CSBT322 Bluetooth Speaker Teardown... - FCC ID 2AMSOCSBT-322

FCC ID 2AMSOCSBT-322

Internal photo

Bluetooth Speaker

by Summit Electronics LLC

Document preview loads when visible.

Document Details

FCC ID2AMSOCSBT-322
Document ID4018025
Document TypeInternal Photos
DescriptionInternal photo
Document TitleAppendix B: Photographs of EUT
ApplicantSummit Electronics LLC
Equipment ClassBluetooth Speaker
Product CodeCSBT322
Application ID7y1OQCceBWF+tk9QBVRRDQ==
Application PurposeOriginal Equipment
Application Date2018-09-25
Frequency Range2402-2480 MHz
FRN0026659094
Test FirmSHENZHEN TONGCE TESTING LAB
Certified ByBeryl Zhao EMC manager, Shenzhen Tongce Testing Lab
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-09-25
Available2018-09-25
Created2018-09-21
Modified2018-09-21
Pages4
File TypeAdobe Acrobat PDF
File Size856583
File SHA-256b112e9fe0b679c4a472ca4982073084d7957d942cc7181b35a218a8ae9eff8d4
PDF Metadata AuthorSky123.Org
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 4018025
