S201 Mobile terminal Test Setup Photos - FCC ID 2AOOFS201

FCC ID 2AOOFS201

Test setup photos of Part15B

Mobile terminal

by Shenzhen Two Monkey technology co. Ltd.

Document preview loads when visible.

Document Details

FCC ID2AOOFS201
Document ID3711815
Document TypeTest Setup Photos
DescriptionTest setup photos of Part15B
Document TitleEMC TRF Template
ApplicantShenzhen Two Monkey technology co. Ltd.
Equipment ClassMobile terminal
Product CodeS201
Application IDZxZibnfYCiJN84p72NzHPg==
Application PurposeOriginal Equipment
Application Date2018-01-12
FRN0027106814
Test FirmShenzhen Huatongwei International Inspection Co.,
Certified ByBeck Wang Certification Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-01-12
Available2018-01-12
Created2018-01-05
Modified2018-01-05
Pages2
File TypeAdobe Acrobat PDF
File Size238696
File SHA-256e0553fc685b01f573d1abdee539cc45c38c4105f98b3f3beb9dc1ab3ef587e7e
PDF Metadata AuthorTara Mitchell
PDF Metadata ProducerTara Mitchell Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3711815
