ZBBRIDGEP SONOFF New Zigbee Bridge Test... - FCC ID 2APN5ZBBRIDGEP

FCC ID 2APN5ZBBRIDGEP

Test Setup Photos

SONOFF New Zigbee Bridge

by Shenzhen Sonoff Technologies Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2APN5ZBBRIDGEP
Document ID5793202
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Titletest Setup photos 15.247
ApplicantShenzhen Sonoff Technologies Co., Ltd.
Equipment ClassSONOFF New Zigbee Bridge
Product CodeZBBRIDGEP
Application IDV/88ooLTjCTbcAKKraB36A==
Application PurposeClass II Permissive Change
Application Date2022-03-31
Frequency Range2402-2480 MHz
FRN0027467786
Test FirmCHINA CERTIFICATION ICT CO., LTD (DONGGUAN)
Certified ByJerry Shi
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2022-03-31
Available2022-03-31
Created2022-03-21
Modified2022-03-21
Pages3
File TypeAdobe Acrobat PDF
File Size446816
File SHA-2562270aea06ff69bfcd7dd63165386dd9e43b9929331cdfa0c7e8d063d7574c3ce
PDF Metadata Authordg06062
PDF Metadata Producerdg06062 Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 5793202
