FCC ID 2ALGQ-BTM835B
Bluetooth module
by Shenzhen Sky Jiarun Technology Co., Ltd
Grantee Code: 2ALGQ Product Code: BTM835B
Latest application date: 2017-05-16
Device Images
FCC ID Device Details
| FCC ID | 2ALGQ-BTM835B |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ALGQ |
| Product Code | BTM835B |
| Applicant Business | Shenzhen Sky Jiarun Technology Co., Ltd 🇨🇳 |
| Related Domains |  tianjiarun.com |
| Equipment Class | Bluetooth module |
| Test Firm | Shenzhen Tongce Testing Lab |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-05-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_BTM835-B UserMan r1 | Users Manual | 2017-05-16 | PDF 827.2 KB |
| 09_BTM835-B IntPho | Internal Photos | 2017-05-16 | PDF 384.4 KB |
| 08_BTM835-B ExtPho | External Photos | 2017-05-16 | PDF 384.4 KB |
| 06-07_BTM835-B LabelSmpl-Loc | ID Label/Location Info | 2017-05-16 | PDF 217.6 KB |
| 17_BTM835-B AntSpec r1 | Operational Description | 2017-05-16 | PDF 40.6 KB |
| 10_BTM835-B TSup | Test Setup Photos | 2017-05-16 | PDF 214.1 KB |
| 14_BTM835-B TestRpt r1 | Test Report | 2017-05-16 | PDF 3.7 MB |
| 18_BTM835-B RFExp | RF Exposure Info | 2017-05-16 | PDF 215.9 KB |
| 12_BTM835-B BlkDia Metadata only | Block Diagram | PDF 115.9 KB | |
| 13_BTM835-B Schem Metadata only | Schematics | PDF 271.1 KB | |
| 11_BTM835-B OpDes Metadata only | Operational Description | PDF 80.4 KB | |
| 16_BTM835-B PartsLst Metadata only | Parts List/Tune Up Info | PDF 43.4 KB |
Application Information
| Application ID | KXaUgOmS5czXyZZ4fZYWJw== |
|---|---|
| Final Action Date | 2017-05-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026277939 |
| Model | BTM835B |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Bluetooth module |
| Responsible Party | Triven Kung, triven.g@tianjiarun.com , 886-755-85279490 |
| Test Firm | Joe Zhou, Shenzhen Tongce Testing Lab, joe.zhou@tct-lab.com  , 860755-36638142 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for portable application with a minimum distance of 5mm to human bodies. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| KXaUgOmS5czXyZZ4fZYWJw== | 2017-05-16 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Rules |
|---|---|---|---|
| 2402-2480 MHz | 0.0022000 | ppm | 15C |
Grants
TCB Grant - Application KXaUgOmS5czXyZZ4fZYWJw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 05/16/2017 Application Dated: 05/16/2017 |
| Shenzhen Sky Jiarun Technology Co., Ltd |
| 4th East, Building 18, Hetai Industrial Zone |
| Heping Community, Fuyong Street, Baoan District |
| Shenzhen, China |
| Attention: Triven Kung |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALGQ-BTM835B |
| Name of Grantee: | Shenzhen Sky Jiarun Technology Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Power listed is conducted. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for portable application with a minimum distance of 5mm to human bodies. |
EAS Grant - Application KXaUgOmS5czXyZZ4fZYWJw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen Sky Jiarun Technology Co., Ltd 4th East, Building 18, Hetai Industrial Zone Heping Community, Fuyong Street, Baoan District Shenzhen, China |
Date of Grant: 05/16/2017 Application Dated: 05/16/2017 |
| Attention: Triven Kung |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALGQ-BTM835B |
| Name of Grantee: | Shenzhen Sky Jiarun Technology Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Bluetooth module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Power listed is conducted. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for portable application with a minimum distance of 5mm to human bodies. |
