FCC ID 2ALJJ-PL4002
4G Smart Phone
by PCD, LLC
Grantee Code: 2ALJJ Product Code: PL4002
Latest application date: 2017-04-25
Device Images
FCC ID Device Details
| FCC ID | 2ALJJ-PL4002 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ALJJ |
| Product Code | PL4002 |
| Applicant Business | PCD, LLC 🇺🇸 |
| Related Domains |  pcdlatam.com |
| Equipment Class | 4G Smart Phone |
| Test Firm | Shenzhen SEM.Test Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-04-25 |
| 706.5-713.5 MHz | Original Equipment | 2017-04-25 |
| 2402-2480 MHz | Original Equipment | 2017-04-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-25 | PDF 179.8 KB |
| Internal Photos | Internal Photos | 2017-04-25 | PDF 2 MB |
| EX Metadata only | External Photos | 2017-04-25 | PDF 467.5 KB |
| External Photos | External Photos | 2017-04-25 | PDF 467.5 KB |
| Label Info & Location | ID Label/Location Info | 2017-04-25 | PDF 87.2 KB |
| Test Set Up Photos | Test Setup Photos | 2017-04-25 | PDF 390.1 KB |
| Test Setup Photos DSS+DTS | Test Setup Photos | 2017-04-25 | PDF 227.1 KB |
| Test Setup Photos JBP | Test Setup Photos | 2017-04-25 | PDF 195.4 KB |
| Appendix for Band 17-1 Test Report | Test Report | 2017-04-25 | PDF 5.5 MB |
| Appendix for Band 17-2 Test Report | Test Report | 2017-04-25 | PDF 5.6 MB |
| Appendix for Band 7-1 Test Report | Test Report | 2017-04-25 | PDF 5.8 MB |
| Appendix for Band 7-2 Test Report | Test Report | 2017-04-25 | PDF 5.7 MB |
| Appendix for Band 7-3 Test Report | Test Report | 2017-04-25 | PDF 5.8 MB |
| Appendix for Band 7-4 Test Report | Test Report | 2017-04-25 | PDF 5 MB |
| PCE 2G+3G Test Report | Test Report | 2017-04-25 | PDF 4.6 MB |
| PCE 4G Tst Report | Test Report | 2017-04-25 | PDF 145.7 KB |
| SAR Test Report | RF Exposure Info | 2017-04-25 | PDF 3.4 MB |
| Test Report BT DSS | Test Report | 2017-04-25 | PDF 571.3 KB |
| Test Report BT DTS | Test Report | 2017-04-25 | PDF 312.4 KB |
| Test Report JBP | Test Report | 2017-04-25 | PDF 200.7 KB |
| Test Report WiFi DTS | Test Report | 2017-04-25 | PDF 547.9 KB |
| Confidential Request Letter | Cover Letter(s) | 2017-04-25 | PDF 481.1 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-04-25 | PDF 481.1 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-04-25 | PDF 481.1 KB |
| Confidentialty Request Letter | Cover Letter(s) | 2017-04-25 | PDF 481.1 KB |
| Label Justification Letter | Cover Letter(s) | 2017-04-25 | PDF 483.4 KB |
| Power of Attorney | Cover Letter(s) | 2017-04-25 | PDF 497.3 KB |
| Power of Attorney Letter | Cover Letter(s) | 2017-04-25 | PDF 497.3 KB |
| Exhibit for Calibration Certificate SAR Report | RF Exposure Info | 2017-04-25 | PDF 2.5 MB |
| Exhibit for the Calibration Cert. SAR Report | RF Exposure Info | 2017-04-25 | PDF 2.5 MB |
| Block Diagram Metadata only | Block Diagram | PDF 13.7 KB | |
| Schematics Metadata only | Schematics | PDF 604.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 453.3 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 51.6 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 84.3 KB |
Application Information
| Application ID | doTielc74gnk8hqPydzroQ== |
|---|---|
| Final Action Date | 2017-04-25 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026362798 |
| Model | PL4002 |
| Equipment Class | JBP - Part 15 Class B Computing Device Peripheral |
| Device Description | 4G Smart Phone |
| Responsible Party | Mauricio Velasco, CTO LATAM, mvelasco@pcdlatam.com , +1.631.495.7537 |
| Test Firm | Jandy So, Shenzhen SEM.Test Technology Co., Ltd., jandyso@semtest.com.cn  , 086-755-33663308 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| doTielc74gnk8hqPydzroQ== | 2017-04-25 | Original Equipment |
| HUhWpCA767HMBvLPSDAuaw== | 2017-04-25 | Original Equipment |
| BNdOdXj47+svzkmnXU3UPQ== | 2017-04-25 | Original Equipment |
| 2L3mexGPTxVsp4mo9ZwbrA== | 2017-04-25 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 706.5-713.5 MHz | 0.191 | 0.0067ppm | 4M49G7D | 27 | |
| 709-711 MHz | 0.1687 | 0.0068ppm | 8M93G7D | 27 | |
| 709-711 MHz | 0.1871 | 0.0069ppm | 8M94W7D | 27 | |
| 824.2-848.8 MHz | 0.369 | 0.0885ppm | 249KG7W | 22H | |
| 826.4-846.6 MHz | 0.2655 | 0.0813ppm | 4M10F9W | 22H | |
| 1850.2-1909.8 MHz | 0.6324 | 0.033ppm | 246KGXW | 24E | |
| 1850.2-1909.8 MHz | 0.3532 | 0.0346ppm | 251KG7W | 24E | |
| 2402-2480 MHz | 0.0027000 | 15C | CC | ||
| 2402-2480 MHz | 0.0007 | 15C | CC | ||
| 2412-2462 MHz | 0.0269 | 15C | CC | ||
| 2505-2565 MHz | 0.191 | 0.0019ppm | 8M94W7D | 27 | |
| 2510-2560 MHz | 0.171 | 0.002ppm | 17M9G7D | 27 | |
| 2510-2560 MHz | 0.1714 | 0.0019ppm | 17M9W7D | 27 |
Grants
TCB Grant - Application HUhWpCA767HMBvLPSDAuaw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 04/25/2017 Application Dated: 04/25/2017 |
| PCD, LLC |
| 1500 Tradeport Drive, Suite A |
| Orlando, FL 32824 |
| Attention: Mauricio Velasco , CTO LATAM |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALJJ-PL4002 |
| Name of Grantee: | PCD, LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | 4G Smart Phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.0269 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0007 |
| Output Power listed is the maximum conducted output power. SAR compliance for body-worn operating configurations is limited to belt-clips and holsters that have no metallic components in the assembly and cause the device to operate with the minimum separation distance of 1.0-cm, as described in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific, and simultaneous transmission conditions are 0.19 W/kg, <0.10 W/kg, <0.10 W/kg, and 1.27 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
