FCC ID 2ALEUM0E10XPX
Wi-Fi Module
by Zhejiang Mylinks intelligence Technology Co., Ltd.
Grantee Code: 2ALEU Product Code: M0E10XPX
Latest application date: 2017-04-17
Device Images
FCC ID Device Details
| FCC ID | 2ALEUM0E10XPX |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ALEU |
| Product Code | M0E10XPX |
| Applicant Business | Zhejiang Mylinks intelligence Technology Co., Ltd. 🇨🇳 |
| Related Domains |  mqlinks.com |
| Equipment Class | Wi-Fi Module |
| Test Firm | Waltek Services(Shenzhen) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-04-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-17 | PDF 868.9 KB |
| User Manual Host | Users Manual | 2017-04-17 | PDF 773.1 KB |
| Internal Photos | Internal Photos | 2017-04-17 | PDF 1.3 MB |
| External Photos | External Photos | 2017-04-17 | PDF 625 KB |
| Host Photos | External Photos | 2017-04-17 | PDF 1,006 KB |
| Label Sample and Label Sample | ID Label/Location Info | 2017-04-17 | PDF 434.8 KB |
| Schematics | Schematics | 2017-04-17 | PDF 58.5 KB |
| Operational Description | Operational Description | 2017-04-17 | PDF 156.5 KB |
| Test Setup Photos | Test Setup Photos | 2017-04-17 | PDF 430.4 KB |
| WiFi Test Report | Test Report | 2017-04-17 | PDF 1.6 MB |
| Confidential Request Letter | Cover Letter(s) | 2017-04-17 | PDF 34.4 KB |
| Limited Modular Approval letter | Cover Letter(s) | 2017-04-17 | PDF 41.6 KB |
| POA | Cover Letter(s) | 2017-04-17 | PDF 17.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 196 KB |
Application Information
| Application ID | ylZPgq2NhEUXJUXvCqSwzA== |
|---|---|
| Final Action Date | 2017-04-17 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026332726 |
| Model | M0E10XPX |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wi-Fi Module |
| Responsible Party | Xudong Shen, manager technology, shenxudong@mqlinks.com , (86) 573-82861005 |
| Test Firm | philo zhong, Waltek Services(Shenzhen) Co., Ltd., philo@waltek.com.cn  , 8675527553488 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This module must not be incorporated into any other device or system without retesting for compliance as a composite system. Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ylZPgq2NhEUXJUXvCqSwzA== | 2017-04-17 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0085900 | 15C |
Grants
TCB Grant - Application ylZPgq2NhEUXJUXvCqSwzA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 04/17/2017 Application Dated: 04/17/2017 |
| Zhejiang Mylinks intelligence Technology Co., Ltd. |
| 2410. Building 2, YaZhong Road, |
| Nanhu District, |
| Jiaxing City, Zhejiang Province,, 314000 China |
| Attention: Xudong Shen , manager technology |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALEUM0E10XPX |
| Name of Grantee: | Zhejiang Mylinks intelligence Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.00859 |
| Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This module must not be incorporated into any other device or system without retesting for compliance as a composite system. Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application ylZPgq2NhEUXJUXvCqSwzA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Zhejiang Mylinks intelligence Technology Co., Ltd. 2410. Building 2, YaZhong Road, Nanhu District, Jiaxing City, Zhejiang Province,, 314000 China |
Date of Grant: 04/17/2017 Application Dated: 04/17/2017 |
| Attention: Xudong Shen , manager technology |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALEUM0E10XPX |
| Name of Grantee: | Zhejiang Mylinks intelligence Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wi-Fi Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.00859 |
| Single Modular Approval. Power listed is conducted. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This module must not be incorporated into any other device or system without retesting for compliance as a composite system. Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
