REPORT No.:SZ18100025W07
TEST REPORT
APPLICANT
: Hyco Genyong Technology Co., Ltd.
PRODUCT NAME
: Smart Watch
MODEL NAME
: W562
BRAND NAME
: HYCO
FCC ID
: 2ARHS-W562
STANDARD(S)
: 47 CFR Part 15 Subpart E
TEST DATE
: 2018-10-18 to 2018-10-20
ISSUE DATE
: 2018-11-07
Tested by:
Wang Meng (Test Engineer)
Approved by:
Peng Huarui ( Supervisor )
NOTE: This document is issued by MORLAB, the test report shall not be reproduced except in full without prior written permission of the
company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for
validation and information confirmed at our website.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
REPORT No.:SZ18100025W07
DIRECTORY
1. Technical Information ··················································································· 4
1.1. Applicant and Manufacturer Information ······················································· 4
1.2. Companion Equipment(Master) Description ·················································· 4
1.3. Equipment Under Test (EUT) Description ······················································ 4
1.4. The channel number and frequency of EUT ··················································· 6
1.5. Test Standards and Results ········································································ 7
1.6. Environmental Conditions ·········································································· 7
2. 47 CFR Part 15C Requirements ······································································ 8
2.1. Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) ··········· 8
Annex A The waveform of the radar ·································································· 19
Annex B Test Uncertainty ················································································ 22
Annex C Testing Laboratory Information ··························································· 23
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 2 of 24
REPORT No.:SZ18100025W07
Change History
Issue
Date
Reason for change
1.0
2018-11-07
First edition
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 3 of 24
REPORT No.:SZ18100025W07
1. Technical Information
Note: Provide by applicant.
1.1. Applicant and Manufacturer Information
Applicant:
Hyco Genyong Technology Co., Ltd.
Applicant Address:
Room 105, 1/F, Building B, No.999 of Huaxu Road, Qingpu
District, Shanghai, CN
Manufacturer:
HYCO Information Technology Co., Ltd
Manufacturer Address:
Room 3A07, Tower B, North Zone, No.999, Huaxu Road, Qingpu
District, Shanghai, CN
1.2. Companion Equipment(Master) Description
Product Name:
Router
Manufacturer:
Cisco
FCC ID:
LDK102091
Serial No:
FGL1848X9S5
Antenna Gain:
2.1 dBi
1.3. Equipment Under Test (EUT) Description
Product Name:
Smart Watch
Serial No:
(N/A, marked #1 by test site)
Hardware Version:
W562_V1.2
Software Version:
W562-FL_6.0_20180625_1408
Modulation Type:
OFDM
Modulation Mode:
802.11a, 802.11n(HT20), 802.11n(HT40)
Operating Frequency Range:
5.180 GHz- 5.240 GHz; 5.260 GHz -5.320 GHz ;
5.745GHz- 5.825GHz
Channel Number:
Refer to 1.3
Antenna Type:
FPC Antenna
Antenna Gain:
-0.23 dBi
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 4 of 24
REPORT No.:SZ18100025W07
Battery
Brand Name:
HYCO
Model No.:
964655P
Serial No.:
(N/A, marked #1 by test site)
Capacity:
3600mAh
Rated Voltage:
3.8V
Charge Limit:
4.35V
AC Adapter 1
Accessory Information:
Brand Name:
AOHAI
Model No.:
A18A-050100U-US2
Serial No.:
(N/A, marked #1 by test site)
Rated Input:
Rated Output:
100-240V, 50/60Hz, 0.2A
5V, 1A
AC Adapter 2
Brand Name:
N/A
Model No.:
UT-146A-5100
Serial No.:
(N/A, marked #1 by test site)
Rated Input:
Rated Output:
100-240V, 50/60Hz, 0.15A
5V, 1A
Note 1: The EUT has two adaptors, both of the two adaptors were tested, only the worst test
result(Adapter1) were recorded in the test report.
Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by
the applicant and/or manufacturer.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 5 of 24
REPORT No.:SZ18100025W07
1.4. The channel number and frequency of EUT
Frequency Range: 5180MHz-5240MHz
Bandwidth
20MHz
40MHz
Channel
Frequency (MHz)
Channel
Frequency (MHz)
36
5180
40
5200
44
5220
48
5240
38
5190
46
5230
Channel
Frequency (MHz)
Channel
Frequency (MHz)
52
5260
56
5280
60
5300
64
5320
54
5270
62
5310
Channel
Frequency (MHz)
Channel
Frequency (MHz)
149
5745
153
5765
157
5785
161
5805
165
5825
151
5775
159
5795
Frequency Range: 5260MHz-5320MHz
Bandwidth
20MHz
40MHz
Frequency Range: 5745-5825MHz
Bandwidth
20MHz
40MHz
Note 1: The black bold channels were selected for test.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 6 of 24
REPORT No.:SZ18100025W07
1.5. Test Standards and Results
The objective of the report is to perform testing according to 47 CFR Part 15 Subpart E (U-NII band)
for the EUT FCC ID Certification:
No
Identity
Document Title
47 CFR Part 15 (5-1-14 Edition)
Radio Frequency Devices
Test detailed items/section required by FCC rules and results are as below:
No.
Section
Description
15.407(h)
TPC and DFS
Test Date
Test Engineer
Result
Oct 19, 2018
Tu Ya’nan
PASS
Note2: The DFS section for U-NII band is applicable to this report, the other test items are
documented in a separate report.
Note3: These RF tests were performed according to the method of measurements prescribed in
KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02.
1.6. Environmental Conditions
During the measurement, the environmental conditions were within the listed ranges:
Temperature (°C):
15 - 35
Relative Humidity (%):
30 -60
Atmospheric Pressure (kPa):
86-106
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 7 of 24
REPORT No.:SZ18100025W07
2. 47 CFR Part 15C Requirements
2.1. Transmit Power Control (TPC) and Dynamic Frequency
Selection (DFS)
2.1.1. Requirement
According to FCC section 15.407(h), (1) Transmit power control (TPC). U-NII devices operating in
the 5.25-5.35 GHz band and the 5.47-5.725 GHz band shall employ a TPC mechanism. The U-NII
device is required to have the capability to operate at least 6 dB below the mean EIRP value of 30
dBm. A TPC mechanism is not required for systems with an e.i.r.p. of less than 500 mW.(2) Radar
Detection Function of Dynamic Frequency Selection (DFS). U-NII devices operating with any part
of its 26 dB emission bandwidth in the 5.25-5.35 GHz and 5.47-5.725 GHz bands shall employ a
DFS radar detection mechanism to detect the presence of radar systems and to avoid co-channel
operation with radar systems. Operators shall only use equipment with a DFS mechanism that is
turned on when operating in these bands. The device must sense for radar signals at 100 percent
of its emission bandwidth. The minimum DFS detection threshold for devices with a maximum
e.i.r.p. of 200 mW to 1 W is −64 dBm. For devices that operate with less than 200 mW e.i.r.p. and a
power spectral density of less than 10 dBm in a 1 MHz band, the minimum detection threshold is
−62 dBm. The detection threshold is the received power averaged over 1 microsecond referenced
to a 0 dBi antenna. For the initial channel setting, the manufacturers shall be permitted to provide
for either random channel selection or manual channel selection.
A U-NII network will employ a DFS function to detect signals from radar systems and to avoid
co-channel operation with these systems. This applies to the 5250-5350 MHz and/or 5470-5725
MHz bands.1
Within the context of the operation of the DFS function, a U-NII device will operate in either Master
Mode or Client Mode. U-NII devices operating in Client Mode can only operate in a network
controlled by a U-NII device operating in Master Mode.2
Tables 1 and 2 shown below summarize the information contained in sections 5.1.1 and 5.1.2.
Table 1: Applicability of DFS Requirements Prior to Use of a Channel
Operational Mode
Requirement
Master
Client Without Radar
Detection
Client With Radar
Detection
Non-Occupancy Period
Yes
Not required
Yes
DFS Detection Threshold
Yes
Not required
Yes
Channel Availability Check Time
Yes
Not required
Not required
U-NII Detection Bandwidth
Yes
Not required
Yes
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 8 of 24
REPORT No.:SZ18100025W07
Table 2: Applicability of DFS requirements during normal operation
Operational Mode
Requirement
Master
Client Without Radar Detection
DFS Detection Threshold
Yes
Not required
Channel Closing Transmission Time
Yes
Yes
Channel Move Time
Yes
Yes
U-NII Detection Bandwidth
Yes
Not required
Additional requirements for
devices with multiple
bandwidth modes
Master Device or Client
with Radar Detection
Client Without Radar
Detection
U-NII Detection Bandwidth and
Statistical Performance Check
All BW modes must be tested
Not required
Channel Move Time and Channel
Closing Transmission Time
Test using widest BW mode
available
Test using the widest BW
mode available for the link
Any single BW mode
Not required
All other tests
Note: Frequencies selected for statistical performance check (Section 7.8.4) should include
several frequencies within the radar detection bandwidth and frequencies near the edge of the
radar detection bandwidth. For 802.11 devices it is suggested to select frequencies in each of
the bonded 20 MHz channels and the channel center frequency.
The operational behavior and individual DFS requirements that are associated with these modes
are as follows:
Master Devices
a) The Master Device will use DFS in order to detect Radar Waveforms with received signal
strength above the DFS Detection Threshold in the 5250 − 5350 MHz and 5470 − 5725 MHz bands.
DFS is not required in the 5150 − 5250 MHz or 5725 − 5825 MHz bands.
b) Before initiating a network on a Channel, the Master Device will perform a Channel Availability
Check for specified time duration (Channel Availability Check Time) to ensure that there is no radar
system operating on the Channel, using DFS described under subsection a) above.
c) The Master Device initiates a U-NII network by transmitting control signals that will enable other
U-NII devices to Associate with the Master Device.
d) During normal operation, the Master Device will monitor the Channel (In-Service Monitoring) to
ensure that there is no radar system operating on the Channel, using DFS described under a).
e) If the Master Device has detected a Radar Waveform during In-Service Monitoring as described
under d), the Operating Channel of the U-NII network is no longer an Available Channel. The
Master Device will instruct all associated Client Device(s) to stop transmitting on this Channel
within the Channel Move Time. The transmissions during the Channel Move Time will be limited to
the Channel Closing Transmission Time.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 9 of 24
REPORT No.:SZ18100025W07
f) Once the Master Device has detected a Radar Waveform it will not utilize the Channel for the
duration of the Non-Occupancy Period. 3
g) If the Master Device delegates the In-Service Monitoring to a Client Device, then the
combination will be tested to the requirements described under d) through f) above.
Client Devices
a) A Client Device will not transmit before having received appropriate control signals from a
Master Device.
b) A Client Device will stop all its transmissions whenever instructed by a Master Device to which it
is associated and will meet the Channel Move Time and Channel Closing Transmission Time
requirements. The Client Device will not resume any transmissions until it has again received
control signals from a Master Device.
c) If a Client Device is performing In-Service Monitoring and detects a Radar Waveform above the
DFS Detection Threshold, it will inform the Master Device. This is equivalent to the Master Device
detecting the Radar Waveform and d) through f) of section 5.1.1 apply.
d) Irrespective of Client Device or Master Device detection the Channel Move Time and Channel
Closing Transmission Time requirements remain the same.
e) The client test frequency must be monitored to ensure no transmission of any type has occurred
for 30 minutes. Note: If the client moves with the master, the device is considered compliant if
nothing appears in the client non-occupancy period test. For devices that shut down (rather than
moving channels), no beacons should appear.
DFS Detection Thresholds
Table 3 below provides the DFS Detection Thresholds for Master Devices as well as Client
Devices incorporating In-Service Monitoring.
Table 3: DFS Detection Thresholds for Master Devices and Client Devices with Radar
Detection
Maximum Transmit Power
Value (See Notes 1, 2, and 3)
EIRP ≥ 200 milliwatt
-64 dBm
EIRP < 200 milliwatt and
-62 dBm
power spectral density < 10 dBm/MHz
EIRP < 200 milliwatt that do not meet the power spectral
-64 dBm
density requirement
Note 1: This is the level at the input of the receiver assuming a 0 dBi receive antenna.
Note 2: Throughout these test procedures an additional 1 dB has been added to the amplitude of
the test transmission waveforms to account for variations in measurement equipment. This will
ensure that the test signal is at or above the detection threshold level to trigger a DFS response.
Note3: EIRP is based on the highest antenna gain. For MIMO devices refer to KDB Publication
662911 D01.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 10 of 24
REPORT No.:SZ18100025W07
Response Requirements
Table 4 provides the response requirements for Master and Client Devices incorporating DFS.
Table 4: DFS Response Requirement Values
Parameter
Value
Non-occupancy period
Minimum 30 minutes
Channel Availability Check Time
60 seconds
Channel Move Time
10 seconds
See Note 1.
Channel Closing Transmission Time
200 milliseconds + an aggregate of 60 milliseconds
over remaining 10 second period. See Notes 1 and 2.
U-NII Detection Bandwidth
Minimum 100% of the U-NII 99% transmission power
bandwidth. See Note 3.
Note 1: Channel Move Time and the Channel Closing Transmission Time should be performed
with Radar Type 0. The measurement timing begins at the end of the Radar Type 0 burst.
Note 2: The Channel Closing Transmission Time is comprised of 200 milliseconds starting at
the beginning of the Channel Move Time plus any additional intermittent control signals required
to facilitate a Channel move (an aggregate of 60 milliseconds) during the remainder of the 10
second period. The aggregate duration of control signals will not count quiet periods in between
transmissions.
Note 3: During the U-NII Detection Bandwidth detection test, radar type 0 should be used. For
each frequency step the minimum percentage of detection is 90 percent. Measurements are
performed with no data traffic.
2.1.2. Test Description
According to Section 7.2 of KDB 905462 D02 V01R01
1. Setup for Master with injection at the Master
(Example Conducted Setup where UUT is a Master and Radar Test Waveforms are injected into
the Master)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 11 of 24
REPORT No.:SZ18100025W07
2. Setup for Client with injection at the Master
(Example Conducted Setup where UUT is a Client and Radar Test Waveforms are injected into the
Master)
3. Setup for Client with injection at the Client
(Example Conducted Setup where UUT is a Client and Radar Test Waveforms are injected into the
Client)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 12 of 24
REPORT No.:SZ18100025W07
2.1.3. Test Result
a. Test sequence and Channel loading between Master and Client
Test Channel
Frequency(MHz)
Payload
62
5310
40.13%
(Test sequence)
(Payload)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 13 of 24
REPORT No.:SZ18100025W07
b. Radar Test Waveforms are injected into the Master:
c. EUT is a Client Device Without Radar Detection :
Channel &
Bandwidth
Requirement
802.11 n(HT40)
5230MHz
802.11 n(HT40)
5310MHz
MORLAB
Operational
Mode
Client Without
Radar Detection
Test
Result
Limit
Verdict
Channel Move Time
Yes
0.63s
<10s
PASS
Channel Closing
Transmission Time
Yes
0.002s
<1s
PASS
Channel Move Time
Yes
0.62s
<10s
PASS
Channel Closing
Transmission Time
Yes
0.003s
<1s
PASS
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 14 of 24
REPORT No.:SZ18100025W07
Test Plots
Note: T0 denotes the start time of the Radar single transmitted, T1 denotes the end time of the
Radar single transmit end. T2 denotes the data transmission time of 200ms from T1. T3 denotes
the end of the Channel Move Time, the time of T3 from T1 is less than 12s.
(5230MHz, 802.11n (HT40))
(5310MHz, 802.11n (HT40))
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 15 of 24
REPORT No.:SZ18100025W07
d. Time per bin
Channel
Frequency (MHz)
Time Per Bin (ms)
46
5230
0.50
62
5310
0.50
Test Plot
(5230MHz, 802.11n (HT40))
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 16 of 24
REPORT No.:SZ18100025W07
(5310MHz, 802.11n (HT40))
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 17 of 24
REPORT No.:SZ18100025W07
e. verification of Non-occupancy time
The sweep time is 2.1ks(35min) which is able to meet the requirements of Non-occupancy time.
Channel & Bandwidth
Test Result
Limit
Verdict
802.11 n (HT40)
5270MHz
35min
≥30min
PASS
(Non-occupancy time, 5270MHz, 802.11n (HT40))
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 18 of 24
REPORT No.:SZ18100025W07
Annex A The waveform of the radar
(Type 0)
(Type 1)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 19 of 24
REPORT No.:SZ18100025W07
(Type 2)
(Type 3)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 20 of 24
REPORT No.:SZ18100025W07
(Type 4)
(Type 5)
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 21 of 24
REPORT No.:SZ18100025W07
Annex B Test Uncertainty
Where relevant, the following measurement uncertainty levels have been estimated for test
performed on the EUT as specified in CISPR 16-1-2:
Test items
Uncertainty
Bandwidth
±5%
Conducted Emission
±2.44dB
This uncertainty represent an expanded uncertainty expressed at approximately the 95%
confidence level using a coverage factor of k=2
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 22 of 24
REPORT No.:SZ18100025W07
Annex C Testing Laboratory Information
1. Identification of the Responsible Testing Laboratory
Company Name:
Shenzhen Morlab Communications Technology Co., Ltd.
Department:
Morlab Laboratory
Address:
FL.3, Building A, FeiYang Science Park, No.8 LongChang
Road, Block 67, BaoAn District, ShenZhen, GuangDong
Province, P. R. China
Responsible Test Lab
Manager:
Mr. Su Feng
Telephone:
+86 755 36698555
Facsimile:
+86 755 36698525
2. Identification of the Responsible Testing Location
Name:
Shenzhen Morlab Communications Technology Co., Ltd.
Morlab Laboratory
Address:
FL.3, Building A, FeiYang Science Park, No.8 LongChang
Road, Block 67, BaoAn District, ShenZhen, GuangDong
Province, P. R. China
3. Facilities and Accreditations
All measurement facilities used to collect the measurement data are located at FL.3, Building A,
FeiYang Science Park, Block 67, BaoAn District, Shenzhen, 518101 P. R. China. The test site is
constructed in conformance with the requirements of ANSI C63.10-2013 and CISPR Publication 22;
the FCC designation number is CN1192, the test firm registration number is 226174.
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 23 of 24
REPORT No.:SZ18100025W07
4. Test Equipments Utilized
4.1 Conducted Test Equipments
Equipment Name
Serial No.
Type
Manufacturer
Cal. Date
Cal. Due
Power Splitter
NW521
1506A
Weinschel
2018.04.17
2019.04.16
Attenuator 1
(N/A.)
10dB
Resnet
2018.04.17
2019.04.16
Attenuator 2
(N/A.)
3dB
Resnet
2018.04.17
2019.04.16
MY53470836
N9010A
Agilent
2017.12.03
2018.12.02
Angilent
N5182B
MY53050961
2018.04.17
2019.04.16
RF cable
(30MHz-26GHz)
CB01
RF01
Morlab
N/A
N/A
Coaxial cable
CB02
RF02
Morlab
N/A
N/A
SMA connector
CN01
RF03
HUBERSUHNER
N/A
N/A
EXA Signal
Analzyer
MXG Vector Signal
Generator
4.2Auxiliary Test Equipment
Equipment Name
Model No.
Brand Name
Manufacturer
Cal.Date
Cal. Due
Computer
T430i
Think Pad
Lenovo
N/A
N/A
END OF REPORT
MORLAB
SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd.
FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road,
Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China
Tel: 86-755-36698555
Fax: 86-755-36698525
Http://www.morlab.cn
E-mail: service@morlab.cn
Page 24 of 24
Download: W562 Smart Watch ( with BT,WIFI) Test Report CE RF Hyco Genyong Technology Co., Ltd.
Mirror Download [FCC.gov]W562 Smart Watch ( with BT,WIFI) Test Report CE RF Hyco Genyong Technology Co., Ltd.
Document ID4114533
Application IDRc8mYEjCBhGYtLh/i5A2AA==
Document DescriptionTest Report_NII_5G DFS
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize74.97kB (937131 bits)
Date Submitted2018-12-23 00:00:00
Date Available2018-12-24 00:00:00
Creation Date2018-11-23 13:42:23
Producing SoftwareAdobe PDF Library 9.0
Document Lastmod2018-11-23 13:42:48
Document TitleCE RF TEST REPORT
Document CreatorAcrobat PDFMaker 9.1 Word 版
Document Author: X

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : X
Company                         : Microsoft
Create Date                     : 2018:11:23 13:42:23+08:00
KSO Product Build Ver           : 2052-9.1.0.4855
Modify Date                     : 2018:11:23 13:42:48+08:00
Source Modified                 : D:20181123054154
Tagged PDF                      : Yes
XMP Toolkit                     : Adobe XMP Core 4.2.1-c043 52.372728, 2009/01/18-15:08:04
Metadata Date                   : 2018:11:23 13:42:48+08:00
Creator Tool                    : Acrobat PDFMaker 9.1 Word 版
Document ID                     : uuid:289b1cda-811c-4fe5-8826-469573d82855
Instance ID                     : uuid:03fe44e4-50f1-43d0-a109-be5a82fb24bb
Subject                         : 44
Format                          : application/pdf
Title                           : CE RF TEST REPORT
Creator                         : X
Producer                        : Adobe PDF Library 9.0
Page Layout                     : OneColumn
Page Count                      : 24
