FCC ID 2ANLH-XPA125B1

2ANLHXPA125B1, 2ANLH XPA125B1, 2ANLH-XPA125B1, 2ANLH-XPAI25BI, 2ANLH-XPA12SB1

Chongqing Xiegu Technology Co.,Ltd. Linear Power Amplifier -XPA125B1

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2ANLH-XPA125B1 is 2ANLH. The remaining characters of the FCC ID, -XPA125B1, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: Linear Power Amplifier

App # Purpose Date Unique ID
1 Original Equipment 2018-11-29 8f5eyvWBuqTLZk5XhMS5EA==

Operating Frequencies

Frequency RangePower OutputEmission DesignatorRule Parts Line Entry
1.8-30 MHz110 WattsXXX97 1
50-54 MHz90 WattsXXX97 2
