WS118 HiTune X6 Hybrid Active... - FCC ID 2AQI5-WS118

FCC ID 2AQI5-WS118

Schematics R

HiTune X6 Hybrid Active Noise-Cancelling Earbuds

by Ugreen Group Limited

Document preview loads when visible.

Document Details

FCC ID2AQI5-WS118
Document ID5476937
Document TypeSchematics
DescriptionSchematics R
Document TitleNo Title
ApplicantUgreen Group Limited
Equipment ClassHiTune X6 Hybrid Active Noise-Cancelling Earbuds
Product CodeWS118
Application IDOwmAcDu67DA84hO26wlnwg==
Application PurposeOriginal Equipment
Application Date2021-09-30
Frequency Range2402-2480 MHz
FRN0026099358
Test FirmShenzhen BCTC Testing Co., Ltd.
Certified ByChi Yang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-09-30
Available2021-09-30
Created2021-07-28
Modified2021-09-30
Pages1
File TypeAdobe Acrobat PDF
File Size75219
File SHA-256ea06969630b261814566b4ddde9d70da8acf31a9fd902df67f5b293bbce471bd
PDF Metadata AuthorUser: Windows NT/95/98 User
PDF Metadata CreatorA ClibPDF program
PDF Metadata Producer[ClibPDF Library 2.01-r2-7] Windows 9x/NT
FCC.gov SourcesFCC.gov 5476937
