D45 Bluetooth headset Teardown Internal Photos - FCC ID 2AQK8-D45

FCC ID 2AQK8-D45

Internal photos

Bluetooth headset

by Chandasung Tech (Shenzhen) Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AQK8-D45
Document ID4387504
Document TypeInternal Photos
DescriptionInternal photos
Document Title1
ApplicantChandasung Tech (Shenzhen) Co., Ltd.
Equipment ClassBluetooth headset
Product CodeD45
Application ID5CAt/9X4A737etTuCz+uIw==
Application PurposeOriginal Equipment
Application Date2019-08-06
Frequency Range2402-2480 MHz
FRN0027685387
Test FirmShenzhen HUAK Testing Technology Co., Ltd.
Certified ByLisa Peng Attestation Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-08-06
Available2019-08-06
Created2019-08-01
Modified2019-08-06
Pages3
File TypeAdobe Acrobat PDF
File Size813427
File SHA-256efc6be91cbf9f8ae85e02fcd9cfe178ea9f4b7c66559f83a0624e008ea2ceee3
PDF Metadata AuthorTian
PDF Metadata ProducerTian Microsoft® Word 2010
FCC.gov SourcesFCC.gov 4387504
