FCC ID 2AK72REU2626
digital-analog convertor and power amplifier
by KATHREIN Solutions GmbH
Grantee Code: 2AK72 Product Code: REU2626
Latest application date: 2017-05-08
Device Images
FCC ID Device Details
| FCC ID | 2AK72REU2626 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AK72 |
| Product Code | REU2626 |
| Applicant Business | KATHREIN Solutions GmbH 🇩🇪 |
| Related Domains |  kathrein.de  sgs.com |
| Equipment Class | digital-analog convertor and power amplifier |
| Test Firm | SGS-CSTC Standards Technical Services Co.,Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 869-894 MHz | Original Equipment | 2017-05-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-05-08 | PDF 4.1 MB |
| Internal photos | Internal Photos | 2017-05-08 | PDF 1.1 MB |
| External photos | External Photos | 2017-05-08 | PDF 378.8 KB |
| Label | ID Label/Location Info | 2017-05-08 | PDF 251.3 KB |
| Label and Location | ID Label/Location Info | 2017-05-08 | PDF 313.1 KB |
| Set up photos | Test Setup Photos | 2017-05-08 | PDF 183.6 KB |
| Test Report | Test Report | 2017-05-08 | PDF 167.2 KB |
| Test Report Band 26 | Test Report | 2017-05-08 | PDF 4 MB |
| Attestation letter | Cover Letter(s) | 2017-05-08 | PDF 591.4 KB |
| Agent Authorization | Cover Letter(s) | 2017-05-08 | PDF 673.8 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-05-08 | PDF 492.8 KB |
| Block diagram Metadata only | Block Diagram | PDF 16.4 KB | |
| Block diagram FPGA Metadata only | Block Diagram | PDF 19.3 KB | |
| Schematics Digital board Metadata only | Schematics | PDF 948.9 KB | |
| Schematics Digital board parts Metadata only | Parts List/Tune Up Info | PDF 317.1 KB | |
| Schematics PA Metadata only | Schematics | PDF 752 KB | |
| Schematics PSU Metadata only | Schematics | PDF 326.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 2.5 MB | |
| Tuneup Procedure Letter Metadata only | Parts List/Tune Up Info | PDF 330.2 KB | |
| PA module parts Metadata only | Parts List/Tune Up Info | PDF 22.2 KB |
Application Information
| Application ID | cwaHha0ZV1bGGVsSHyMSOw== |
|---|---|
| Final Action Date | 2017-05-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026253872 |
| Model | REU2626 |
| Frequency Range | 869-894 MHz |
| Equipment Class | B2I - Part 20 Industrial Booster (CMRS) |
| Device Description | digital-analog convertor and power amplifier |
| Responsible Party | Veronika Shivaldova, veronika.shivaldova@kathrein.de , +49 08031 184-8366 |
| Agent | Jack Jack Jack, SGS-CSTS Standards Technical Services Co., Ltd, jack.zhang@sgs.com , 0755-2532-8506 |
| Technical Contact | Keny Xu, SGS-CSTS Standards Technical Services Co., keny.xu@sgs.com , 0755-2654 4119 |
| Non-Technical Contact | Sade Luo, SGS-CSTS Standards Technical Services Co., sade.luo@sgs.com , 0755-2532 8506 |
| Test Firm | June Zhang, SGS-CSTC Standards Technical Services Co.,Ltd., June.Zhang@sgs.com , 8675525328598 |
| TCB Email | uscts.tcb@sgs.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is conducted at the antenna terminal. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b) (3). |
