LSD4BTK5Y Bluetooth Module Test Setup... - FCC ID 2AOFDLSD4BT-K5Y

FCC ID 2AOFDLSD4BT-K5Y

Test Setup Photos

Bluetooth Module

by Zhejiang Lierda Internet of Things technology Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2AOFDLSD4BT-K5Y
Document ID4260337
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleBL-SZ1930151-AR RF test setup photo
ApplicantZhejiang Lierda Internet of Things technology Co.,Ltd
Equipment ClassBluetooth Module
Product CodeLSD4BTK5Y
Application IDL5p9Ho9ueB+uu1PgvS8wyA==
Application PurposeOriginal Equipment
Application Date2019-04-30
Frequency Range2402-2480 MHz
FRN0027026012
Test FirmShenzhen BALUN Technology Co., Ltd.
Certified ByXuewen Wu Certification Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2019-04-30
Available2019-04-30
Created2019-04-17
Modified2019-04-19
Pages4
File TypeAdobe Acrobat PDF
File Size1175124
File SHA-256707f09e1e1538e15fc41b7d38d160b6876ebec50f6923b59e8e850f334836c4b
FCC.gov SourcesFCC.gov 4260337
