T20 Outlet Test Setup Photos - FCC ID 2ARJH-T20

FCC ID 2ARJH-T20

setup photo

Outlet

by Shenzhen Champon Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2ARJH-T20
Document ID8774387
Document TypeTest Setup Photos
Descriptionsetup photo
ApplicantShenzhen Champon Technology Co., Ltd.
Equipment ClassOutlet
Product CodeT20
Application ID+gJ6J0rvwKLmPnFdSQvONg==
Application PurposeOriginal Equipment
Application Date2025-11-20
Frequency Range2402-2480 MHz
FRN0027932193
Test FirmHD TESTING TECHNOLOGY (GUANGDONG) CO., LTD.
Certified ByChengbo Chen CEO
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceNo
Submitted2025-11-20
Available2025-11-20
Created2025-11-04
Modified2025-11-04
Pages2
File TypeAdobe Acrobat PDF
File Size380164
File SHA-256de713b7a054e2f63e2e484debe09c847f33cda5ef6cbb480f3e7f926c258cb27
PDF Metadata Authorkevin.liang
PDF Metadata ProducerWPS 文字
FCC.gov SourcesFCC.gov 8774387
