FCC ID 2ALVWW-07-FS
W-07-FS
by GuangZhou XinMai Electronics CO.,LTD
Grantee Code: 2ALVW Product Code: W07FS
Latest application date: 2017-04-23
Device Images
FCC ID Device Details
| FCC ID | 2ALVWW-07-FS |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ALVW |
| Product Code | W07FS |
| Applicant Business | GuangZhou XinMai Electronics CO.,LTD 🇨🇳 |
| Equipment Class | W-07-FS |
| Test Firm | BZT Testing Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 202.75 MHz | Original Equipment | 2017-04-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2017-04-23 | PDF 1.2 MB |
| Internal photos | Internal Photos | 2017-04-23 | PDF 1.4 MB |
| External photos | External Photos | 2017-04-23 | PDF 1.8 MB |
| Label | ID Label/Location Info | 2017-04-23 | PDF 80.1 KB |
| Test setup | Test Setup Photos | 2017-04-23 | PDF 261.3 KB |
| Test report | Test Report | 2017-04-23 | PDF 2.7 MB |
| Cover letter | Cover Letter(s) | 2017-04-23 | PDF 149.3 KB |
| RF Exposure | RF Exposure Info | 2017-04-23 | PDF 70.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 61.9 KB | |
| Schematics Metadata only | Schematics | PDF 246.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 232.5 KB | |
| Tune up Metadata only | Parts List/Tune Up Info | PDF 189.8 KB |
Application Information
| Application ID | EZO5xHdDpB+5lIbsPOKSTg== |
|---|---|
| Final Action Date | 2017-04-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026458547 |
| Model | W-07-FS |
| Frequency Range | 202.75 MHz |
| Equipment Class | TBF - Licensed Broadcast Transmitter Held to Face |
| Device Description | W-07-FS |
| Responsible Party | ruihui yuan, Manager, 1016790038@qq.com  , 13533949237 |
| Test Firm | Bruce Zhang, BZT Testing Technology Co., Ltd., bruce@bzt.org.cn  , (86)-0755-33071680 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is EIRP. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| EZO5xHdDpB+5lIbsPOKSTg== | 2017-04-23 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application EZO5xHdDpB+5lIbsPOKSTg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 04/23/2017 Application Dated: 04/23/2017 |
| GuangZhou XinMai Electronics CO.,LTD |
| 3 Floor, B Building,10 Number Nan bang sheng |
| two road Jinghu Street ,Hua du district |
| Guangzhou City, China |
| Attention: ruihui yuan , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALVWW-07-FS |
| Name of Grantee: | GuangZhou XinMai Electronics CO.,LTD |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | W-07-FS |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| M4 | 74.861 | 202.75 - 202.75 | 0.00325 | 10.4 PM | 73K3F3E |
| Output power listed is EIRP. |
| M4: | Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. |
EAS Grant - Application EZO5xHdDpB+5lIbsPOKSTg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
GuangZhou XinMai Electronics CO.,LTD 3 Floor, B Building,10 Number Nan bang sheng two road Jinghu Street ,Hua du district Guangzhou City, China |
Date of Grant: 04/23/2017 Application Dated: 04/23/2017 |
| Attention: ruihui yuan , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ALVWW-07-FS |
| Name of Grantee: | GuangZhou XinMai Electronics CO.,LTD |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | W-07-FS |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| M4 | 74.861 | 202.75 - 202.75 | 0.00325 | 10.4 PM | 73K3F3E |
| Output power listed is EIRP. |
| M4: | Operation of this unit is limited to use at stations licensed for use under Part 74 of FCC Rules. |
