BTM Wireless headphone Teardown Internal Photos - FCC ID 2AMLDBTM
FCC ID 2AMLDBTM
Internal photos
Wireless headphone
Document preview loads when visible.
Document Details
| FCC ID | 2AMLDBTM |
|---|---|
| Document ID | 6738488 |
| Document Type | Internal Photos |
| Description | Internal photos |
| Applicant | Shenzhen ZFX Technology CO.,Ltd |
| Equipment Class | Wireless headphone |
| Product Code | BTM |
| Application ID | IBnLSYj3ln4TpBdg+YxniQ== |
| Application Purpose | Original Equipment |
| Application Date | 2023-08-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0027376615 |
| Test Firm | Shenzhen Microtest Co., Ltd. |
| Certified By | Eva Zhang VP |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-08-17 |
| Available | 2023-08-20 |
| Created | 2023-08-14 |
| Modified | 2023-08-14 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 1892614 |
| File SHA-256 | aba4c5f6260bb6ccb12a6007a63a2d9cdfd8a027e7505eea18cf911e85c8946d |
| PDF Metadata Author | Hank Yan |
| PDF Metadata Producer | Hank Yan Adobe PDF Library 15.0 |
| FCC.gov Sources | FCC.gov 6738488 |
