XO10013 Speaker Teardown Internal Photos - FCC ID 2ALCFXO-10013
FCC ID 2ALCFXO-10013
Internal Photos
Speaker
Document preview loads when visible.
Document Details
| FCC ID | 2ALCFXO-10013 |
|---|---|
| Document ID | 5113607 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal Photos |
| Applicant | Dongguan Xing Yue Electronic co., Ltd |
| Equipment Class | Speaker |
| Product Code | XO10013 |
| Application ID | pbaPVSEIYv/OJIDCRKRmKQ== |
| Application Purpose | Original Equipment |
| Application Date | 2021-02-06 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0026315127 |
| Test Firm | Shenzhen LCS Compliance Testing Laboratory Ltd. |
| Certified By | Sunny zhang manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-02-05 |
| Available | 2021-02-06 |
| Created | 2021-01-26 |
| Modified | 2021-02-04 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 437461 |
| File SHA-256 | 2cc9bacd0bf71a71bb988b49716548d793683aa84b01ae88bc25f38eeed94efa |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Acrobat Distiller 11.0 (Windows) Administrator |
| FCC.gov Sources | FCC.gov 5113607 |
