P001R1 Karie Connectivity Module Label Diagram - FCC ID 2AQKR-P001R1

FCC ID 2AQKR-P001R1

Label

Karie Connectivity Module

by AceAge Inc.

Document preview loads when visible.

Document Details

FCC ID2AQKR-P001R1
Document ID4004892
Document TypeID Label/Location Info
DescriptionLabel
ApplicantAceAge Inc.
Equipment ClassKarie Connectivity Module
Product CodeP001R1
Application ID1QRTNcWz46bVFXLJkSamJA==
Application PurposeOriginal Equipment
Application Date2018-09-13
Frequency Range2402-2480 MHz
FRN0027682418
Test FirmJianYan Testing Group Shenzhen Co., Ltd.
Certified ByBruce Zhang EMC lab manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-09-13
Available2018-09-13
Created2018-08-06
Modified2018-08-06
Pages1
File TypeAdobe Acrobat PDF
File Size138711
File SHA-256f35e42cbc160f010b3d7f4b0c246ffa1f82b8ccab9dbcab5048476abfc5cc84d
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Adobe PDF Library 10.0
FCC.gov SourcesFCC.gov 4004892, FCC.gov 4004862, FCC.gov 4004677, FCC.gov 4004629
