MW1CDBT CAR AUDIO Teardown Internal Photos - FCC ID 2AKVT-MW-1CDBT

FCC ID 2AKVT-MW-1CDBT

Internal Photos

CAR AUDIO

by Music Wave Limited

Document preview loads when visible.

Document Details

FCC ID2AKVT-MW-1CDBT
Document ID3315198
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal Photos
ApplicantMusic Wave Limited
Equipment ClassCAR AUDIO
Product CodeMW1CDBT
Application IDiodBNsmUQYJjwc7CyFHM3w==
Application PurposeOriginal Equipment
Application Date2017-03-14
Frequency Range2402-2480 MHz
FRN0026161653
Test FirmEST Technology Co.,Ltd
Certified ByAmy Ng
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-03-14
Available2017-03-14
Created2017-01-20
Modified2017-01-20
Pages7
File TypeAdobe Acrobat PDF
File Size4017834
File SHA-256994ae4c39ecc2e9ba9397f4f4fb22a57d8d2a2604ddea0abde1cb4ed6127ac5f
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 3315198
