ZWA023 Smart Switch 7 Teardown Internal Photos - FCC ID 2AOGIZWA023

FCC ID 2AOGIZWA023

INT_PHOTO

Smart Switch 7

by AEOTEC LIMITED

Document preview loads when visible.

Document Details

FCC ID2AOGIZWA023
Document ID4793546
Document TypeInternal Photos
DescriptionINT_PHOTO
Document TitleZWA023-A_internal Photox
ApplicantAEOTEC LIMITED
Equipment ClassSmart Switch 7
Product CodeZWA023
Application IDcsqENCGbNRnBFSurt3l3xA==
Application PurposeOriginal Equipment
Application Date2020-07-06
Frequency Range908.42 MHz
FRN0027036524
Test FirmSHENZHEN STS TEST SERVICES CO.,LTD.
Certified ByScott Ding
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-07-06
Available2020-07-06
Created2020-05-15
Modified2020-05-15
Pages3
File TypeAdobe Acrobat PDF
File Size949609
File SHA-25676e8acefe8c9faed4b74caea4ae92223817a2bb889415fe8becc311d3bc12db7
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 4793546
