MX680 GSM/GPRS Module Label Diagram - FCC ID 2AKL7MX680
FCC ID 2AKL7MX680
06-07_MX680 LabelSmpl-Loc
GSM/GPRS Module
Document preview loads when visible.
Document Details
| FCC ID | 2AKL7MX680 |
|---|---|
| Document ID | 3236587 |
| Document Type | ID Label/Location Info |
| Description | 06-07_MX680 LabelSmpl-Loc |
| Document Title | ANNEX_Part 22H&24E&27 |
| Applicant | Shanghai ZhiWu Communication Technology Co.,Ltd |
| Equipment Class | GSM/GPRS Module |
| Product Code | MX680 |
| Application ID | Xs0QHBhP9QmRBojAs+l9CQ== |
| Application Purpose | Original Equipment |
| Application Date | 2016-12-21 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0026099390 |
| Test Firm | Shenzhen SEM.Test Technology Co., Ltd. |
| Certified By | Joerg Kusig Head of Certification |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-12-21 |
| Available | 2016-12-21 |
| Created | 2016-12-14 |
| Modified | 2016-12-14 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 123199 |
| File SHA-256 | 353e7fd8a41a555aa322d28f1a6c16e80afa48e6ec04e62ddc62d05a6871c1ed |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Administrator Acrobat Distiller 9.3.2 (Windows) |
| FCC.gov Sources | FCC.gov 3236587, FCC.gov 3236521 |
