XF638 WALKIE TALKIE Test Setup Photos - FCC ID 2AN6WXF-638

FCC ID 2AN6WXF-638

Test setup

WALKIE TALKIE

by Shenzhen XinFuChuang Electronic Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AN6WXF-638
Document ID3722382
Document TypeTest Setup Photos
DescriptionTest setup
Document TitleEMC TRF Template
ApplicantShenzhen XinFuChuang Electronic Co., Ltd.
Equipment ClassWALKIE TALKIE
Product CodeXF638
Application ID+ZmtOfIjFuvsi+0aZpHaYQ==
Application PurposeOriginal Equipment
Application Date2018-01-22
Frequency Range462.55-462.725 MHz
FRN0026967950
Test FirmShenzhen Huatongwei International Inspection Co.,
Certified ByXingbing Zhao General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-01-22
Available2018-01-22
Created2017-12-28
Modified2018-01-04
Pages1
File TypeAdobe Acrobat PDF
File Size127090
File SHA-25641e14ca30e60ae7abd91c1a5ce8f36e30344de3f66b49ffd5c9743c6ecdf0eef
PDF Metadata Authoreie
PDF Metadata Producereie Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3722382
