TREKB1 Trek Mini Test Setup Photos - FCC ID 2AQ8LTREKB1
FCC ID 2AQ8LTREKB1
Test setup photos
Trek Mini
by Parsyl
Document preview loads when visible.
Document Details
| FCC ID | 2AQ8LTREKB1 |
|---|---|
| Document ID | 4954885 |
| Document Type | Test Setup Photos |
| Description | Test setup photos |
| Document Title | BL-SZ2050721-AR RF test setup photo |
| Applicant | Parsyl |
| Equipment Class | Trek Mini |
| Product Code | TREKB1 |
| Application ID | Gkx3UflyRtMDTX6gOwFMaQ== |
| Application Purpose | Original Equipment |
| Application Date | 2020-10-15 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0027846211 |
| Test Firm | Shenzhen BALUN Technology Co., Ltd. |
| Certified By | Murat Erdogan Director of Manufacturing |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 04/12/2021 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2020-10-15 |
| Available | 2021-04-12 |
| Created | 2020-08-22 |
| Modified | 2020-08-22 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 627691 |
| File SHA-256 | 6a50f063db611a61fb33a3f8087be18abb7e8ef0dc424b9dab4ff7a5af30de86 |
| PDF Metadata Author | denghui.guo |
| PDF Metadata Producer | Acrobat Distiller 10.0.0 (Windows) denghui.guo |
| FCC.gov Sources | FCC.gov 4954885 |
