WV800 Mobile Phone Teardown Internal Photos - FCC ID 2AM86W-V800
FCC ID 2AM86W-V800
Int_Photos
Mobile Phone
by Wiko SAS
Document preview loads when visible.
Document Details
| FCC ID | 2AM86W-V800 |
|---|---|
| Document ID | 4502330 |
| Document Type | Internal Photos |
| Description | Int_Photos |
| Document Title | HD 271 S1 |
| Applicant | Wiko SAS |
| Equipment Class | Mobile Phone |
| Product Code | WV800 |
| Application ID | ISsU6vJCyywReduaoGI2/w== |
| Application Purpose | Original Equipment |
| Application Date | 2019-11-04 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0026697029 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Filippo Cesare FERRARA |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/03/2020 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-11-04 |
| Available | 2020-05-03 |
| Created | 2019-10-25 |
| Modified | 2019-10-25 |
| Pages | 9 |
| File Type | Adobe Acrobat PDF |
| File Size | 2092497 |
| File SHA-256 | b6b24d2db3c41e7fc513495279cdbc4bd5b306cf72c10e29821fc38c384b2fd2 |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 4502330, FCC.gov 4502316 |
