TYLC5 Wi-Fi Module Test Setup Photos - FCC ID 2ANDL-TYLC5

FCC ID 2ANDL-TYLC5

Test Setup Photos

Wi-Fi Module

by Hangzhou Tuya Information Technology Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2ANDL-TYLC5
Document ID4314185
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleEXHIBIT C_TEST SETUP PHOTOGRAPHS
ApplicantHangzhou Tuya Information Technology Co.,Ltd
Equipment ClassWi-Fi Module
Product CodeTYLC5
Application IDUoyteIB0FuvFZHbpU7zyFg==
Application PurposeOriginal Equipment
Application Date2019-06-11
Frequency Range2412-2462 MHz
FRN0026759332
Test FirmBay Area Compliance Laboratories Corp. (Kunshan)
Certified ByXiaodong Shou
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2019-06-11
Available2019-06-11
Created2019-04-24
Modified2019-06-12
Pages2
File TypeAdobe Acrobat PDF
File Size1130885
File SHA-256f74c5ff2d0a7f98927bb88202a3656b22dcfcd2a92c3e0f98eb50c2ea2c1d292
PDF Metadata Authorbaclks150
PDF Metadata Producerbaclks150 Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 4314185
