HGD2 Wireless Display Adapter Test Setup Photos - FCC ID 2AQ5R-HG-D2
FCC ID 2AQ5R-HG-D2
Test Setup Photos
Wireless Display Adapter
Document preview loads when visible.
Document Details
| FCC ID | 2AQ5R-HG-D2 |
|---|---|
| Document ID | 9529429 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | Shenzhen KTC Commercial Display Technology CO.,LTD. |
| Equipment Class | Wireless Display Adapter |
| Product Code | HGD2 |
| Application ID | RsyUujx0gwmf+LzGP/oD0g== |
| Application Purpose | Original Equipment |
| Application Date | 2026-08-05 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0027827005 |
| Test Firm | Guangdong Global Testing Technology Co., Ltd. |
| Certified By | Kang Tao |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Submitted | 2026-08-05 |
| Available | 2026-08-05 |
| Pages | 0 |
| File Type | Adobe Acrobat PDF |
| File Size | 949698 |
| File SHA-256 | ac5d10d0c71e74799aa7a3c61d7b32fb2155a55ac19baf50e735fcd4bdc7dcef |
| FCC.gov Sources | FCC.gov 9529429, FCC.gov 9529410 |
