FS040U LTE USB Modem Label Diagram - FCC ID 2ANKMFS040U

FCC ID 2ANKMFS040U

Label info

LTE USB Modem

by Shanghai Tricheer Technology Co.,Ltd.

Document preview loads when visible.

Document Details

FCC ID2ANKMFS040U
Document ID3589366
Document TypeID Label/Location Info
DescriptionLabel info
ApplicantShanghai Tricheer Technology Co.,Ltd.
Equipment ClassLTE USB Modem
Product CodeFS040U
Application IDmqQdxi3JFQ2jy6aCP30Hwg==
Application PurposeOriginal Equipment
Application Date2017-10-02
Frequency Range2498.5-2687.5 MHz
FRN0026796276
Test FirmBV 7Layers Communications Technology (Shenzhen) Co
Certified ByAmyee Qian
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/01/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-10-02
Available2017-10-02
Created2017-09-26
Modified2017-09-26
Pages1
File TypeAdobe Acrobat PDF
File Size179457
File SHA-256a2aed25a89da459d064c1044b6099bd2d9baa72c21397ce2fefa3a7e9c921d8d
PDF Metadata Authoramqian Bureau Veritas
PDF Metadata Produceramqian Adobe PDF Library 15.0
FCC.gov SourcesFCC.gov 3589366
