ACD02 Dongle Test Setup Photos - FCC ID 2AKDT-ACD02

FCC ID 2AKDT-ACD02

Test setup photo

Dongle

by XPPEN Technology CO.

Document preview loads when visible.

Document Details

FCC ID2AKDT-ACD02
Document ID5319505
Document TypeTest Setup Photos
DescriptionTest setup photo
Document TitleBL-SZ2140659-AR RF test setup photo V02
ApplicantXPPEN Technology CO.
Equipment ClassDongle
Product CodeACD02
Application ID82XKFFHtpARcrjSnbUT/Sg==
Application PurposeOriginal Equipment
Application Date2021-06-30
Frequency Range2402-2480 MHz
FRN0026040436
Test FirmShenzhen BALUN Technology Co., Ltd.
Certified ByXUEWEN WU
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/28/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2021-06-30
Available2021-12-28
Created2021-06-30
Modified2021-06-30
Pages4
File TypeAdobe Acrobat PDF
File Size748629
File SHA-2568fe181d6c971af22aa8ecbe88c2e5f5ed6d6f4bf82e99a9ac44efbb4adc46c0f
PDF Metadata Authordongmei.mo
PDF Metadata Producerdongmei.mo Acrobat Distiller 10.0.0 (Windows)
FCC.gov SourcesFCC.gov 5319505
