K540 Smart Phone Teardown Internal Photos - FCC ID 2AO6ZK540
FCC ID 2AO6ZK540
Internal Photos
Smart Phone
Document preview loads when visible.
Document Details
| FCC ID | 2AO6ZK540 |
|---|---|
| Document ID | 3979385 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal Photos--已看-----updated 0824 |
| Applicant | Epik One America Corporation |
| Equipment Class | Smart Phone |
| Product Code | K540 |
| Application ID | C8LXedhT5UJAg0taiOirKQ== |
| Application Purpose | Original Equipment |
| Application Date | 2018-08-27 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0027313469 |
| Test Firm | Bay Area Compliance Laboratories Corp. (Shenzhen) |
| Certified By | Sunny Choi |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2018-08-27 |
| Available | 2018-08-27 |
| Created | 2018-08-24 |
| Modified | 2018-08-24 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 1055750 |
| File SHA-256 | a4fa0d2783fae2aa9f3100fb4b7b2c3cf6cf56cde8a36ac4617ecb6bc130acab |
| PDF Metadata Author | SZ8104 |
| PDF Metadata Producer | SZ8104 Acrobat Distiller 9.0.0 (Windows) |
| FCC.gov Sources | FCC.gov 3979385, FCC.gov 3979374, FCC.gov 3979363 |
