EDC114 5.8G Radar module Teardown Internal... - FCC ID 2ARDMEDC114
FCC ID 2ARDMEDC114
Internal Photos
5.8G Radar module
Document preview loads when visible.
Document Details
| FCC ID | 2ARDMEDC114 |
|---|---|
| Document ID | 6593441 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Figure 5 |
| Applicant | ShenZhen Easydetek Technology CO. LTD. |
| Equipment Class | 5.8G Radar module |
| Product Code | EDC114 |
| Application ID | 9GfDYiO3qdC0B5c+LXOHxQ== |
| Application Purpose | Original Equipment |
| Application Date | 2023-06-13 |
| Frequency Range | 5750-5870 MHz |
| FRN | 0027877331 |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
| Certified By | TOM CHEN |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-06-13 |
| Available | 2023-06-13 |
| Created | 2023-06-08 |
| Modified | 2023-06-08 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 1127479 |
| File SHA-256 | c90bfefd3fb7c47a627d5792d145c541638e2f4d8709e5ff2b21f33cbe6bf799 |
| PDF Metadata Author | anbotek |
| PDF Metadata Producer | WPS 文字 |
| FCC.gov Sources | FCC.gov 6593441 |
