
(dBm)
(dBm)
LIMIT (dBm)
802.11a
36
5180
10.54
8.07
23.98
40
5200
10.91
9.02
23.98
48
5240
10.76
8.42
23.98
802.11n(HT20)
36
5180
11.12
9.13
23.98
40
5200
11.45
9.62
23.98
48
5240
11.08
9.29
23.98
802.11n(HT40)
38
5190
10.07
7.93
23.98
46
5230
9.34
7.22
23.98
Note:
1. For mobile and portable client devices in the 5.15-5.25 GHz band, the maximum conducted output power
over the frequency band of operation shall not exceed the lesser of 0.25 W.
Page 49 of 55
Report No.: STS1807042W16
Band II (5.25-5.35GHz)
Band II(5.25-5.35GHz)
Test Channel
Frequency (MHz)
PK Power
AV Power
(dBm)
(dBm)
LIMIT (dBm)
802.11a
52
5260
11.02
8.93
23.98
60
5300
10.56
8.21
23.98
64
5320
10.64
8.57
23.98
802.11n(HT20)
52
5260
11.34
9.78
23.98
60
5300
10.68
8.52
23.98
64
5320
10.91
9.14
23.98
802.11n(HT40)
54
5270
10.12
7.84
23.98
62
5310
9.46
7.56
23.98
Note:
1. For mobile and portable client devices in the 5.25-5.35 GHz band, the maximum conducted output power
over the frequency band of operation shall not exceed the lesser of 0.25 W.
Page 50 of 55
Report No.: STS1807042W16
Band III (5.47-5.725GHz)
Band9 III(5.47-5.725GHz)
Test Channel
Frequency (MHz)
PK Power
AV Power
(dBm)
(dBm)
LIMIT (dBm)
802.11a
100
5500
10.64
8.93
23.98
116
5580
9.72
7.42
23.98
140
5700
9.26
6.82
23.98
802.11n(HT20)
100
5500
10.67
8.71
23.98
116
5580
10.24
8.66
23.98
140
5700
9.37
7.26
23.98
802.11n(HT40)
102
5510
9.72
7.35
23.98
110
5550
9.15
7.04
23.98
134
5670
9.07
7.55
23.98
Note:
1. For mobile and portable client devices in the 5.47-5.725 GHz band, the maximum conducted output
power over the frequency band of operation shall not exceed the lesser of 0.25 W.
Page 51 of 55
Report No.: STS1807042W16
Band IV (5.725-5.85GHz)
Band IV (5.725-5.85GHz)
Test Channel
Frequency (MHz)
PK Power
AV Power
(dBm)
(dBm)
LIMIT (dBm)
802.11a
149
5745
9.72
7.37
30
157
5785
8.26
6.02
30
165
5825
8.81
6.87
30
802.11n(HT20)
149
5745
9.42
7.460
30
157
5785
8.37
6.140
30
165
5825
8.41
6.570
30
802.11n(HT40)
151
5755
8.24
6.360
30
159
5795
8.07
5.940
30
Note:
1. For the band 5.745-5.850 GHz, the maximum conducted output power over the frequency band of
operation shall not exceed the lesser of 1 W.
Page 52 of 55
Report No.: STS1807042W16
8. AUTOMATICALLY DISCONTINUE TRANSMISSION
8.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION
The device shall automatically discontinue transmission in case of either absence of information to
transmit or operational failure. These provisions are not intended to preclude the transmission of
control or signaling information or the use of repetitive codes used by certain digital technologies to
complete frame or burst intervals. Applicants shall include in their application for equipment
authorization to describe how this requirement is met.
8.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION
During no any information transmission, the EUT can automatically discontinue transmission and
become standby mode for power saving. The EUT can detect the controlling signal of ACK message
transmitting from remote device and verify whether it shall resend or discontinue transmission
Page 53 of 55
Report No.: STS1807042W16
9. ANTENNA REQUIREMENT
9.1 STANDARD REQUIREMENT
15.203 requirement: For intentional device, according to 15.203: an intentional radiator shall
be designed to ensure that no antenna other than that furnished by the responsible party
shall be used with the device.
9.2 EUT ANTENNA
The EUT antenna is PIFA Antenna. It comply with the standard requirement.
Page 54 of 55
APPENDIX - PHOTOS OF TEST SETUP
Radiated Measurement Photos
Report No.: STS1807042W16
Page 55 of 55
Report No.: STS1807042W16
Conducted Measurement Photos
※※※※※END OF THE REPORT※※※※※
Download: ATOM Smart Phone Test Report Measurement Report Shanghai Unihertz E-Commerce Co., Ltd
Mirror Download [FCC.gov]ATOM Smart Phone Test Report Measurement Report Shanghai Unihertz E-Commerce Co., Ltd
Document ID3989644
Application IDGJJunpNb/IqYW2UgbpaM6Q==
Document DescriptionTest Report - 5G
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize141.29kB (1766067 bits)
Date Submitted2018-09-04 00:00:00
Date Available2018-09-04 00:00:00
Creation Date2018-08-21 06:42:08
Producing SoftwareMicrosoft? Office Word 2007
Document Lastmod2018-08-21 06:42:08
Document TitleMeasurement Report
Document CreatorMicrosoft? Office Word 2007
Document Author: Kent

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.5
Linearized                      : No
Page Count                      : 55
Language                        : zh-CN
Tagged PDF                      : Yes
Title                           : Measurement Report
Author                          : Kent
Creator                         : Microsoft? Office Word 2007
Create Date                     : 2018:08:21 06:42:08+08:00
Modify Date                     : 2018:08:21 06:42:08+08:00
Producer                        : Microsoft? Office Word 2007
