01 Bluetooth Cassette Teardown Internal Photos - FCC ID 2AKQL01

FCC ID 2AKQL01

Internal photos

Bluetooth Cassette

by SHENZHEN RUIDA LIMITED

Document preview loads when visible.

Document Details

FCC ID2AKQL01
Document ID3282863
Document TypeInternal Photos
DescriptionInternal photos
Document TitleInternal photos
ApplicantSHENZHEN RUIDA LIMITED
Equipment ClassBluetooth Cassette
Product Code01
Application ID8ABcP6uw32Kn6OCu2gXiww==
Application PurposeOriginal Equipment
Application Date2017-02-15
Frequency Range2402-2480 MHz
FRN0026131375
Test FirmIntertek Testing Services Shenzhen Ltd.
Certified Bysky zhu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-02-14
Available2017-02-15
Created2017-02-07
Modified2017-02-07
Pages4
File TypeAdobe Acrobat PDF
File Size799959
File SHA-2564097b7a95a1db82722ee35a2eac723414cab213971c09a2339c819ecda2c449b
PDF Metadata Authorsky.zhu
PDF Metadata ProducerGPL Ghostscript 9.07 sky.zhu
FCC.gov SourcesFCC.gov 3282863
